Tokina MONOFOCAL LENS TC0614AI Specification

MONOFOCAL LENS
TC0614AI f=6mm F1:1.4 VIDEO IRIS
SPECIFICATION
MODEL NUMBER
IMAGE FORMAT
FOCAL LENGTH
MAXIMUM APERTURE
APERTURE RATIO
ANGLE
OF
VIEW
FILTER SIZE
DIMENSIONS
OPERATING TEMPERATURE RANGE
OPERATING HUMIDITY RANGE
INPUT VOLTAGE
CURRENT CONSUMPTION
INPUT SIGNAL
IRIS ACCURACY
SENSITIVITY
RESPONSE SPEED
CABLE COLOR
RED
WHITE
GREEN
BLACK
M.O.D.
DIAGONAL
HORIZONTAL
VERTICAL
WEIGHT
MOUNT
CONNECTION
POWER (DC+8V 16V)
VS OR V SIGNAL
REMOTE
GND
TOKINA Co.,Ltd.
Security Products Division
120-4 NOZUTA-MACHI,MACHIDA-SHI,
TOKYO, 195-0063 JAPAN
TEL:+81-42-734-8912 FAX:+81-42-735-1463
E-mail:cctv@tokina.co.jp
TC0614AI
1/2inch
6mm
F1.4
F1.4 250
0.3m
57.5°
46.0°
34.5°
W48.7×H37.0×D36.5mm
75g
10
30 70
C
DC+8V 16V
35mA OR LESS
VS OR V SIGNAL
±15% AT VIDEO SIGNAL LEVEL
AT VIDEO SIGNAL LEVEL
0.5 1.0Vp p
APPROX.1.5 SECONDS
45
