Busch-Jaeger 8216 U Manual

Hide thumbs Also See for 8216 U:

Download this manual

8216 U

Need help?

Do you have a question about the 8216 U and is the answer not in the manual?

Page 1 8216 U...
Page 4 Anschluss gemäß Anschlussgra 10 ... 230 V AC, ±10 %, 50 / 60 Hz Lautsprecher: °C … +40 °C...
Page 5 The device may only be installed in deep flush-mounted device boxes according to DIN 49073-1. EU declaration of conformity (simplified) Busch-Jaeger herewith declares that radio system types 8216 U conform to directive 2014/53EU. The complete text of the EU declaration of conformity is available at the following Internet address: ■...
Page 6: Operation / Setup
Technical Data Nominal voltage: 110 ... 230 V AC, ±10%, 50 / 60 Hz Operating temperature: 5°C to +40°C Protection type: IP 20 Power consumption during < 1 W the idle state: Maximum load capacity 2 x 1.5 W RMS: 4 …...
Page 7 For the connection, see the connection diagram. Loudspeaker: For MONO mode, the loudspeaker can be connected to the left (L- / L+) or right (R- / +) connecting terminals. Mains voltage: Phase (L): To terminal L Neutral conductor (N): To terminal N Options: A Simultaneous activation with room lighting.
Page 8 To access the extended operation manual, use the QR code or the QR link, see the heading of these brief instructions. Service Busch-Jaeger Elektro GmbH - A member of the ABB Group, Freisenbergstraße 2, D-58513 Lüdenscheid, Germany, Tel.: +49 2351 956-1600;...
