National Cycle Quantum VStream N20136 Installation Instructions

Thank you for purchasing a National Cycle product. Read these instructions carefully and thoroughly before beginning work. Dealers, if installing this
windshield for a customer, please give them this manual upon completion. It contains information needed to properly maintain and use this product.
WARNING:
Special notes and cautionary measures which can prevent
damage to the accessory or motorcycle.
CONTENTS OF KIT
ITEM DESCRIPTION
(1) VStream Windscreen
Figure 1
Figure 2
©2020 National Cycle, Inc.
QTY.
1
Figure 2
National Cycle, Inc. PO Box 158 Maywood, IL 60153-0158 USA
708-343-0400 / Fax 708-343-0625 / www.nationalcycle.com / info@nationalcycle.com
Quantum® Hardcoated Polycarbonate
VStream® Windscreen for:
Kawasaki® KLE1000 Versys
N20136, Low, Dark Tint
N20137, Mid, Light Tint
NOTE:
Tips for facilitation of operation, control and adjustment,
as well as maintenance work.
TOOLS REQUIRED
5mm Allen Wrench
INSTALLATION
Install the four OEM grommets (E) to the VStream Windscreen.
Install the Windscreen to the motorcycle using the OEM covers
and fasteners (A - D).
Tighten the four screws firmly, but do not overtighten.
(5mm Allen Wrench) Figure 3
Page 1 of 2
VStream® Windscreen Patent No. 7,387,328
ALL OEM FASTENERS
WILL BE REUSED.
PREPARATION
Position motorcycle securely on its
stand. Remove the OEM front covers
(A, B, C, D) and windscreen.
(5mm Allen Wrench) Figure 1
Remove the four grommets (E) from the
OEM windscreen. All OEM hardware
(A - E) will be reused.
Figure 2
10-110811-000 01/20
