Power Supply User's Manual
V550W / V650W / V750W
1. Model Descriptions
RS-550-AFBA-G1: 550W Active PFC Power Supply
RS-650-AFBA-G1: 650W Active PFC Power Supply
RS-750-AFBA-G1: 750W Active PFC Power Supply
2. Specifications
Type: Intel ATX 12V V2.31
Input Voltage: 100~240Vac
Input Frequency : 47Hz ~ 63Hz
Fan: 120mm Cooler Master Silencio FP FAN
Power Good Signal: 100 ~ 500ms
Hold Up Time: > 16ms
Efficiency: 90% Typically
MTBF
: >
Protection OCP / OPP / OVP / OTP / SCP / UVP
Dimension: 150 × 140 × 86mm (5.9 × 5.5 × 3.4 in)
Operation Temperature 0~40℃ Nominal Input Voltage
Regulatory CE / TUV / FCC / UL / EAC / CCC /
100,000Hours
:
:
BSMI / RCM / KC
:
(
Ver 3.0 2015/07
)
Advertisement
Table of Contents
Related Manuals for Cooler Master RS-550-AFBA-G1
Summary of Contents for Cooler Master RS-550-AFBA-G1
- Page 1 Ver 3.0 2015/07 Power Supply User's Manual V550W / V650W / V750W 1. Model Descriptions RS-550-AFBA-G1: 550W Active PFC Power Supply RS-650-AFBA-G1: 650W Active PFC Power Supply RS-750-AFBA-G1: 750W Active PFC Power Supply 2. Specifications Type: Intel ATX 12V V2.31...
-
Page 2: Installation
RS-550-AFBA-G1 AC Input 100-240V~ 8-4A 60-50Hz +3.3V +12V -12V DC Output 0.3A 2.5A 12.5W 100W 540W 3.6W Total Power 550W RS-650-AFBA-G1 AC Input 100-240V~ 9-4.5A 60-50Hz +3.3V +12V -12V DC Output 0.3A 2.5A 648W 3.6W 12.5W Total Power 650W RS-750-AFBA-G1... -
Page 3: Connector Descriptions
4. Connector Descriptions 4.1 Motherboard 24 Pin Connector(P1) Description Description Pin1 Pin13 +3.3V +3.3V +3.3V +3.3V -12V PS-ON P.G. +12V +12V +3.3V 4.2 CPU 4+4Pin Description Description Pin1 Pin5 +12V +12V +12V +12V 4.3 PCI-e 6+2Pin Connector Description Description Pin1 Pin5 +12V +12V +12V... -
Page 4: Weee Notice
4.4 S-ATA Connector Description +3.3V +12V 4.5 Peripheral 4-Pin Connector Description +12V 4.6 Floppy Connector Pin Description +12V 5. WEEE Notice English Disposal of Waste Equipment by Users in Private Households in the European Union. This symbol on the product or on its packaging indicates that this product must not be disposed of with your other household waste. -
Page 5: Warranty
English Warranty Cooler Master guarantees this device to be free of defects in material and workmanship, and provide a 5-year hardware limited warranty for the power supply on the date of purchase. Please register on our official website for your international limited warranty (http://www.coolermaster.com/member). - Page 6 (Cooler Master Technology Inc. 8F ., No. 788-1, Zhongzheng Rd., Zhonghe Dist., New Taipei City 23586, Taiwan (R.O.C.).) +886-2-2225-3517 Cooler Master Technology Inc. 8F ., No. 788-1, Zhongzheng Rd., Zhonghe Dist., New Taipei City 23586, Taiwan (R.O.C.). +886-2-2225-3517...
- Page 7 V Series...
- Page 8 Company information Asia Pacific - Cooler Master Technology Inc. 8F., No. 788-1, Zhongzheng Rd., Zhonghe Dist., New Taipei City 23586, Taiwan (R.O.C.). Tel: +886-2-2225-3517 Tech Support: https://account.coolermaster.com/ China - Cooler Master China Room 2062, Floor 6, No. 421, Weiqing Rd.,...
