Armytek Zippy User Manual

Thank you for choosing the products of Armytek Optoelectronics Inc., Canada.
Specification
Maximum light output 200 LED lumens
®
Unique optical system with 110° angle of light
®
Built-in Li-Pol battery and color indication of charge level
®
Robust, shockproof and water-resistant body
®
Simple operation with one button
®
Slim and lightweight: 59x25x9 mm / 12 g
®
Auto-memorization of last used mode
®
Lock function against accidental activation
®
Durable ring for keys and removable steel clip for attaching to a belt, backpack or pocket
®
Model
Maximum light output, LED / OTF lumens
Peak beam intensity, candelas
Hotspot : spill
Maximum beam distance, meters
Modes, light output (OTF lumens) and
runtimes (measured with 100mAh Li-Pol
until the light output drops to 10% of the
initial value)
Power source (built in)
Size and weight (without mounts)
Set description
Items included in the package: flashlight, steel clip, user manual.
The producer reserves the right to change the package at his own discretion without modifying this manual.
Operation
On / Off. Click the button once.
Cycling through the modes. Press and hold the button,
when the flashlight is on. Release the button to select the
mode. The flashlight remembers the last used mode.
Lock function. Press and hold the button for 3 seconds
when the flashlight is off. Repeat the action to unlock. When
you hold the button, the flashlight blinks once to confirm the
lock / unlock. To turn on the flashlight, click the button.
Warning indication of battery level. Low level - the
flashlight blinks once and begins to decrease in brightness
before turning off in the Maximum and Medium modes. When
cycling through the modes and the battery is low, the
flashlight will turn off after the third cycle.
Charging
Insert the cable into the Micro-USB connector and connect it
to the USB-A output of any battery charger with an output
voltage of 4.5 - 5.5V. Approximate charging time for a fully
discharged battery is 1 hour 10 minutes.
Indication of the charging process: Red color – the
charging is in progress. Green color – the charging is finished.
Service and Warranty
Armytek provides free warranty repair for 5 years (excluding batteries, chargers, switches and connectors,
which have a 2-year warranty) from the date of acquisition and if there is a document confirming the purchase.
Warranty doesn't cover damage caused by:
1. Improper usage.
2. Attempts to modify or repair the flashlight by nonqualified specialists.
3. Prolonged use in chlorinated or other polluted liquids.
4. High temperatures and chemicals (including the exposure of liquid from defected batteries).
Optional: original 360 ° headband widens the spheres of Zippy application.
Armytek Optoelectronics Inc.
13-85 West Wilmot St, Richmond Hill, Ontario, L4B 1K7, Canada
+1 (206) 785-9574
www.armytek.com | service@armytek.com
THE MOST TECHNICALL Y ADVANCED
Zippy
USER MANUAL
Please read this manual carefully before using the product.
Specifications are subject to change without notice.
English
Zippy
200 / 160
58
60° : 110°
15
High 160 lm / 17 min
Medium 50 lm / 1 h
Low 5 lm / 10 h
Li-Pol (100mAh)
59x25x9 mm / 12 g
Click once
Press and hold for 3 sec
On / Off
Lock function
Charging
Charging is
in progress
Charged
