For Thermal Transfer Barcode Printer
GP-1124T/1125T GP-1134T/1135T GP-1125Z/1135Z
Please read this user guide before printer operation
and keep this guide for reference.
Remark:
GP-1124T/1134T
paper roll and ribbon, without external holder.
GP-1125T /1135T
with paper roll and ribbon, with external holder.
User's Manual
series comes with Serial +USB + Parallel port, with
series comes with Serial +USB + Ethernet +Parallel port,

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the GP-1124T and is the answer not in the manual?

Questions and answers

Related Manuals for GPRINTER GP-1124T

Summary of Contents for GPRINTER GP-1124T

  • Page 1 User’s Manual For Thermal Transfer Barcode Printer GP-1124T/1125T GP-1134T/1135T GP-1125Z/1135Z Please read this user guide before printer operation and keep this guide for reference. Remark: GP-1124T/1134T series comes with Serial +USB + Parallel port, with paper roll and ribbon, without external holder.
  • Page 2 ON LINE: Power indicator ERROR: Error indicator RIBBON: Ribbon status Indicator Cover-open button PAUSE button FEED button LED indicator External paper entrance USB port Parallel port Power port Ethernet port Serial port Note: The interface of printer showed in picture may have some difference from the model your purchased.
  • Page 3 Print head Print head Ribbon Print media Paper guide Paper guide rod Gap/Black mark sensor Media bar Gap & black mark sensor Media path (Outside wound) Media path (inside wound) Rubber roller If you need more information about the product, please refer to the User’s Manual in CD. *The printer specification, accessory, spare parts and program are subject to change without prior notice.
  • Page 4 Print media loading 2.Insert the print media into the 1.Press two buttons on printer two shaft as picture showing, and fix sides to lift and open the cover. the label roll in the middle. 4.Press the button to open print 3.Load print media into the printer;...

  • Page 5: Ribbon Loading

    5.Pull out the print media till it pass gap sensor and then close printer head mechanismto complete media loading. Ribbon loading 2.Install ribbon dispenser and roll 1.Insert ribbon dispenser into into the printer, left side first , right an empty roll. side afterwards.
  • Page 6 3.Insert ribbon dispenser into 4.Open printer head by pressing 5.Install ribbon supply shaft into new ribbon the picture showing button the printer, left side first, right side afterwards 6.Put our ribbon and let it touch 7.Adjust the running wheel to let 8.Close the printer head by the print head and the step 1 the ribbon touch print head in...
  • Page 7 1.Introduction Thanks for choosing GP-1124T/1125T/1134T/1135T/ direct thermal transfer label printer. This series printer is built with 2sets of gear to drive motor,with capability of handling 300meters long ribbon and large label roll.Printer inner volume is fit for 5" OD(Outer Diameter)paper roll,if using external paper holder,you can install 8.4"OD industrial grade label roll.

  • Page 8: Thermal Transfer Printing

    2.LED Indicator and Function Direct Thermal Printing LED Indicator status Descriptions Printer is powered on and in normal Power indicator is on, Error indicator is off. printing status Power indicator flashes every 640ms, Printer is paused Error indicator is off. Power indicator is off,Error indicator goes Printer cover is opened for 80ms,then goes off for 160ms,printer...

  • Page 9: Button Function

    3.Button Function Feed When the printer is ready(LED blue fixed),click the button,label paper into the front end of a paper label. Pause The printer in the print, click the PAUSE button to print suspended. At this time power indicator is blue flashing. Just click the button, the print job resume normal. Power-on function The printer has six kinds of power on functions can be used to set or test the...

  • Page 10: Dip Switch Function

    4.DIP SWITCH FUNCTION Function DIP NO. Beeper Disabled Enabled ------ Reserved ------ Ribbon detect Disabled Enabled Sensor High sensitivity Normal Sensitivity Power on paper feed Disabled Enabled Enabled Reserved Disabled Baud rate set ------ Default value 7&8 BAUD RATE： BAUD RATE 9600 * 19200 38400...

  • Page 11: Troubleshooting

    5.Troubleshooting Below the table of contents are generally common problems and solutions, you can also contact your local service provider for more technical support. Problems Possible Reasons Solution and Suggestion Check power connector and Plug to AC outlet and plug to AC outset if plugs are correctly printer not well connected.
  • Page 12 cable 1. Check if RJ-45 green/orange LED indicator is on. 1.cable improperly connected 2.When printer receive and process printing data,LED 2.Pin configuration in cable two will be orange color; sides are not matching 3.Check if printer IP is each other assigned in DHCP mode 4.Check if fixed IP address is correctly set in printer...
  • Page 13 Clear unnecessary file from FLASH/ DRAM. DRAM only can save 256 files. Storage space is FLASH/ DRAM Storage is exceeded exceeded Max capacity:1024KB. (FLASH/ DRAM) FLASH only can save 256 files. Max capacity:1024KB. Re-install ribbon and/or label. Clean print head and print and print again.
