SERVICE MANUAL

Level 1&2

RM-576 / RM-577

Transceiver characteristics

Band:

RM-576:

• WCDMA 900/1900/2100 (VIII, II, I)

• GSM 850/900/1800/1900

RM-577:

• WCDMA 850/1900/2100 (V, II, I)

• GSM 850/900/1800/1900

Display:

320 x 240 QVGA 2.2" 16M colors TFT

Camera:

Main camera: 5 megapixels (2592 x 1944) 3x digital zoom

Secondary camera: 320 x 240

Operating System:

S60 3rd Edition Feature Pack 2 (S60 3.2.3) Symbian OS 9.3

Connections:

• Bluetooth 2.0 EDR, A2DP

• 2.5 mm AV connector

• High-Speed 2.0 Micro-USB connector

• Micro SD card (2 GB in sales package)

• WLAN is not supported

Transceiver with BL-4C battery pack

Talk time

GSM:

Up to 4 hours

WCDMA:

Up to 3 hours

Note:

Talk times are dependant on network parameters and

phone settings

Nokia 6700 Slide

RM-576 / RM-577

Service Manual Level 1&2

Standby

GSM:

Up to 300 hours

WCDMA:

Up to 250 hours

Version 1.0

Need help?

Do you have a question about the RM-577 and is the answer not in the manual?

Questions and answers

Summary of Contents for Nokia RM-577

Page 1 Up to 4 hours Up to 300 hours WCDMA: WCDMA: Up to 3 hours Up to 250 hours Note: Talk times are dependant on network parameters and phone settings Confidential | Copyright © 2010 Nokia | All rights reserved Version 1.0...
Page 2 6. Battery information ..................................8 7. Exploded view ....................................9 8. Service devices .....................................10 9. Software update ..................................11 10. Disassembly instructions ..............................12 11. Assembly Hints ..................................21 12. Solder components ................................25 Confidential | Copyright © 2010 Nokia | All rights reserved Version 1.0...
Page 3 12.1.2010 First approved version The purpose of this document is to help Nokia service levels 1 and 2 workshop technicians to carry out service to Nokia products. This Service Manual is to be used only by authorized Nokia service suppliers, and the content of it is confidential. Please note that Nokia provides also other guidance documents (e.g.
Page 4 Nokia operates a policy of continuous development. Nokia reserves the right to make changes and improvements to any of the products described in this document without prior notice. Under no circumstances shall Nokia be responsible for any loss of data or income or any special, incidental, consequential or indirect damages howsoever caused.
Page 5 3. Use only approved components as specified in the parts list. 4. Ensure all components, modules screws and insulators are correctly re–fitted after servicing and alignment. 5. Ensure all cables and wires are repositioned correctly Confidential | Copyright © 2010 Nokia | All rights reserved Version 1.0...
Page 6 RM-576 / RM-577 Service Manual Level 1&2 4. ESD PROTECTION Nokia requires that service points have sufficient ESD protection (against static electricity) when servicing the phone. Any product of which the covers are removed must be handled with ESD protection. The SIM card can be replaced without ESD protection if the product is otherwise ready for use.
Page 8 Batteries’ performance is particularly limited in temperatures well below freezing. Do not dispose batteries in a fire! Dispose of batteries according to local regulations (e.g. recycling). Do not dispose as household waste. Confidential | Copyright © 2010 Nokia | All rights reserved Version 1.0...
Page 9 I0207 I0213 ANTENNA COVER I0217 SCREW M1.4X3.4 TORX+ 4 BATTERY COVER ASSEMBLY I0218 I0219 Only available as These parts can not be Ver. 1.0 assembly reused after removal Confidential | Copyright © 2010 Nokia | All rights reserved Version 1.0...
Page 10 Service Bulletin (SB-011) on Nokia Online. Supplier or manufacturer contacts for tool re-order can be found in “Recommended service equipment” document on Nokia Online. AC-8 Travel Charger SS-217 Jig alignment tool Confidential | Copyright © 2010 Nokia | All rights reserved Version 1.0...
Page 11 Flash concept – Point of Sale (POS) To use the FLS-5 Flash Dongle, follow the user guide inside the sales package. Please check always for the latest version of flash software available on Nokia Online (NOL). Confidential | Copyright © 2010 Nokia | All rights reserved...
Page 12 5) Remove the BATTERY COVER. If there is a BATTERY 6) Slide the phone open. Detach the three shown inserted, remove it also. clips holding the MAIN KEYMAT ASSEMBLY by sliding the SRT-6 in the direction shown. Confidential | Copyright © 2010 Nokia | All rights reserved Version 1.0...
Page 13 4 screws in the order shown. 11) Detach the two clips holding the engine board 12) Close the slide. Lift up and separate the D-COVER with the SS-93. ASSY. Confidential | Copyright © 2010 Nokia | All rights reserved Version 1.0...
Page 14 15) Use the AV plug to lift up the AV CONNECTOR. 16) Remove the AV CONNECTOR with the tweezers. 17) Use the SS-93 to release the ANTENNA MODULE 18) Remove the ANTENNA MODULE ASSY. ASSY. Confidential | Copyright © 2010 Nokia | All rights reserved Version 1.0...
Page 15 23) Lift up the engine board and remove the SLIDE 24) Use the camera removal tool SS-210 version 2 to MODULE ASSY. remove the camera. Press down the SS-210 until the camera retaining clips are released. Confidential | Copyright © 2010 Nokia | All rights reserved Version 1.0...
Page 16 29) First release the clips on both sides with the 30) Then release the clips at the bottom end. sharp end of the SS-93. Confidential | Copyright © 2010 Nokia | All rights reserved Version 1.0...
Page 17 35) Unscrew the two TORX+ size 4 screws in the 36) Carefully move the UI KEYMAT SUPPORT order shown. Do not use them again. Discard them. ASSEMBLY to the direction shown. Confidential | Copyright © 2010 Nokia | All rights reserved Version 1.0...
Page 18 LCD. be careful not to damage the connector. 41) Then carefully remove the LCD. 42) Turn over the device and release the MAIN FLEX ASSEMBLY. Confidential | Copyright © 2010 Nokia | All rights reserved Version 1.0...
Page 19 MAIN FLEX ASSEMBLY on the top side. 47) Remove the main flex from the UI KEYMAT 48) The UI flex cannot be used again. Discard it. SUPPORT ASSEMBLY with the SS-93. Confidential | Copyright © 2010 Nokia | All rights reserved Version 1.0...
Page 20 Nokia 6700 Slide RM-576 / RM-577 Service Manual Level 1&2 49) Nokia 6700 slide disassembly procedure is now complete. - End of disassembly - Confidential | Copyright © 2010 Nokia | All rights reserved Version 1.0...
Page 21 14 Ncm in the order shown. torque of 14 Ncm in the order shown. 5) Tighten the four TORX+ size 4 screws to the torque of 14 Ncm in the order shown. Confidential | Copyright © 2010 Nokia | All rights reserved Version 1.0...
Page 22 3) Remove the UI KEYMAT protective tape. 4) Remove the microphone gasket protective tape 5) Use the guiding pins of the SS-217 to align the UI from the UI KEYMAT SUPPORT. KEYMAT SUPPORT correctly. Confidential | Copyright © 2010 Nokia | All rights reserved Version 1.0...
Page 23 MAIN FLEX ASSEMBLY with the SS- 2) Connect the LCD connector to the MAIN FLEX 3) Turn over the LCD. ASSEMBLY. Close the locking mechanism with the SS-93. Confidential | Copyright © 2010 Nokia | All rights reserved Version 1.0...
Page 24 LCD flex is correctly positioned. bended. Place the UI KEYMAT SUPPORT on it's place so that the LCD flex folds nicely underneath it Confidential | Copyright © 2010 Nokia | All rights reserved Version 1.0...
Page 25 RM-576 / RM-577 Service Manual Level 1&2 12. SOLDER COMPONENTS X1500 X2402 X2400 X7402 X7401 F2000 F3300 X7403 X2403 X2401 G2200 S2412 X6199 BOTTOM V2400 V2401 Ver. 1.0 Confidential | Copyright © 2010 Nokia | All rights reserved Version 1.0...
