User Manual L400MA04T1A05
USER MANUAL L400MA04T1A05
SUBJECT INDEX:
DESCRIPTION
TECHNICAL SPECIFICATION
DEVICE POWER SUPPLY AND CONNECTION TO THE LED MODULE
OPERATION MODES
LINEAR POTENTIOMETER MODE 100KOHM
MODE 0-10V/1-10V (NOT ISOLATED) PASSIVE
PUSH MODE
DALI MODE
PARAMETERS CONFIGURATION
1
NEWLAB - User Manual L400MA04T1A05
Advertisement
Related Manuals for Newlab L400MA04T1A05
Summary of Contents for Newlab L400MA04T1A05
- Page 1 User Manual L400MA04T1A05 USER MANUAL L400MA04T1A05 SUBJECT INDEX: DESCRIPTION TECHNICAL SPECIFICATION DEVICE POWER SUPPLY AND CONNECTION TO THE LED MODULE OPERATION MODES LINEAR POTENTIOMETER MODE 100KOHM MODE 0-10V/1-10V (NOT ISOLATED) PASSIVE PUSH MODE DALI MODE PARAMETERS CONFIGURATION NEWLAB - User Manual L400MA04T1A05...
- Page 2 - Over temperature protection. - To supply the device you have to use a SELV power supply in order to maintain the required elettrical security level. All connections must be made with non-live devices and carried out by NEWLAB - User Manual L400MA04T1A05...
- Page 3 - If the control voltage of the PUSH input is higher than the SELV voltage it is necessary to use the OPTIONAL terminal / cable cover to keep the product in CLASS II. - Use only in dry conditions. NEWLAB - User Manual L400MA04T1A05...
- Page 4 MAX OUTPUT CONTROL CASE DIMENSION VOLTAGE CURRENT CHANNELS POWER INPUTS L400MA04T1A05 8-53V DC 432W at 48V DC Insulated Push button x1 40x80 DALI x1 h 24.45 Linear Potentiometer 100K x1 0-10V Passive x1 1-10V Passive x1 NEWLAB - User Manual L400MA04T1A05...
- Page 5 DEVICE POWER SUPPLY AND CONNECTION TO THE LED MODULE POWER SUPPLY CONNECTION DIAGRAM AND LED L400MA04T1A05 - FIGURE N. 1 The L400MA04T1A05 dimmer has to be powered according to the polarity showed in FIG. 1 through the DC IN (+ and -) terminals.
- Page 6 OPERATION MODES LINEAR POTENTIOMETER MODE 100KOHM POTENTIOMETER WIRING L400MA04T1A05 - FIGURE N. 2 In order to activate this mode of control/operation just connect a linear potentiometer of 100 Kohm between the D+ and D- inputs and disconnect the remaining inputs.
- Page 7 User Manual L400MA04T1A05 MODE 0-10V/1-10V (NOT ISOLATED) PASSIVE WIRING 0-10V L400MA04T1A05 - FIGURE N. 3 In order to activate this mode of control/operation just connect the active control signal of 0-10V/1-10V between the D+ and D- inputs (being careful to observe the correct polarity) and disconnect the remaining control signals.
- Page 8 User Manual L400MA04T1A05 PUSH MODE WIRING BUTTON L400MA04T1A05 - FIGURE N. 4 In order to activate this mode of control/operation it is necessary to remove any control signals from the D + and D- inputs and connect between the DALI/P1 and DALI/P2 inputs, a signal in direct or alternating voltage (DC voltage range:10÷265V, AC 12÷265Vac 50÷65Hz) interrupted by a normally open button (N.O.).
- Page 9 User Manual L400MA04T1A05 DALI MODE DALI L400MA04T1A05 WIRING - FIGURE N. 5 In order to activate this mode of control/operation it is necessary to shortcircuit the D+ and D- inputs and connect the DALI bus between the DALI/P1 and DALI/P2 inputs.
- Page 10 QUERY POWER ON LEVEL QUERY SYSTEM FAILURE LEVEL QUERY FADE TIME/FADE RATE QUERY SCENE LEVEL (0-15) QUERY GROUPS (0-7) QUERY GROUPS (8-15) QUERY RANDOM ADDRESS H QUERY RANDOM ADDRESS M QUERY RANDOM ADDRESS L Manual update 18/10/2018 NEWLAB - User Manual L400MA04T1A05...
- Page 11 OFF OFF OFF OFF OFF OFF OFF OFF OFF OFF Fade Configuration Fade Off OFF OFF OFF OFF OFF OFF OFF OFF OFF OFF OFF OFF Fade On OFF OFF OFF OFF OFF OFF OFF OFF OFF OFF OFF NEWLAB - User Manual L400MA04T1A05...
