NEW HOLLAND CR 920/940/960 COMBINES
Combine Initial Settings
Adjust front drum height to small grains position
as per combine operators manual.
Ensure feeder house output shaft speed is 575
rpm.
CR FEEDER HOUSE
Fully retract header tilt cylinder and lower header
until it slightly contacts the ground. At this point
adjust feeder faceplate angle to align pendulum
with rear face of adapter (if applicable).
Pendulum must line
up with rear face of
adapter frame.
Remove all feeder house dust shields, enclosure
panels, etc.
873 Adapter Initial Settings
Place adapter leg pin in proper hole for your
header model as follows:
•
963/972/973/974/84C headers in hole (B), (factory
set) with dust shields and hole (A) with dust
shields removed.
Place adapter down stop pin in proper hole for
your header model as follows:
•
973/974/84C headers in hole (2), (factory set).
•
963/972 headers in hole (3).
B
A
Form 147075
QUICK REFERENCE CARD
3
2
Rev. E (E27025)
If mounting adapter to a header, ensure down stop pads are
orientated properly (both sides).
•
963/972/973 header with dust shields removed and 973
with dust shields on, orientation is correct as shipped (D).
•
963/972 with dust shields on, orient pads to position (F).
•
974/84C headers, orient pads to position (E).
For 972/973/974/84C - Install skid plate on adapter feed
pan so dim. D = 4-11/32" (110 mm) in Hole B (dust
shields installed). For 963 - Slide transition plate forward
until feed pan bolts hit front of slot
For 972/973/974/84C - Install skid plate on adapter feed
pan so dim. D = 3-1/2" (90 mm) in Hole A (dust shields
removed). For 963 - Slide transition plate rearward until
feed pan bolts hit rear of slot.
•
Refer to 873 Operator's Manual for adjustment
details.
Adjust RTD position to achieve 1" to 2" dimension.
Note: To achieve this feed chain on combine may
need to be fully extended.
X
X = 225 mm (factory setting).
Set the center link between the header and adapter
to 19-1/4" (490 mm) length (pin to pin).
Set the float to specs given on pages 3 & 4.
Set the draper speed flow control so number "4" is
at the 12 o'clock position.
D
1" to 2"
(25 to 50 mm)
DRUM
FLOATED UP
