LED World Bright Plus FA30M50-10M-24V Series Quick Start Manual

LED FLEX STRIP - Bright Plus
Model: FA30M50-10M-24V-X (X = COLOR
2.2
24V
WATTS
DC Power
FOOT
LISTED
use only with
Class 2 Type
power units
Please read instructions before using product and SAVE THESE INSTRUCTIONS. Before using this product make sure you have right color, product (item number)
and voltage (printed on product). Check for possibility of damage during shipping. If damaged, or wrong product, do not use. Disconnect power before installing
Use only with Class 2 Type power supply. Using with any other type of power supply will void the limited warranty.
Use only with Class 2 Type power supply.
Indoor use, Dry locations. Do not expose LED Flex Strip to moisture.
Disconnect power before installing or servicing (at breaker point).
This product is intended to be installed and serviced by a qualied licensed electrician. Install in accordance with the National Electric Code, and local regulations.
Only power with a (listed) constant voltage Class 2 power supply (24V DC).
Never plug into 120V AC. The product requires a optional class 2 Transformer.
Do not power when rolled. Lighting must be installed in a straight line. Do not curl or twist and roll out completely straight before applying power.
Ÿ
Only install on smooth at surfaces free of burrows that are re retardant.
Ÿ
Product has an adhesive tape on back. Adhesion can only be made once and the LED strip must fully adhere to surface (ush). Failure to do this step will
Ÿ
damage product. Rigidly support wires with wire clamps.
During installation, do not damage the printed circuit. Exposed wires can cause short circuit damaging product and creating a serious hazard. Do not mount in
Ÿ
a manner or support LED Strip light in a manner that can damage the outer jacket or cord insulation. Do not install this lighting system where the exposed bare
conductors can be shorted or contact any conductive materials. Carefully check that there is no wire cross-over or possibility in the future in area of installation.
To reduce the risk of re and overheating, make sure all connections are tight.
Ÿ
Product is sold in the maximum length. Do not exceed or extend the length of the roll.
Ÿ
Only qualied electrician or engineer can perform installation familiar with low voltage wiring techniques. Correct polarity is imperative (+/- is marked on printed
Ÿ
circuit). Parallel connection only.
DO NOT install on ammable material or possibility of in the future. Do not install any luminaire closer than 6 inches (15.25 cm) from any curtain, or similar
Ÿ
combustible materials.
The light and all its components cannot be mechanically pressed. Never apply to surface above 40c (104F).
Ÿ
Voltage must not exceed 24VDC and must be regulated. The Voltage is printed every 6 LEDS. Check that it is the correct voltage before applying power.
Ÿ
This is not a toy. Keep out of children's reach.
Ÿ
Keep Flex strip spaced ¾" apart if placing next to each other.
Ÿ
LED Flex Strip is bendable on one at widest plane. Maximum bend radius is 4 inches (100mm) on one plane (at).
Ÿ
Not for use in mission critical, aircraft, emergency signs or lifesaving equipment.
Ÿ
Static electricity can damage LED(s). Handle with care.
Ÿ
Inspect installation after one hour and thereafter regularly.
Ÿ
For stationary use only and not subjected to possible pressure or movement (or in the future).
Ÿ
Not for in-wall use.
Ÿ
Max. Soldering temperature cannot exceed 250°C (482°F) for a max of 4 seconds. Use 22~20 AWG wire to connect.
Ÿ
Use correct wiring as required by local electrical code. Use a 20 gauge wire to attach to strip by solder (2464 type of wire). Connection to power source may use
Ÿ
Wago™ 222-413 in hardwire applications.
Cable lighting systems not be installed in bathrooms.
Ÿ
Conductors of extra-low-voltage circuits be rigidly supported.
Ÿ
Conductors not be installed in contact with combustible materials and not run through walls, ceilings, oors or partitions, and; Uninsulated conductors not be
Ÿ
installed less than 2.2 m (86") from the oor.
Do not stare directly into the LED Light. Install LED lighting out of direct sight.
Ÿ
LED WORLD INC. warranties this product for one year (some exceptions may apply) from the date of shipping unless otherwise noted in writing. This warranty is expressly in lieu of all other
warranties expressed or implied. Under this Limited Warranty, the obligation of the company is limited to replacing on a prorated basis, at its option, any component found to be defective. This
Limited Warranty does not apply to damage caused by buyer or alteration to the product or incorrect power supply. Factory warrantees are covered by the original manufacturer and claims
must be submitted to them.
LED World Inc. And its providers will never be liable to you or any other person for any indirect, incidental, consequential, special, punitive or exemplary loss or damage arising from, connected
with, the purchase of products, including but not limited to loss of data, business, markets, cost of labour, savings, income, profits, use, production, reputation or goodwill, anticipated or
otherwise, or economic loss, under any theory of liability (whether in contract, tort, strict liability or any other theory or law or equity), regardless of any negligence or other fault or wrongdoing
(including without limitation gross negligence and fundamental breach) by led world inc. Or any person for whom led world inc. Is responsible, and even if led world inc. Has been advised of
the possibility of such loss or damage being incurred.
If a product is defective, we will replace the product with similar or identical product or at our option a credit towards a future purchase. To make a claim under this warranty, obtain a return
authorization number.
1/4
Copyright @2014 LED WORLD INC™. All Rights Reserved. We are not responsible for errors or omissions. Product and specications subject to change without notice. Registered trademarks are owned by their respective registers, or licensee(s).
W:Pure White / WW:Warm White)
IMPORTANT INSTRUCTIONS
Never Nail or use Staples
Only power with 24VDC
Class 2 Power Source
Safety & Warnings
TWO YEAR LIMITED LIGHTING WARRANTEE
LED World Inc. | #130 10615 48 ST SE | CALGARY, AB T2C 2B7 | CANADA | Version 1.2 - 09/25/2014
Never apply weights or walk on strips
KG
Apply to surface at room temperature. Keep
away from ammable materials. Surface
temperature MAX 40°C (104°F)
or using.
1-800-387-4081
