Thank you for purchasing a National Cycle product. Read these instructions carefully and thoroughly before beginning work. Dealers, if installing this
windshield for a customer, please give them this manual upon completion. It contains information needed to properly maintain and use this product.
Description:
VStream® Replacement Windscreen
Part Number:
N20076/N20077/N20078
PACKAGE CONTENTS
ITEM PART NO.
DESCRIPTION
A
VStream Windscreen
ATTENTION: Special notes and cautionary measures
which can prevent damage to the accessory or vehicle.
Figure 1
National Cycle, Inc. PO Box 158 Maywood, IL 60153-0158 USA
©
2
0
2
2
N
t a
o i
n
l a
C
y
l c
, e
n I
. c
Quantum® Hardcoated Polycarbonate
VStream® Windscreen for Honda®
Transalp XL750
N20076
Dark Tint, Sport
N20077
Light Tint, Sport-Tour
N20078
Clear, Touring
Model:
Installation Time:
QTY.
1
OEM Hardware
TOOLS REQUIRED
5mm Hex Wrench
NOTE: Tips for facilitation of operation, control
and adjustment, as well as maintenance work.
NOTE: Illustrations shown are on the Transalp XL750
model. Installation procedures are for
the Transalp XL750 Standard model.
PREPARATION
Place motorcycle securely on its sidestand.
OEM WINDSCREEN REMOVAL
Figure 1
With a 5mm Hex Key, loosen – remove all four
Allen Screws holding the OEM Windscreen to the mount-
ing bracket.
All hardware will be reused.
.
P: 708-343-0400 / F: 708-343-0625 / E: info@nationalcycle.com
P
a
g
e
1
f o
3
VStream® Windscreen Patent No. 7,387,328
2024-Later Honda® Transalp XL750
15 min. Difficulty Level: Easy
www.nationalcycle.com
1
0
1 -
2
9
5
33
0 -
0
0
0
2/24
Advertisement
Related Manuals for National Cycle Quantum Vstream N20076
Summary of Contents for National Cycle Quantum Vstream N20076
- Page 1 VStream® Windscreen Patent No. 7,387,328 Thank you for purchasing a National Cycle product. Read these instructions carefully and thoroughly before beginning work. Dealers, if installing this windshield for a customer, please give them this manual upon completion. It contains information needed to properly maintain and use this product.
- Page 2 With a 5mm Hex Wrench, tighten all four Flanged Button- head Cap Screws (B) securely. Do not overtighten. Ride safe and enjoy your new VStream Windscreen! National Cycle, Inc. PO Box 158 Maywood, IL 60153-0158 USA P: 708-343-0400 / F: 708-343-0625 / E: info@nationalcycle.com www.nationalcycle.com ©...
- Page 3 National Cycle 3-Year Limited Warranty National Cycle hereby warrants to the original registered owner of a National Cycle polycarbonate windshield for a period of three years from the date of purchase against breakage. This limited warranty is expressly limited to the replacement of the polycarbonate windscreen.
