- Page 1 Extreme Networks 5420 Series Quick Reference 5420F-8W-16P-4XE 5420F-24P-4XE 5420F-24S-4XE 5420F-24T-4XE 5420F-16MW-32P-4XE 5420F-16W-32P-4XE 5420F-48P-4XE 5420F-48P-4XL 5420F-48T-4XE 5420M-24T-4YE 5420M-24W-4YE 5420M-16MW-32P-4YE 5420M-48T-4YE 5420M-48W-4YE P/N 9036834-00 Rev. AB...
-
Page 2: Necessary Tools
1 Switch 3 Rack mount ears (2), cable (1), screws 2 Accessory box If the switch appears to be damaged, contact Extreme Networks. See “Getting Help” for more information. Extreme Networks does not include power input cords with this product. -
Page 3: Install Transceivers
Connecting to the Primary Power Source To attach your 5420 Series to an AC power source, do the following: Connect the AC power cord to the AC power input socket on the power supply and an AC power outlet. -
Page 4: Hardware Components
10/100/1000BASE-T full/half duplex MACsec capable ports with 802.3bt Type 4 PoE (90W) Note: 5420 Series switches have either PoE or non-PoE ports, not a mix of both. For component details, see 5420 Hardware Installation Guide. Figure 2 5420 Series: Sample Rear Panels... - Page 5 Interfaces Each 5420 Series includes a Micro-B USB console port, 2 SFP-DD stacking ports, an RJ-45 management port, an RJ-45 serial console port, and 2 USB A ports for connecting to memory. 5420 factory switches are pre-loaded with both EXOS and VOSS OSs.
-
Page 6: Getting Help
Getting Help For additional support related to 5420 Series switches or this document, contact Extreme Networks using one of the following methods: https://www.extremenetworks.com/documentation/ Product Documentation Phone: 1-800-998-2408 (toll-free in U.S. and Canada) Global Technical or +1-408-579-2826. For the support phone number in... - Page 7 • GB 4943.1-2011 • SANS IEC 60950 Optical Module Compliance Extreme Networks pluggable optical modules and direct-attach cables meet the following regulatory requirements: • UL and/or CSA registered component for North America • Class 1 or Class 1M Laser Product •...
- Page 8 Éliminez les piles usées en conformité aux règlements locaux d'élimination des piles. Hazardous Substances- China and Taiwan BSMI RoHS Guidance concerning the China and Taiwan BSMI RoHS (Restriction of Hazardous Substances) directive for this Extreme Networks® product can be found on the following web page: www.extremenetworks.com/support/documentation/restriction-hazardous- substances/ The page contains tables detailing the presence of 10 substances defined by the RoHS directive.
