OWNER'S MANUAL
Bluetooth® LG Stereo Headset
Rev 1.0 AU
NOTE: For the proper performance and
to prevent any damage to, or misuse of the
headset, please read all of the information
carefully prior to using the headset.
Any modifications or changes to this
manual due to typographical errors or
inaccuracies of stated information shall
only be made by LG Electronics Inc.
Google Play
App Store
TONE-FP9A
TONE-FP9WA
www.lg.com
TONE-FP9EA
Copyright © 2021 LG Electronics Inc. All Rights Reserved
Advertisement
Table of Contents
Related Manuals for LG Free TONE-FP9A
Summary of Contents for LG Free TONE-FP9A
- Page 1 Any modifications or changes to this manual due to typographical errors or inaccuracies of stated information shall only be made by LG Electronics Inc. Google Play App Store TONE-FP9A TONE-FP9WA www.lg.com TONE-FP9EA Copyright © 2021 LG Electronics Inc. All Rights Reserved...
- Page 2 *A mid-sized ear gel is attached to the earbud by default. ! CAUTION Make sure authentic LG Electronics components are used. Using a non- authentic component may damage the product and thus void the warranty. Use the USB Type C™ cable/USB-C™ to AUX cable provided with the product.
- Page 3 1. Overview [Charging Case] Mood light (When you open the charging case, the mood light turns on and off.) Charging port UVnano LED Charging terminals UVnano LED Battery Status Indicator (up) Plug and Wireless Mode Switch UVnano Indicator (down)
- Page 4 [Earbuds] Microphone Speaker mesh Speaker mesh (Microphone) (Microphone) Touchpad Touchpad Charging terminals Charging terminals Microphone *Make sure that the charging terminal is not soiled with foreign substance. *The appearance and specifications of the actual product may differ depending on the model.
-
Page 5: How To Pair
2. How to pair Turn on the Bluetooth function on the mobile phone or the device to be connected. Open the cover of the charging case with the earbuds mounted on the case. Press and hold the touchpad of the left or right earbud for 3 to 5 seconds until the battery status indicator blinks in blue. - Page 6 Bluetooth and location information settings of the mobile device.) If the pop-up does not appear, select [LG-TONE-FP9] from the Bluetooth menu on the mobile phone and connect it (for users of iOS or Android 5.0 or lower versions).
- Page 7 3. Wearing Earbuds Separate the earbuds from the charging case and adjust them so that they fit comfortably in your ears. You can use ear gels that fit your ears to improve NOTE: Active Noise Canceling (ANC) performance and enjoy rich music sound.
-
Page 8: Playing Music
: Touch the left(Decrease volume) or the Volume right(Increase volume) earbud twice. Play Next : Touch the left or right earbud three times. NOTE: You can change the operation method of the function in the touchpad settings of the LG TONE Free app. -
Page 9: Mobile Calling Functions
5. Mobile Calling Functions Function Status Description Answering Calls Ringing Touch the left or right earbud once. Ending Calls Talking Touch the left or right earbud twice. If you make a call using a mobile phone, the Making Calls Idle call is automatically connected to the headset. - Page 10 Touch and hold the left or right earbud to switch between the ANC mode and the LAS mode. You can set the LAS and ANC functions in the LG TONE Free app. You can configure the Listen to the Ambient Sound mode and Conversation mode using the LG TONE Free app.
- Page 11 Touch and hold the left or right earbud to switch between the ANC mode and the LAS mode. You can set the LAS and ANC functions in the LG TONE Free app. You can configure the Listen to the Ambient Sound mode and Conversation mode using the LG TONE Free app.
- Page 12 7. UVnano The charging case has a built-in UVnano LED, which allows you to use your earbuds cleanly. If you charge the earbuds wired after mounting them on the charging case and closing the cover, the UVnano LED operates for 5 minutes. *UVnano is a compound word derived from the words UV and its unit, nanometer.
- Page 13 8. Charging [Wired Charging] When the charging cable is connected, the charging status is displayed in the charging case. NOTE: The earbuds and the charging case are charged at the same time. The charging port on the charging case cannot be used to supply power to mobile phones, etc.
- Page 14 2 Open the cover of the charging case to connect the charging case to the to the Bluetooth device that was previously connected. If the Plug and Wireless Mode is turned on, the earbuds and the LG TONE Free earbuds. Once the connection is established, the battery status indicator app are disconnected.
- Page 15 NOTE: Deactivate the Plug and Wireless Mode to reconnect the earbuds to the Bluetooth device that was previously connected. If the Plug and Wireless Mode is turned on, the earbuds and the LG TONE Free app are disconnected. The Plug and Wireless mode does not support the call function.
-
Page 16: Checking The Battery Status
10. Checking the Battery Status If earbuds are mounted in the charging case, the earbuds’ battery status is displayed. Otherwise, the charging case’s battery status is displayed. If the earbuds are mounted in the charging case while plugged in, the UVnano process will commence for 5 minutes. -
Page 17: Safety Precautions
The LG TONE Free (TONE-FP9A) is a lightweight wireless headset that uses Bluetooth technology. This product can be used as an audio accessory for devices supporting either the A2DP or Hands-Free Bluetooth Profile. Safety Precautions The following safety precautions are provided to prevent any unexpected accident or damage. - Page 18 ! CAUTION Choking Hazard: This product contains small parts that may present a choking hazard, Keep out of reach of children. Do not disassemble, adjust, or repair the product arbitrarily. Do not place the product near excessive heat or flammable material. The product may be damaged if an incompatible charger is used.
- Page 19 Do not store or transport at pressures lower than 11.6 kPa and at above 15000 m altitude. Replacement of a battery with an incorrect type that can defeat a safeguard (for example, in the case of some lithium battery types). Disposal of a battery into fire or a hot oven, or mechanically crushing or cutting of a battery, that can result in an explosion.
-
Page 20: Battery Status Indicator
HD Speaker If the communication network of the device you are connecting to supports HD Voice Calling, you can enjoy making voice calls and listening to music in high definition. Battery Status Indicator Status Description Bluetooth Search Mode The battery status indicator flashes in blue. The battery status indicator turns on and Battery below 20% off in red. -
Page 21: Out Of Range
Voice Alert, Change Equalizer Mode, Check Last Connected Location Information, and Find My Earbuds functions. Check out the app for more details. To install the “LG TONE Free” app, search LG TONE Free in the Google Play Store or App Store or scan the QR code below. -
Page 22: Troubleshooting
Troubleshooting If you see any of the following symptoms while using the product, make sure to recheck it. It may not be a malfunction. Symptom Cause and Solution The power does not Check the battery level and charge it. turn on If the mobile phone does not support headset and hands-free functions, you cannot use the If unable to make a... -
Page 23: Specifications And Features
Specifications and Features Item Comments Bluetooth V 5.2 (Headset/Hands-Free/A2DP/AVRCP) Specifications Earbud : 3.7 V / 68 mAh, Lithium-ion Battery Charging case : 3.7 V / 390 mAh, Lithium-ion Music Play Time ANC Off : Up to 10 & Up to 24 hours* Earbuds &... - Page 24 Frequency range 2402 MHz to 2480 MHz *Duration of use may vary depending on the connected mobile device, features being used, settings, signal strength, operating temperature, frequency band, and other methods of use.
-
Page 25: Declaration Of Confirmation
Declaration of Confirmation FCC NOTICE TO USERS: This device complies with part 15 of the FCC rules. Operation is subject to the following two conditions: (1) This device may not cause harmful interference, and (2) This device must accept any interference received, including interference that may cause undesired operation. - Page 26 DECLARATION OF CONFORMITY: Hereby, LG Electronics declares that the radio equipment type this headset is in compliance with Directive 2014/53/EU. The full text of the EU declaration of conformity is available at http://www.lg.com/global/support/cedoc/cedoc#...
-
Page 27: Additional Information
ZNFTONEFP9C (Charging case) Additional Information 1. Radio frequency exposure This Bluetooth LG Stereo Headset is a radio transmitter and receiver. When in operation, it communicates with a Bluetooth equipped mobile device by receiving and transmitting radio frequency (RF) electromagnetic fields (microwaves) in the frequency range 2402 to 2480 MHz. - Page 28 2. Bluetooth Connection Precautions The following environments affect the range and reception of Bluetooth signals: - When walls, metal, human bodies, or other obstacles exist between the Bluetooth device and the connected device. - When equipment that uses 2.4 GHz frequency signals (Wireless LANs, wireless phones, microwave ovens, etc.) is placed near the devices being used.
-
Page 29: Important Safety Information
5. Recycling the battery in your Bluetooth Headset The battery in your Bluetooth Headset must be disposed of properly and should never be placed in municipal waste. Important Safety Information Avoiding hearing damage Permanent hearing loss may occur if you use your headset at a high volume. Set the volume to a safe level. -
Page 30: Open Source Software Notice Information
In addition to the source code, all referred license terms, warranty disclaimers and copyright notices are available for download. LG Electronics will also provide open source code to you on CD-ROM for a charge covering the cost of performing such distribution (such as the cost of media, shipping, and handling) upon email request to opensource@lge.com. - Page 31 RISK GROUP 2 CAUTION : UV EMITTED FROM THIS PRODUCT. EYE OR SKIN IRRITATION MAY RESULT FROM EXPOSURE. USE APPROPRIATE SHIELDING. WARNING : IF YOU DON’T DO CHARGING OR IF YOU OPEN THE CHARGING CASE, THE UVNANO FUNCTION IS NOT ACTIVATED.
- Page 32 Symbols Refers to alternating current (AC). Refers to direct current (DC). Refers to class II equipment. Refers to stand-by. Refers to “ON” (power). Refers to dangerous voltage. The output level shall automatically return to an output level not exceeding RS1 when the power is switched off.
