Chapter 19. Network Configuration
1. Click the Devices tab.
2. Click the New button.
3. Select xDSL connection from the Device Type list, and click Forward.
4. If your Ethernet card is in the hardware list, select the Ethernet Device from the pulldown menu
from the page shown in Figure 19-8. Otherwise, the Select Ethernet Adapter window appears.
Note
The installation program detects supported Ethernet devices and prompts you to configure
them. If you configured any Ethernet devices during the installation, they are displayed in the
hardware list on the Hardware tab.
Figure 19-8. xDSL Settings
5. If the Select Ethernet Adapter window appears, select the manufacturer and model of the
Ethernet card. Select the device name. If this is the system's first Ethernet card, select eth0
as the device name; if this is the second Ethernet card, select eth1 (and so on). The Network
Administration Tool also allows you to configure the resources for the NIC. Click Forward to
continue.
6. Enter the Provider Name, Login Name, and Password. If you have a T-Online account, instead
of entering a Login Name and Password in the default window, click the T-Online Account
Setup button and enter the required information. Click Forward to continue.
7. On the Create DSL Connection page, click Apply.
After configuring the DSL connection, it appears in the device list as shown in Figure 19-7.
