Thank you for purchasing a National Cycle product. Read these instructions carefully and thoroughly before beginning work. Dealers, if installing this
windshield for a customer, please give them this manual upon completion. It contains information needed to properly maintain and use this product.
VStream® Replacement Windscreen
Description:
and Side Deflectors
Part Number:
N20412/N20413/N20414/N20415
PARTS LIST
ITEM PART NO.
DESCRIPTION
A
VStream Windscreen; 2.0mm Polycarbonate
B
20-290936-000
Deflector; Left, 1.5mm Polycarbonate
C
20-290937-000
Deflector; Right, 1.5mm Polycarbonate
BAG#1387
D
49-490355-000
Spacer, Nylon, Black
E
49-495587-000
Spacer, Stainless Steel
F
51-516216-000
Cap Screw, M5x16, Zinc, Black
G
75-766188-000
Pad, Rubber Bumper Pair, 0.50" x 0.14"
H
77-770200-000
Alcohol Prep Wipe
Figure 1
Figure 2
National Cycle, Inc. PO Box 158 Maywood, IL 60153-0158 USA
©2022 National Cycle, Inc.
INSTALLATION INSTRUCTIONS
AND OWNERS MANUAL
VStream® Windscreens and Deflectors for
Harley-Davidson® Pan America Models
N20412 VStream, Low, Beaded Edge
N20413 VStream, Mid, Beaded Edge
N20414 VStream, Low
N20415 VStream, Mid
Model:
Installation Time:
QUANTITY
C
1
1
1
2
2
4
1
1
TOOLS REQUIRED
• T-25 Torx Wrench
• 3mm Allen Wrench
PREPARATION
Put the motorcycle securely on its centerstand before beginning.
INSTALLATION
Figure 1
Use a T-25 Torx Wrench to remove the four screws securing the
OEM windscreen to the motorcycle, and then remove the wind-
screen.
Figure 2
Use the same T-25 Torx Wrench to remove the four screws
securing the OEM deflectors to the motorcycle, and then
remove the deflectors.
P: 708-343-0400 / F: 708-343-0625 / E: info@nationalcycle.com
Page 1 of 4
2021-Later Harley-Davidson®
Pan America
20 min. Difficulty Level: Easy
Left and right
are determined
B
from the rider's
point of view
VStream® Windscreen
Patent No. 7,387,328.
Quantum® is a registered
trademark of National Cycle Inc.
MADE in U.S.A.
D
F
E
H
G
www.nationalcycle.com
10-118627-000 RevB 07/22
Advertisement
Subscribe to Our Youtube Channel
Related Manuals for National Cycle Vstream N20412
Summary of Contents for National Cycle Vstream N20412
- Page 1 N20415 VStream, Mid Thank you for purchasing a National Cycle product. Read these instructions carefully and thoroughly before beginning work. Dealers, if installing this windshield for a customer, please give them this manual upon completion. It contains information needed to properly maintain and use this product.
- Page 2 Figure 7 Rubber Bumpers should appear as shown. Figure 5 Figure 6 Figure 7 National Cycle, Inc. PO Box 158 Maywood, IL 60153-0158 USA P: 708-343-0400 / F: 708-343-0625 / E: info@nationalcycle.com www.nationalcycle.com ©2022 National Cycle, Inc. Page 2 of 4...
- Page 3 Ride safe and enjoy your new VStream® Windscreen and Deflectors! Figure 9 National Cycle, Inc. PO Box 158 Maywood, IL 60153-0158 USA P: 708-343-0400 / F: 708-343-0625 / E: info@nationalcycle.com www.nationalcycle.com ©2022 National Cycle, Inc.
- Page 4 National Cycle 3-Year Limited Warranty National Cycle hereby warrants to the original registered owner of a National Cycle polycarbonate windshield for a period of three years from the date of purchase against breakage. This limited warranty is expressly limited to the replacement of the polycarbonate windscreen. This limited warranty does...
