Linear PCM Recorder
Operating Instructions
PCM-A10
4-740-910-41(1)

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the PCM-A10 and is the answer not in the manual?

Questions and answers

Related Manuals for Sony PCM-A10

Summary of Contents for Sony PCM-A10

  • Page 1 Linear PCM Recorder Operating Instructions PCM-A10 4-740-910-41(1)

  • Page 2: Owner's Record

    The model number is located at the rear panel and the serial number is located at the rear panel. Record these numbers in the space provided below. Refer to these numbers whenever you call upon your Sony dealer regarding this product.

  • Page 3: Parts And Controls

    Parts and controls Built-in microphones Peak indicator Display window OPTION button T-MARK (track mark) button BACK/ HOME button STOP button REC/PAUSE (record/pause) button, recording indicator  (play/enter) button*¹ Control button (  DPC (Digital Pitch Control),    A-B (repeat A-B),  (review/fast backward),  (cue/fast forward)) (headphones) jack USB connector cover (You can find the USB connector retracted behind the cover.)

  • Page 4: Initial Settings

    VOL –/+ button Select on-screen instruction to turn on the Bluetooth function. On the smartphone, start REC Remote and select “PCM-A10” Enter (your linear PCM recorder) from the available device list. For detailed instructions, refer to the help of REC Remote and the manual supplied with the smartphone.
  • Page 5 Select “Yes” to start the initial settings. Select the display language. You can select from the following languages: English*, Español (Spanish), Français (French) * Default setting Set the current year, month, day, hour, and minute. To go back to the previous clock setting item, press BACK/HOME. Select “Next.”...
  • Page 6 Press to select the optimum recording volume level for the sound source. You can check the current recording volume level on the peak level meters. Adjust the recording volume so that the recording volume level stays around -12 dB ( ), which fits within the optimum range.
  • Page 7 Select the file you want to delete from the list of recorded files or play back the file you want to delete. Select “Delete a File” from the OPTION menu. “Delete?” appears and the selected file starts playing for your confirmation.
  • Page 8 “Add Device (Pairing)” from the HOME menu and follow the on-screen instruction to turn on the Bluetooth function. On the smartphone, start REC Remote and select “PCM-A10” (your linear PCM recorder) from the available device list. For detailed instructions, refer to the help of REC Remote and the manual supplied with the smartphone.

  • Page 9: Using The Home Menu

    Using the HOME menu You can use the HOME menu for a variety of operations, including locating and playing a recorded file and changing the settings of your linear PCM recorder. BACK/HOME Select Enter Press and hold BACK/HOME. The HOME menu screen appears. The HOME menu items are aligned in the following sequence.

  • Page 10: Installing Sound Organizer

    Copying files from your linear PCM recorder to a computer You can copy the files and folders from your linear PCM recorder to a computer to store them. Follow the instructions in “Charge” to connect your linear PCM recorder to a computer. Drag and drop the files or folders you want to copy from “PCMRECORDER”...
  • Page 11 Do not use alcohol, benzine or thinner. If you have any questions or problems concerning your unit, please consult your nearest Sony dealer. Notes on the Bluetooth function • Bluetooth wireless technology allows connection at a distance of up to about 10 m (33 feet).
  • Page 12 INCLUDING IN THE PROVINCE OF QUEBEC. POUR LES CONSOMMATEURS AUX ÉTATS-UNIS. NON APPLICABLE AU CANADA, Y COMPRIS LA PROVINCE DE QUÉBEC. If you have any questions about this product, you may call: Sony Customer Information Service Center 1-800-222-7669 or http://www.sony.com/...

  • Page 13: Bluetooth Specification

    Specifications Capacity (User available capacity*¹*²) 16 GB (approx. 12.80 GB = 13,743,895,347 Byte) Maximum recording time*³ (Built-in memory) The maximum recording time of all the folders is as follows. LPCM 96 kHz/24 bit 6 hours 35 minutes LPCM 48 kHz/24 bit 13 hours 15 minutes LPCM 48 kHz/16 bit 19 hours 50 minutes...
  • Page 14 5 • The BLUETOOTH® word mark and logos are registered trademarks owned by Bluetooth SIG, Inc. and any use of such marks by Sony Corporation is under license. Other trademarks and trade names are those of their respective owners.
