Medium-Voltage Switchgear
Air-Insulated Switchgear NXAIR M
24 kV / 25 kA / ≤ 2500 A Busbar Current
© Siemens AG 2018 All rights reserved.
INSTALLATION INSTRUCTIONS
Order No.:
Issue:
Revision:
139-2019.9
September 2018
07
