Tokina FIRIN 100mm F2.8 FE MACRO Quick Start Manual

100mm F2.8 FE MACRO
ENGLISH
Part names
① Hood attachment mark
② Focus ring
③ Lens holding grip
How to attach and remove lens
Please follow the camera instruction manual for attaching and removing
the lens.
※Take care to not touch or hit electrical contacts on the mounting face
of the lens while attaching or removing.
Aperture Settings
Please set the aperture settings on the camera side in accordance with
the shooting mode.
Focusing
■ Auto Focus
Set your camera's focus mode to Auto Focus (AF).
The camera will automatically focus when the shutter button is
half-pushed.
■ Manual Focus
Set your camera's focus mode to manual Focus (MF).
Adjust focus by turning the focus ring while observing the camera
monitor and finder image.
It is also possible to conduct precision focusing using the display
enlarging function.
[Full-time Manual Function]
With this lens, it is possible to make slight focal adjustments manually
while the camera is in use with autofocus mode without switching the
focus mode.
Set the focus mode of the camera to Direct Manual Focus (DMF). Then,
focus using the autofocus function, and with the shutter button still in
the half-pushed position, make slight focal adjustments by turning the
focus ring. This is for precision focusing when taking portraits and when
conducting macro photography.
The focus ring spins in the same direction as other genuine lenses
manufactured by us.
Lens hood
The included lens hood prevents strong angular light from the side from
striking the front lens element and causing lens flare or ghosting that
would impact image quality.
Please be sure to always use the lens
hood when photographing to achieve
the best results possible.
■Attaching the lens hood
Line up the mark on the lens hood's side
with the white hood attachment mark on
the lens barrel, then turn the hood
clockwise unlike you feel and hear the
hood click into place.
Vignetting may occur if the hood is not
attached correctly.
SONY E-Mount Full Frame
①
②
③
④
⑤
④ Mount attachment mark
⑤ Lens signal contact
※ Please do not touch directly with hands.
※
Hood attachment mark
