Pelican 9440 RALS User Manual

9440 RALS
9440 RALS
EN
EN
USER MANUAL
CAUTION: PLEASE READ ENTIRE MANUAL BEFORE FIRST USE.
USER MANUAL
WARNING: KEEP FINGERS CLEAR OF MOVING PARTS AT ALL TIMES - FAILURE
TO COMPLY COULD RESULT IN INJURY.
Deployment Operation
CAUTION: PLEASE READ ENTIRE MANUAL BEFORE FIRST USE.
1. To deploy, release the red
latch then lift the outer collar
of the light head upwards until WARNING: KEEP FINGERS CLEAR OF MOVING PARTS AT ALL TIMES - FAILURE
all three legs release. (A)
2. Once all three legs are TO COMPLY COULD RESULT IN INJURY.
released, push the outer collar
downwards until all three legs
touch the ground.
Deployment Operation
3. Once all three legs have
touched the ground, while
supporting the outer collar, lift
1. To deploy, release the red
the switch housing upwards
until the red latch clicks into
latch then lift the outer collar
place. (B)
Mast Operation of the light head upwards until
1. Release each of the cam clamps and raise the light head until the desired height is
all three legs release. (A)
reached. Then re-clamp to hold in place.
2. Rotate the light head to the desired position.
2. Once all three legs are
Note: If the product is used in wet conditions, water may be captured at the base of the
released, push the outer collar
mast pole. Turn upside down in order to drain.
Light Operation
downwards until all three legs
CAUTION: DO NOT DIRECT LIGHT INTO EYES.
touch the ground.
1. Press switch once for full power.
3. Once all three legs have
2. Press again for medium power.
3. Press again for low power.
touched the ground, while
4. Press again to switch off.
The 9440 RALS features the ability to be used continuously while connected to the
supporting the outer collar, lift
charger.
The 9440 will default to the medium power level.
the switch housing upwards
The full power level is not available while connected to the charger. To select low power,
press the switch once more. Press again to switch off.
until the red latch clicks into
Storage Operation
place. (B)
1. Collapse the mast by releasing the cam clamps
one at a time while supporting the weight of the
light head.
Mast Operation
2. Position the light head upwards then pull the red
latch until the base of the product slides down to
the floor.
1. Release each of the cam clamps and raise the light head until the desired height is
3. Lift the outer collar upwards until level with the
light head. Then pull all three legs in using both
reached. Then re-clamp to hold in place.
hands and lift them over their locking fork at
the base while holding the latch in the release
2. Rotate the light head to the desired position.
position (as per diagram on main body).
Note: Please look closely at the bottom of the legs to understand how they are locked
in place - the legs must lift upwards before they can locate. The latch must be
Note: If the product is used in wet conditions, water may be captured at the base of the
released for the legs to move upwards. (C)
mast pole. Turn upside down in order to drain.
Battery Status Indication
Green = 100% - 65% capacity
Yellow = 65% - 30% capacity
Light Operation
Red = 30% - 0% capacity
Charging
CAUTION: DO NOT DIRECT LIGHT INTO EYES.
CAUTION: PLEASE READ BEFORE USE.
USE APPROVED CHARGER ONLY. ONLY USE CHARGER IN DRY ENVIRONMENT.
1. Press switch once for full power.
1. The charging socket is located at the base of the light.
2. Press again for medium power. Remove the dust cap and plug the charger in until it
clicks. (D)
2. Plug the charger into an electrical outlet.
3. Press again for low power.
3. The battery charge level is identified at the battery level
indicator next to the power switch. While charging, the
4. Press again to switch off.
indicator will flash red, yellow, green (depending on the
battery level) and will change to solid green once the
charge is complete.
The 9440 RALS features the ability to be used continuously while connected to the
4. To remove, press the latch on the charger plug and pull.
charger.
Product Care
The 9440 will default to the medium power level.
To ensure maximum product life please observe the following points:
1. Keep moving parts free of foreign objects.
The full power level is not available while connected to the charger. To select low power,
2. Do not stand on product.
3. Avoid use on extreme gradients.
press the switch once more. Press again to switch off.
4. Ensure charging dust cap is replaced after charging.
5. Do not use if damaged - contact dealer.
Storage Operation
1. Collapse the mast by releasing the cam clamps
one at a time while supporting the weight of the
light head.
RELEASE DATE DATE
2. Position the light head upwards then pull the red
8 MR 22 7-20-21
latch until the base of the product slides down to
IZE NUMBER OF FOLDS
the floor.
7.00"w 2
3. Lift the outer collar upwards until level with the
light head. Then pull all three legs in using both
TECHNICAL COPY
hands and lift them over their locking fork at
Jon French
the base while holding the latch in the release
No Changes
position (as per diagram on main body).
PROVED BY ALL TEAM MEMBERS
Note: Please look closely at the bottom of the legs to understand how they are locked
in place - the legs must lift upwards before they can locate. The latch must be
released for the legs to move upwards. (C)
Battery Status Indication
Green = 100% - 65% capacity
Yellow = 65% - 30% capacity
Red = 30% - 0% capacity
Charging
CAUTION: PLEASE READ BEFORE USE.
USE APPROVED CHARGER ONLY. ONLY USE CHARGER IN DRY ENVIRONMENT.
1. The charging socket is located at the base of the light.
Remove the dust cap and plug the charger in until it
clicks. (D)
2. Plug the charger into an electrical outlet.
3. The battery charge level is identified at the battery level
indicator next to the power switch. While charging, the
indicator will flash red, yellow, green (depending on the
battery level) and will change to solid green once the
charge is complete.
4. To remove, press the latch on the charger plug and pull.
Product Care
To ensure maximum product life please observe the following points:
1. Keep moving parts free of foreign objects.
2. Do not stand on product.
3. Avoid use on extreme gradients.
4. Ensure charging dust cap is replaced after charging.
5. Do not use if damaged - contact dealer.
Cat. # 9440
A B
C
D
VERSION
1
FOLDED SIZE
5.875"h x 8.50"w
PRODUCT MGR. TEAM
Paulo Quitain
3-2-22
Battery Conditioning
It is important that the new battery in this product is given an initial conditioning. The
charger should be left connected to the product after the Green indicator on the charger
is permanently on. In this state the battery receives a trickle charge and should be left
connected for 18-24 hours. There will be improvement to the light duration if this is
repeated for the first 8-10 charge cycles.
BATTERY SAFETY
BATTERY SAFETY – YOU MUST READ THESE WARNINGS AND INSTRUCTIONS
BEFORE USING OR CHARGING YOUR BATTERIES!
WARNING: HANDLE AND STORE BATTERIES PROPERLY TO AVOID INJURY OR
DAMAGE
BATTERIES CAN BE DANGEROUS!
IMPROPER HANDLING OF BATTERIES CAN LEAD TO LEAKING, FIRE OR
EXPLOSION WHICH CAN CAUSE SERIOUS INJURY OR PROPERTY DAMAGE.
A
Rechargeable Batteries
» Hazardous Location Safety Approvals for explosive environments are only valid for
the Pelican battery pack that is supplied with the equipment.
» For replacement battery packs, only use the approved Pelican battery pack for the
model of the product that you are using. The use of other battery packs will reduce
performance, expose the user or others to serious injury, and will invalidate the safety
approval.
» Equipment should only be charged in a non-hazardous location.
» Equipment should only be charged using the Pelican charger base that is supplied.
» Batteries should be charged and operated between the temperatures shown in this
table:
BATTERY TYPE
Lead Acid
Ni-MH
Li-Ion and
LiFePO4
» DO NOT charge rechargeable alkaline batteries while they are still in the equipment.
Charging the alkaline batteries while they are still in the equipment can cause internal
gas or heat generation resulting in venting, explosion or possibly fire which could
cause serious injury or property damage.
» Deep discharge* of the rechargeable batteries may cause batteries to vent potentially
dangerous gasses and electrolytes.
» It is strongly recommended to condition* batteries every three months. During
storage, the capacity of the battery decreases due to self-discharging. Leaving the
product unused for long periods of time will decrease the battery life. Withdrawal of
the charger from the product prior to a 'READY' indication will result in an inadequate
charge.
» If products are stored that contain regchargeable products, it is advisable to do so in
a cool, dry place. If the average temperature exceeds 25°C (77°F) (below 30°C or
86°F), the frequency of supplementary charging should increase.
» It is advisable to always condition a battery that has been stored before use.
* Deep Discharge: The battery has been allowed to discharge most of its capacity to a point beyond
which irreparable damage has occurred. See battery specifications for the specific levels.
* Condition a Battery: Charge your battery to the fullest capacity and then disconnect from charger. Let
the light run until it completely drains the battery and turns itself off. Place the flashlight back onto its
charger and completely recharge the battery before using it. This conditioning or "cycling" of the battery
will help it retain a fuller charge for a longer period of time.
Warning
» If the charger fails to indicate a full charge after repeated charging attempts, or the
battery exhibits a marked reduction in performance, a battery replacement is required.
» DO NOT use chargers designed for a different battery technology or equipment, or
model. Doing so may damage the product and expose the user to serious injury or
property damage.
» Ni-MH Rechargeable Battery Packs: DO NOT use Ni-MH rechargeable battery packs
for longer than three years or 500 charge/discharge cycles, whichever comes first.
Using Ni-MH rechargeable battery packs for longer than three years or 500 charge/
discharge cycles will reduce the performance of the battery and expose the user to
serious injury or property damage.
» Li-Ion and LiFePO4 Rechargeable Battery Packs: DO NOT use Li-Ion and LiFePO4
rechargeable battery packs for longer than five years. Using for a period longer than
five years will reduce the performance of the battery and expose the user to serious
injury or property damage.
» Lead Acid Battery: DO NOT use lead acid batteries for longer than five years or 400
charge/discharge cycles at 100% DOD ( Depth Of Discharge) * , whichever comes
first. Using lead acid batteries for longer than five years or 400 charge/discharge
cycles at 100% DOD will reduce the performance of the battery and expose the user
to serious injury or property damage.
* DOD (Depth Of Discharge) *: is the fraction or percentage of the capacity which has been removed
from the fully charged battery. Depth of Discharge is defined as the total amount of energy that is
discharged from a battery, divided by the battery's nominal capacity. Depth of discharge is normally
expressed as a percentage.
Battery Recycling
ALWAYS dispose of batteries properly at an approved battery recycling center. Failure to
do so may be a crime and can lead to the release of harmful toxic materials. Pelican has
partnered with Call 2 Recycle in the US and Canada to dispose of recyclable batteries.
Please call 1-800-822-8837 to find a battery recycling center near you.
C
Cat. # 9440
B
CHARGING OPERATING
TEMP TEMP
–15°C to 40°C –15°C to 50°C
(5°F to 104°F) (5°F to 122°F)
0°C to 40°C –20°C to 50°C
(32°F to 104°F) (–4°F to 122°F)
0°C to 45°C –20°C to 60°C
(32°F to 113°F) (–4° F to 140°F)
D
