Siemens UVRPA12DC Installation Instructions

s
Undervoltage Release
Bobina de mínima tensión
Déclencheur mini de tension
Installation Instructions / Instructivo de Instalación
Hazardous Voltage. Hazardous Voltage.
Will cause death or serious injury. Will cause death or serious injury.
Turn off and lock out all power supplying this device before Turn off and lock out all power supplying this device before
working on this device. working on this device.
Replace all covers before power supplying this device is Replace all covers before power supplying this device is
turned on. turned on.
Use only with Siemens certified Components.
Utilizar únicamente con componentes certificados de Siemens.
A utiliser uniquement avec les composants certifiés Siemens.
NOTE - These instructions do not purport to cover all details or variations in
equipment, or to provide for every possible contingency to be met in
connection with installation, operation or maintenance. Should further
information be desired or should particular problems arise, which are not
covered sufficiently for the purchaser's purposes, the matter should be
referred to the local Siemens sales office. The contents of this instruction
manual shall not become part of or modify any prior or existing agreement,
commitment or relationship. The sales contract contains the entire obligation
of Siemens. The warranty contained in the contract between the parties is the
sole warranty of Siemens. Any statements contained herein do not create new
warranties or modify the existing warranty.
Trademarks - Unless otherwise noted, all names identified by ® are registered
trademarks of Siemens AG or Siemens Industry, Inc. The remaining
trademarks in this publication may be trademarks whose use by third parties
for their own purposes could violate the rights of the owner.
8 0 6 8 2 4 A 0 2
Item: UVRPA12DC
Tensión peligrosa. Tensión peligrosa.
Puede causar la muerte o lesiones graves. Puede causar la muerte o lesiones graves.
Desenergice totalmente antes de instalar o darle servicio. Desenergice totalmente antes de instalar o darle servicio.
Reemplace todas las barreras y cubiertas antes de Reemplace todas las barreras y cubiertas antes de
energizar el interruptor. energizar el interruptor.
s
Disp. de Min. Tensión
Cat No: UVRPR240
220-250V 50/60Hz
1.3VA
MLFB: 3VL9800-1SR00
U.S. Cat. No. Euro Order No.
3VL9800-1UN01
3VL9800-1UP01
UVRPB24DC
3VL9800-1UU01
UVRPC48DC
3VL9800-1UV01
UVRPG60DC
3VL9800-1UR01
UVRPD125DC
3VL9800-1US01
UVRPE250DC
Para Usar Con Caja Base MG, NG, PG
Tension dangereuse. Tension dangereuse.
Danger de mort ou risque de blessures graves. Danger de mort ou risque de blessures graves.
Couper l'alimentation de l'appareil et barrer avant de Couper l'alimentation de l'appareil et barrer avant de
travailler. travailler.
Remplacez touts les couverts avant que Remplacez touts les couverts avant que
l'approvisionnement de pouvoir soit alimenté. l'approvisionnement de pouvoir soit alimenté.
UVRPA12DC 3VL9800-1UN01 = 12V
UVRPB24DC 3VL9800-1UP01 = 24V
UVRPC48DC
3VL9800-1UU01 = 48V
UVRPG60DC 3VL9800-1UV01 = 60V
UVRPD125DC 3VL9800-1UR01 = 110-127V
UVRPE250DC
3VL9800-1US01 = 220-250V
UVRPN120
3VL9800-1UG01= 110-127V
UVRPR240
3VL9800-1UH01 = 220-250V
UVRPP208
3VL9800-1UM01 = 208V
UVRPS277
3VL9800-1UQ01 = 277V
UVRPT415
3VL9800-1UJ01 = 380-415V
UVRPU480
3VL9800-1UK01 = 440-480V
1 / 4
Euro Order No.
U.S. Cat. No.
3VL9800-1UG01
UVRPN120
3VL9800-1UH01
UVRPR240
3VL9800-1UM01
UVRPP208
3VL9800-1UQ01
UVRPS277
3VL9800-1UJ01
UVRPT415
3VL9800-1UK01
UVRPU480
For Use With Frame MG, NG, PG
Cal. ISO 6789
V
V
50 / 60 HZ
I.L. No. 806824A02
~
