Page 1
SUBJECT INDEX: DESCRIPTION TECHNICAL SPECIFICATION DEVICE POWER SUPPLY AND CONNECTION TO THE LED MODULE OPERATION MODES LINEAR POTENTIOMETER MODE 100KOHM MODE 0-10V/1-10V (NOT ISOLATED) PASSIVE PUSH MODE DALI MODE BLUETOOTH MODE + PUSH PARAMETERS CONFIGURATION NEWLAB - User Manual L400MD04C1A01...
Page 2
Input Range: 8-53V DC. Output Current PWM with current from 0.17A to 1.05A (54.6W at 52V DC). Controllable with Android/iOS app Newlab Go. In order to set the output current you will need the L392MA00N0A01 interface sold separately. Default current 0.35A.
Page 3
User Manual L400MD04C1A01 - Use only in dry conditions. NEWLAB - User Manual L400MD04C1A01...
Page 4
POWER INPUTS L400MD04C1A01 8-53V DC from 0.17A 54.6W at 52V DC Insulated Push button x1 40x80 to 1.05A DALI x1 h 24.45 Linear Potentiometer 100K x1 0-10V Passive x1 1-10V Passive x1 Bluetooth LE x1 NEWLAB - User Manual L400MD04C1A01...
Page 5
DEVICE POWER SUPPLY AND CONNECTION TO THE LED MODULE POWER SUPPLY CONNECTION DIAGRAM AND LED L400MD04C1A01 - FIGURE N. 1 The L400MD04C1A01 dimmer has to be powered according to the polarity showed in FIG. 1 through the DC IN (+ and -) terminals.
OPERATION MODES LINEAR POTENTIOMETER MODE 100KOHM POTENTIOMETER WIRING L400MD04C1A01 - FIGURE N. 2 In order to activate this mode of control/operation just connect a linear potentiometer of 100 Kohm between the D+ and D- inputs and disconnect the remaining inputs.
Page 7
User Manual L400MD04C1A01 MODE 0-10V/1-10V (NOT ISOLATED) PASSIVE WIRING 0-10V L400MD04C1A01 - FIGURE N. 3 In order to activate this mode of control/operation just connect the active control signal of 0-10V/1-10V between the D+ and D- inputs (being careful to observe the correct polarity) and disconnect the remaining control signals.
User Manual L400MD04C1A01 PUSH MODE WIRING BUTTON L400MD04C1A01 - FIGURE N. 4 In order to activate this mode of control/operation it is necessary to remove any control signals from the D + and D- inputs and connect between the DALI/P1 and DALI/P2 inputs, a signal in direct or alternating voltage (DC voltage range:10÷265V, AC 12÷265Vac 50÷65Hz) interrupted by a normally open button (N.O.).
Page 9
User Manual L400MD04C1A01 DALI MODE DALI L400MD04C1A01 WIRING - FIGURE N. 5 In order to activate this mode of control/operation it is necessary to shortcircuit the D+ and D- inputs and connect the DALI bus between the DALI/P1 and DALI/P2 inputs.
Page 10
QUERY MIN LEVEL QUERY POWER ON LEVEL QUERY SYSTEM FAILURE LEVEL QUERY FADE TIME/FADE RATE QUERY SCENE LEVEL (0-15) QUERY GROUPS (0-7) QUERY GROUPS (8-15) QUERY RANDOM ADDRESS H QUERY RANDOM ADDRESS M QUERY RANDOM ADDRESS L NEWLAB - User Manual L400MD04C1A01...
Page 11
BLE L400MD04C1A01 WIRING - FIGURE N. 6 In order to activate this mode of control/operation it is necessary to install the Newlab Go App on the Android or iOS device that you want to use for the L400MD04C1A01 dimmer control and disconnect any 0-10V (1-10V) inputs or potentiometer connected to the dimmer.
Page 12
In order to install the app on your Apple or Android device you need to scan the desired QRCode to be automatically redirected to the product data sheet of the Newlab Go application. As an alternative you can download the app by clicking on one of two links below: Apple: https://itunes.apple.com/it/app/newlab-go/id1151044984?mt=8...
OFF OFF OFF OFF OFF OFF OFF 480 mA OFF OFF OFF OFF OFF OFF OFF 490 mA OFF OFF OFF OFF OFF OFF OFF OFF OFF OFF 500 mA OFF OFF OFF OFF OFF OFF OFF OFF OFF NEWLAB - User Manual L400MD04C1A01...
Page 14
OFF OFF OFF OFF OFF OFF 975 mA OFF OFF OFF OFF OFF OFF OFF OFF 990 mA OFF OFF OFF OFF OFF OFF 1020 mA OFF OFF OFF OFF OFF OFF 1050 mA OFF OFF OFF OFF OFF OFF NEWLAB - User Manual L400MD04C1A01...
