SPLIT-TYPE, HEAT PUMP AIR CONDITIONERS
TECHNICAL & SERVICE MANUAL
[Model name]
<Outdoor unit>
Refer to page 2.
Revision :
· PUMY-P100/125/140VHMBR3(-BS), PUMY-P100/125/140YHMBR3(-BS) have been added in REVISED
EDITION-D.
· Please void OCH446 REVISED EDITION-C.
NOTE :
· This service manual describes technical data of outdoor unit. As for indoor units, refer to its service manual.
· RoHS compliant products have <G> mark on spec name plate.
· For servicing of RoHS compliant products, refer to RoHS PARTS LIST.
Model name
indication
OUTDOOR UNIT
PUMY-P100YHMB
PUMY-P125YHMB
PUMY-P140YHMB
PUMY-P100YHMB-BS
PUMY-P125YHMB-BS
PUMY-P140YHMB-BS
CONTENTS
1. TECHNICAL CHANGE ...................................... 2
2. SAFETY PRECAUTION .................................... 3
3. OVERVIEW OF UNITS ...................................... 6
4. SPECIFICATIONS ............................................. 8
5. DATA ................................................................ 10
6. OUTLINES AND DIMENSIONS ...................... 26
7. WIRING DIAGRAM ......................................... 28
9. TROUBLESHOOTING .................................... 40
10. ELECTRICAL WIRING .................................... 86
11. REFRIGERANT PIPING TASKS ..................... 89
12. DISASSEMBLY PROCEDURE ....................... 93
PARTS CATALOG (OCB446)
May 2012
No. OCH446
REVISED EDITION-D
HFC
utilized
R410A
