HeaterMate WIRELESS Owner's Manual

HEATERMATE WIRELESS
Thank you for choosing Heatermate Wireless.
This programmable temperature controller will provide
you with comfortable home environment and will help
you to save energy.
HEATERMATE WIRELESS
CURRENT
TARGET
SET CLOCK
SET OK
Control Unit
1. Quick Start-up Guide
1. Insert 2 AA batteries into Control Unit.
2. Press POWER button to turn Control Unit ON –
TARGET temperature will be displayed under
CURRENT temperature.
3. Plug Plug Unit into power socket.
4. By pressing UP/DOWN buttons on Control Unit,select
your desired TARGET temperature.
5. Plug your heater into Plug Unit.
6. The temperature sensor is located in the Control Unit,
please place it in the room where the temperature
needs to be controlled.
7. If child lock is activated, press and hold DOWN button
for 3 seconds to deactivate.
2. Speficiation
Control Unit
Temperature range.............................. 0~60 °C
Current Temp. Resolution........................0.1 °C
TARGET Temp. Resolution.........................1 °C
Power supply........................3V(2pcs* AA 1.5V)
Max.Rang......................20 meters in open land
Transmission Frequency...................433.92Mhz
Product demension.....................240x83x45mm
Net weight..................................................100g
Wall mount holder & Table stand
Plug Unit
Max. operation voltage/Frequency....240V/50Hz
Max.current/Load.............................10A/2400W
Product dimension......................132x62x76mm
Weight........................................................140g
HEAT COOL CD
ON/OFF
HEATERMATE WIRELESS
Plug unit
