Operating Instructions
CD Stereo System
SC-UA3
Model No.
Thank you for purchasing this product.
For optimum performance and safety, please read these instructions carefully.
Please keep this manual for future reference.
Panasonic Corporation
GN
GS
En
Web Site: http://www.panasonic.com
TQBJ2013-2
L0417CH2058
© Panasonic Corporation 2017

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the SC-UA3 and is the answer not in the manual?

Questions and answers

Related Manuals for Panasonic SC-UA3

Summary of Contents for Panasonic SC-UA3

  • Page 1 CD Stereo System SC-UA3 Model No. Thank you for purchasing this product. For optimum performance and safety, please read these instructions carefully. Please keep this manual for future reference. Panasonic Corporation Web Site: http://www.panasonic.com TQBJ2013-2 L0417CH2058 © Panasonic Corporation 2017...

  • Page 2: Maintenance

    Your system and the illustrations can look differently. The symbols on this product (including the accessories) represent the following: Class II equipment (The construction of the product is double-insulated.) Standby For Australia and New Zealand Disposal of Old Equipment and Batteries Only for European Union and countries with recycling systems This symbol is only valid in the European...

  • Page 3: Safety Precautions

    Safety precautions WARNING! Unit • To reduce the risk of fire, electric shock or product damage, – Do not expose this unit to rain, moisture, dripping or splashing. – Do not place objects filled with liquids, such as vases, on this unit. –...

  • Page 4: Note On Ac Mains Lead

    Note on AC mains lead (For the AC mains plug of three pins) Before use Remove the connector cover. How to replace the fuse The location of the fuse differ according to the type of AC mains plug (figures A and B). Confirm the AC mains plug fitted and follow the instructions below.

  • Page 5: About Bluetooth

    ® trademarks owned by Bluetooth SIG, Inc. and any use of such marks by Panasonic Corporation is under license. Other trademarks and trade names are those of their respective owners. Google Play and Android are trademarks of Google Inc.

  • Page 6: Troubleshooting

    • For some built-in Bluetooth devices, you have to set the ® audio output to “SC-UA3” manually. Read the operating instructions of the device for details. Sound from the device is interrupted. • The device is out of the 10 m communication range. Move the device nearer to the system.
  • Page 7 • The system cannot show the remaining play time for variable bit rate (VBR) tracks. Remote control code When other Panasonic equipment responds to the remote control of this system, change the remote control code for this system. Preparation Press [USB/CD] repeatedly to select “CD”.

  • Page 8: Transporting The Unit

    Transporting the unit Preparation Disconnect all connected devices and cables from the unit. Always carry the unit as illustrated below when moving the unit around. Holding both sides of the unit Holding the handle bar Note: • Put the unit on a flat safe surface. •...

  • Page 9: Making The Connections

    Making the connections Connect the AC mains lead only after all the other connections have been made. Except for Australia and New Zealand Connect the FM indoor antenna. Place the antenna where reception is best. Adhesive tape (not supplied) Connect the AC mains lead. Do not use any other AC mains leads except the supplied one.

  • Page 10: Specifications

    Specifications █ Amplifier section RMS output power stereo mode Front ch (both ch driven) 150 W per channel (4 Ω), 1 kHz, 30% THD Total RMS stereo mode power 300 W PMPO output power Except for Australia and New Zealand 3300 W █...
  • Page 11 █ Terminal section USB port USB standard USB 2.0 full speed Media file format support MP3 (*.mp3) USB device file system FAT12, FAT16, FAT32 Digital audio input Optical digital input Optical terminal Sampling frequency 32 kHz, 44.1 kHz, 48 kHz, 96 kHz Analog audio input Audio input Pin jack (1 system)
  • Page 12 Overview of controls Do the procedures with the remote control. You can also use the buttons on the unit if they are the same. Standby/on switch [`], [1] Select the jukebox Press to switch the unit from on to standby mode or USB port ( vice versa.

  • Page 13: Preparing Media

    (Z“Disconnecting a device”). Press [ If “PAIRING” is shown, continue with step 3. Press [PLAY MENU] to select “PAIRING” and then press [OK]. Select “SC-UA3” from the Bluetooth menu of the ® device. If prompted for a passkey, input “0000” or “1234”.
  • Page 14 If this system is connected to a Bluetooth device, ® disconnect it (Z“Disconnecting a device”). Press [ “BLUETOOTH READY” is shown. Select “SC-UA3” from the Bluetooth menu of the ® device. The name of the connected device is shown for a few seconds.

  • Page 15: Media Playback

    Media playback The following marks indicate the availability of the feature. CD-R/RW in CD-DA format or with MP3 files. USB device with MP3 files. Bluetooth device. BLUETOOTH ® Basic playback CD USB BLUETOOTH Play Press [4/9]. Stop Press [8]. The position is memorised. “RESUME”...
  • Page 16 █ Note on disc • This system can play CD-R/RW with CD-DA or MP3 format content. • Before playback, finalise the disc on the device it was recorded on. • Some CD-R/RW cannot be played because of the condition of the recording. █...

  • Page 17: Sound Effects

    Using the “Panasonic MAX Juke” app You can download and install the free Android™ app “Panasonic MAX Juke” on Google Play™ for additional features, such as to request song playback from multiple devices simultaneously. You can also call up the tracks you want to play through the app.

  • Page 18: Using A Microphone

    Karaoke Except for Australia and New Zealand Preparation Select the music source. Note: The Karaoke function is switched off when you switch off the system. Changing the Karaoke effect You can use the Karaoke effect function to add the sound effects.

  • Page 19: External Equipment

    Play timer (Except for Bluetooth , AUX and D-IN source) ® You can set the timer to come on at a certain time to wake you up. Preparation Set the clock. Press [SETUP] repeatedly to select “TIMER ADJ”. Press [R, T] to set the start time and then press [OK].
  • Page 20 Bluetooth device again. ® Software update Occasionally, Panasonic may release updated software for this unit that may add or improve the way a feature operates. These updates are available free of charge. For more details, refer to the following website.
  • Page 21 Subject to the conditions of this warranty Panasonic or its Authorised Service Centre will perform necessary service on the product, without charge for parts or labour, if in the opinion of Panasonic the product is found to have a manufacturing defect within one (1) year or (12 months) (the “warranty period”) from the date of purchase appearing on your purchase receipt.
