Eclipse Security ECL-DVR32 Series User Manual

Hide thumbs
Table of Contents

Advertisement

Quick Links

Download this manual
ECL-DVR32 User's Manual
Our Units Do Not Suppord PAL
V1.3.0

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the ECL-DVR32 Series and is the answer not in the manual?

Questions and answers

Related Manuals for Eclipse Security ECL-DVR32 Series

Summary of Contents for Eclipse Security ECL-DVR32 Series

  • Page 1 ECL-DVR32 User’s Manual Our Units Do Not Suppord PAL V1.3.0...

  • Page 2: Table Of Contents

    Overview ..........................1 Features ..........................1 Specifications ........................2 1.3.1 2 HDDs 1.5U Series ...................... 2 1.3.2 4 HDDs 1.5U Series ...................... 6 ECL-DVR32 Series 1.3.3 ..................10 OVERVIEW AND CONTROLS ............... 15 Front Panel ........................15 2.1.1 1.5U Series ........................15 ECL-DVR32 Series 2.1.2...
  • Page 3 INSTALLATION AND CONNECTIONS ..........31 Check Unpacked DVR ..................... 31 About Front Panel and Rear Panel ................. 31 3.2.1 HDD Installation ......................31 3.2.2 Rack Installation ......................33 Connecting Power Supply ....................33 Connecting Video Input and Output Devices ..............33 3.4.1 Connecting Video Input ....................
  • Page 4 Startup Wizard ........................41 Manual Record ......................... 44 4.3.1 Live Viewing ......................... 44 Right-Click Menu ......................46 4.4.1 Window Switch ......................46 4.4.2 PIP ..........................47 4.4.3 PTZ Control ........................48 4.4.4 Auto Focus ........................54 4.4.5 Color ..........................54 4.4.6 Search ..........................
  • Page 5 4.8.1 Search .......................... 62 4.8.2 Backup .......................... 69 4.8.3 Shut Down ........................72 Information ........................72 4.9.1 System Info ........................72 4.9.2 Event..........................76 4.9.3 Network ........................76 4.9.4 Log ..........................79 4.10 Setting ..........................81 4.10.1 Camera ........................81 4.10.2 Network ........................
  • Page 6 5.8.1 Camera ........................169 5.8.2 Network ........................177 5.8.3 Event........................... 192 5.8.4 Storage ........................202 5.8.5 Setting ........................207 Information ........................223 5.9.1 Version ........................223 5.9.2 Log ..........................223 5.9.3 Connection Log ......................224 5.9.4 Online User ........................ 225 5.10 Playback .........................
  • Page 7 Appendix B-4 Compatible USB DVD List ................242 Appendix B-5 Compatible SATA DVD List ................242 Appendix B-6 Compatible SATA HDD List ................243 APPENDIX C COMPATIBLE CD/DVD BURNER LIST ......247 APPENDIX D COMPATIBLE DISPLAYER LIST ........248 APPENDIX E COMPATIBLE SWITCHER ........... 249 APPENDIX F COMPATIBLE WIRELESS MOUSE LIST ......
  • Page 8 Welcome Thank you for purchasing our DVR! This user’s manual is designed to be a reference tool for the installation and operation of your system. Here you can find information about this series hybrid standalone DVR features and functions. Before installation and operation please read the following safeguards and warnings carefully!

  • Page 9: Important Safeguards And Warnings

    Important Safeguards and Warnings 1．Electrical safety All installation and operation here should conform to your local electrical safety codes. The product must be grounded to reduce the risk of electric shock. We assume no liability or responsibility for all the fires or electric shock caused by improper handling or installation.

  • Page 10: Features And Specifications

    FEATURES AND SPECIFICATIONS 1.1 Overview The hybrid standalone series DVR is an excellent digital monitor product designed for security field. It adopts embedded Linux OS to maintain reliable operation. Popular H.264 compression algorithm and G.711 audio compression technology realize high quality, low bit stream. Unique frame by frame play function is suitable for detailed analysis.

  • Page 11: Specifications

    Client-end user can download the file to local HDD to backup via network. Support eSATA, SATA port backup (eSATA port can connect to burner or HDD, SATA port can connect to burner.)  Record & playback function Support each channel real-time record independently, and at the same time it can support search, forward play, network monitor, record search, download and etc.
  • Page 12 High-performance industrial embedded micro controller Main Processor System Embedded LINUX System Multiplex operations: Multiple-channel record, multiple-channel Resources playback and network operation simultaneously Interface User-friendly graphical user interface Input Devices Front panel, USB mouse, remote control Arabic number, English character, donation and extension Chinese Input Method (optional) Shortcut...
  • Page 13 Image Quality 6-level image quality (Adjustable) Privacy mask Support one privacy mask of user-defined size in full screen. Support max 4 zones. Image Channel information, time information and privacy mask zone. Information TV Adjust Adjust TV output zone suitable to anamorphic video. Channel Lock Cover secret channel with blue screen though system is encoding normally.
  • Page 14 Multi-channel Support 1/4/9/16-channel modes (It may vary due to different series.) Playback Window Switch between self-adaptive screen/full screen when playback Zoom Partial When in one-window full-screen playback mode, you can select any Enlargement zone to activate partial enlargement function. Backup HDD backup function Support peripheral USB backup device.

  • Page 15: Hdds 1.5U Series

    System Hard Disk Display HDD current status Information Information Data Stream Data stream statistics for each channel (in wave mode) Statistics Backup to 1024 log files. Log statistics Support various search engines such as time and type. Display version information: channel amount, alarm input and output Version amount, system version and release date.
  • Page 16 System Embedded LINUX System Multiplex operations: Multiple-channel record, multiple-channel Resources playback and network operation simultaneously Interface User-friendly graphical user interface Input Devices Front panel, USB mouse, remote control Arabic number, English character, donation and extension Chinese Input Method (optional) Shortcut Copy/paste operation, USB mouse right-key shortcut menu, double Function click USB mouse to switch screen.
  • Page 17 Privacy mask Support one privacy mask of user-defined size in full screen. Support max 4 zones. Image Channel information, time information and privacy mask zone. Information TV Adjust Adjust TV output zone suitable to anamorphic video. Channel Lock Cover secret channel with blue screen though system is encoding normally.
  • Page 18 Window Switch between self-adaptive screen/full screen when playback Zoom Partial When in one-window full-screen playback mode, you can select any Enlargement zone to activate partial enlargement function. Backup HDD backup function Support peripheral USB backup device. (Flash disk, portable disk, Backup Mode USB burner and etc.) Support external eSATA device backup...

  • Page 19: Ecl-Dvr32 Series

    -10℃－＋55℃ Temperature Working 10%－90% Humidity Air Pressure 86kpa－106kpa Dimension 1.5U standard industrial case. 440(W) x410(D) x70(H)mm Weight 4.5－5.5KG (Exclude HDD) Installation Desktop/Rack installation Mode ECL-DVR32 Series 1.3.3 32-ch Series Parameter Main High-performance industrial embedded micro controller System Processor Embedded LINUX...
  • Page 20 System Multiplex operations: Multiple-channel record, multiple-channel Resources playback and network operation simultaneously Interface User-friendly graphical user interface Input Devices Front panel, USB mouse, remote control Arabic number, English character, donation and extension Chinese Input Method (optional) Shortcut Copy/paste operation, USB mouse right-key shortcut menu, double Function click USB mouse to switch screen.
  • Page 21 Privacy mask Support one privacy mask of user-defined size in full screen. Support max 4 zones. Image Channel information, time information and privacy mask zone. Information TV Adjust Adjust TV output zone suitable to anamorphic video. Channel Lock Cover secret channel with black screen though system is encoding normally.
  • Page 22 function Support peripheral USB backup device. (Flash disk, portable disk, USB burner and etc.) Support peripheral eSATA backup device. Support network download and save View monitor channel remotely. DVR configuration through client-end and web browser Upgrade via client or browser to realize remote maintenance. Network View alarm information such as external alarm, motion detection and Function...
  • Page 23 On-line user Display current on-line user User Multi-lever user management; various management modes Management Integrated management for local user, serial port user and network User user. Configurable user power. Management Support user /group and its corresponding rights modification. No limit to the user or group amount. Password modification Administrator can modify other user’s password.

  • Page 24: Overview And Controls

    2 Overview and Controls This section provides information about front panel and rear panel. When you install this series DVR for the first time, please refer to this part first. 2.1 Front Panel 2.1.1 1.5U Series The front panel is shown as in Figure 2-1. Figure 2-1 Please refer to the following sheet for front panel button information.

  • Page 25: Ecl-Dvr32 Series

    Record light 1-16 System is recording or not. It becomes on when system is recording. ECL-DVR32 Series 2.1.2 This series products’ front panel is shown as below. See Figure 2-2.
  • Page 26 Figure 2-2 Please refer to the following sheet for front panel button information. Name Icon Function Power button, press this button for three seconds to boot up or Power button shut down DVR. Input Arabic number Number button Switch channel Input number If you want to input a number more than 10, please click this...
  • Page 27 Go to previous menu, or cancel current operation. When playback, click it to restore real-time monitor mode. Confirm current operation Enter ENTER Go to default button Go to menu One-window monitor mode, click this button to display assistant function: PTZ control and image color. Backspace function: in numeral control or text control, press it for 1.5 seconds to delete the previous character before the cursor.

  • Page 28: Rear Panel

    Status indication Status The light is on if device operates properly. light Power indication Power indication light light IR Receiver It is to receive the signal from the remote control. 2.2 Rear Panel 2.2.1 2 HDDs 1.5U Series This series products’ rear panel is shown as below. See Figure 2-3. The following figure is based on the 32-channel series product.
  • Page 29  When your alarm input device using external power, please make sure the device and the NVR have the same ground.  NO1～NO5 Alarm output port 5 groups of alarm output 1～5 ports. (Group 1：port NO1～ NO2 ～ C1,Group 2:port C2,Group 3:port NO3 ～...

  • Page 30: Hdds 1.5U Series

    to the monitor to view analog video. USB2.0 port Connect to mouse, USB storage media, USB-burner and etc. SPOT OUT Video matrix SPOT output. Support 1-window output port standard definition matrix output. HDMI1 High definition High definition audio and video media interface signal output port.
  • Page 31 VIDEO IN VIDEO IN Video input port AUDIO IN Audio input port Connect to microphone and etc to input audio signal. AUDIO OUT Audio output port Connect to sound box and etc to output audio signal. eSATA eSATA port External SATA port.

  • Page 32: Ecl-Dvr32 Series

    Video output port Connect to output devices such as TV. SPOT OUT Video matrix output SPOT output. Support 1-window port standard definition matrix output. ECL-DVR32 Series 2.2.3 The 32-channel series DVR rear panel is shown as below. See Figure 2-5.
  • Page 33 Figure 2-5 Please refer to the following sheet for detailed information. Icon Name Function Ground port Power switch Power on/off button. VIDEO IN VIDEO IN Video input port VIDEO OUT Video output port Connect to output devices such as TV. Power Power socket AUDIO OUT...
  • Page 34 USB2.0 port Connect to mouse, USB storage media, USB-burner and etc. High definition HDMI1 High definition audio and video media interface signal output port. It transmits the same video signal VGA/TV. Support mouse operation. HDMI2 HD video matrix output. Support zero-channel encoding matrix output.

  • Page 35: Connection Sample

    When connect the Ethernet port, please use crossover cable to connect the PC and use the straight cable to connect to the switch or router. 2.3 Connection Sample Please refer to the following figure for detailed information. See Figure 2-6. The ECL-DVR32 Series following interface is based on the 32-channel product. Figure 2-6...

  • Page 36: Remote Control

    2.4 Remote Control The remote control interface is shown as in Figure 2-7. Please note remote control is not our standard accessory and it is not included in the accessory bag. Figure 2-7 Serial Number Name Function Power button Click it to boot up or shut down the device.
  • Page 37 In normal playback click this button to pause playback. In real-time monitor mode, click this button to enter video search menu. Reverse/pause Reverse playback pause mode, click this button to realize normal playback. In reverse playback click this button to pause playback. Esc.

  • Page 38: Mouse Control

    2.5 Mouse Control Left click System pops up password input dialogue box if you have not logged in. mouse In real-time monitor mode, you can go to the main menu. When you have selected one menu item, left click mouse to view menu content.

  • Page 39: Virtual Keyboard & Front Panel

    Right click In real-time monitor mode, pops up shortcut menu: one-window, mouse four-window, nine-window and sixteen-window, Pan/Tilt/Zoom, color setting, search, record, alarm input, alarm output, main menu. Among which, Pan/Tilt/Zoom and color setting applies for current selected channel. If you are in multiple-window mode, system automatically switches to the corresponding channel.

  • Page 40: Installation And Connections

    3 Installation and Connections Note: All the installation and operations here should conform to your local electric safety rules. 3.1 Check Unpacked DVR When you receive the DVR from the forwarding agent, please check whether there is any visible damage. The protective materials used for the package of the DVR can protect most accidental clashes during transportation.
  • Page 41 HDD and the SATA Close the chassis and fix the port screws to secure firmly. ECL-DVR32 Series 3.2.1.2 This series DVR max supports 8 SATA HDDs. Please use HDD of 7200rpm or higher. 1. Loosen the screws of the 2.

  • Page 42: Rack Installation

    7. Unfasten the HDD power Insert the HDD power Use the special data cable to cable. cable. connect the HDD and the SATA port. Close the chassis and fix the screws to secure firmly. Important: If the HDD amount is less than four, you do not need to install the HDD bracket. When there is a bracket, please make sure the installation direction of HDDs is the same.

  • Page 43: Connecting Video Output

    The camera shall be installed in a cool, dry place away from direct sunlight, inflammable, explosive substances and etc. The camera and the DVR should have the same grounding to ensure the normal operation of the camera. Guarantee stability and reliability of the transmission line BTT TB Please use high quality, sound shielded BNC.

  • Page 44: Alarm Input And Output Connection

    3.6 Alarm Input and Output Connection Please read the followings before connecting. 1. Alarm input a. Please make sure alarm input mode is grounding alarm input. b. Grounding signal is needed for alarm input. c. Alarm input needs the low level voltage signal. d.
  • Page 45 Figure 3-1 Figure 3-2 Figure 3-3 Please refer to the following sheet for detailed information. : 1，2，3，4，5，6， ALARM 1 to ALARM 16. The alarm becomes active in low voltage. 7，8，9，10，11， 12，13，14，15，16 NO1 C1， The first four are four groups of normal open activation output (on/off NO2 C2，...

  • Page 46: Alarm Input Port

    device power to cancel the alarm. +12V It is external power input. Need the peripheral equipment to provide +12V power (below 1A). Earth cable. 485 A/B 485 communication port. They are used to control devices such as decoder. T+,T-,R+,R- They are four-wire double duplex RS485 port T+ T-: output wire R+ R-: input wire 3.6.2 Alarm Input Port...
  • Page 47 Rating Rated switch capacity 30VDC 2A, 125VAC 1A （Resistance Maximum switch power 125VA 160W Load） Maximum switch voltage 250VAC, 220VDC Maximum switch currency Insulation Between touches with same 1000VAC 1minute polarity 1000VAC 1minute Between touches with different polarity Between touch and winding 1000VAC 1minute Between touches with same Surge voltage...

  • Page 48: Other Interfaces

    Figure 3-5 485 Port Figure 3-6 Figure 3-7 485 Port 3.8 Other Interfaces There are still other interfaces on the DVR, such as USB ports.

  • Page 49: Overview Of Navigation And Controls

    4 Overview of Navigation and Controls 4.1 Boot up and Shutdown 4.1.1 Boot up Before the boot up, please make sure:  The rated input voltage matches the device power on-off button. Please make sure the power wire connection is OK. Then click the power on-off button. ...

  • Page 50: Startup Wizard

    4.2 Startup Wizard After device successfully booted up, it goes to startup wizard. Click Cancel/Next button, you can see system goes to login interface. Tips Check the box Startup button here, system goes to startup wizard again when it boots up the next time.
  • Page 51 Note: For security reason, please modify password after you first login. Within 30 minutes, three times login failure will result in system alarm and five times login failure will result in account lock! Click OK button, you can go to General interface. See Figure 4-3. For detailed information, please refer to chapter 4.10.5.1.
  • Page 52 Figure 4-4 Click Next button, you can go to Schedule interface. See Figure 4-5. For detailed information, please refer to chapter 4.10.4.1.1. Figure 4-5 Click Finish button, system pops up a dialogue box. Click the OK button, the startup...

  • Page 53: Manual Record

    wizard is complete. See Figure 4-6. Figure 4-6 4.3 Manual Record 4.3.1 Live Viewing After you logged in, the system is in live viewing mode. You can see system date, time, channel name and window No. If you want to change system date and time, you can refer to general settings (Main Menu->Setting->System->General).
  • Page 54  Support digital zoom function.  Support real-time backup function. You can follow the contents listed below for the operation instruction. Preview control interface Move you mouse to the top centre of the video of current channel, you can see system pops up the preview control interface.

  • Page 55: Right-Click Menu

    Right click mouse to cancel zoom and go back to the original interface. Manual record function It is to backup the video of current channel to the USB device. System can not backup the video of multiple-channel at the same time. Click button , system begins recording.

  • Page 56: Pip

    Figure 4-11 4.4.2 PIP It is to realize picture in picture function in 1-window mode. The small window supports instance playback, digital zoom and etc.  Window switch: Double click the small window, you can switch the position of the large window and the small window.

  • Page 57: Ptz Control

    Figure 4-12 Figure 4-13 Go to the 1-winode mode, on the navigation bar, click , you can see the video on the large window and the video from the next channel is the default video on the small window. If you have set PIP function, you can click to view the last edited PIP video.
  • Page 58 Please note the commend name is grey once device does not support this function. The PTZ operation is only valid in one-window mode. Here you can control PTZ direction, speed, zoom, focus, iris, preset, tour, scan, pattern aux function, light and wiper, rotation and etc. Speed is to control PTZ movement speed.

  • Page 59: Ptz Function Setup

    etc. See Figure 4-16. Figure 4-16 Please refer to the following sheet for detailed information. Please note the above interface may vary due to different protocols. The button is grey and can not be selected once the current function is null. Right click mouse or click the ESC button at the front panel to go back to the Figure 4-14.
  • Page 60 Figure 4-17 Preset Setup In Figure 4-17, click preset button and use eight direction arrows to adjust camera to the proper position. The interface is shown as in Figure 4-18. Click Set button and then input preset number. Click Set button to save current preset. Figure 4-18 Tour Setup In Figure 4-17, click tour button.
  • Page 61 Figure 4-19 Pattern Setup In Figure 4-17, click Pattern button and input pattern number. Click Begin button to start direction operation. Or you can go back to Figure 4-14 to operate zoom/focus/iris/direction operation. In Figure 4-17, click End button. Figure 4-20 Scan Setup In Figure 4-17, click Scan button.
  • Page 62 Figure 4-21 4.4.3.2 Call PTZ Function Call Preset In Figure 4-16, input preset value and then click to call a preset. Click again to stop call. Call Pattern In Figure 4-16, input pattern value and then click to call a pattern. Click again to stop call.

  • Page 63: Auto Focus

    Click , system goes to the following interface. The options here are defined by the protocol. The aux number is corresponding to the aux on-off button of the decoder. See Figure 4-22. Figure 4-22 4.4.4 Auto Focus It is to set auto focus function. Please make sure the camera supports this function. 4.4.5 Color Here you can set hue, brightness, contrast, saturation, gain, white level, color mode and etc.
  • Page 64 Item Note periods. Effective Time Check the box here to enable this function and then set period time. The value here is to adjust the edge of the video. The value ranges from 0 to 100. The larger the value is, the clear the edge is and vice versa.

  • Page 65: Search

    Item Note gentle. Select a color mode, the sharpness, brightness, contrast automatically switch corresponding setup. 4.4.6 Search Please refer to chapter 4.8.1 for detailed information. 4.4.7 Record Control Please refer to chapter 4.10.4.3 for detailed information. 4.4.8 Remote Device Please refer to chapter 4.10.1.1 for detailed information. 4.4.9 Manual Record Please refer to chapter 4.4.9 for detailed information.
  • Page 66 Figure 4-25 In Figure 4-25, click Add to favorites; you can see the following interface. See Figure 4-26 . Here you can input customized favorites name. System max supports 31-character. Click OK button, you can save current favorites name. Figure 4-26 In Figure 4-25, click Edit favorites;...

  • Page 67: Channel Tree

    Figure 4-27 Double click a name; you can change its name. See Figure 4-28. Input a new name and then click OK button. Figure 4-28 4.5.4 Channel Tree It is to set channel setup. The interface is shown as below. See Figure 4-29.

  • Page 68: Tour

    Figure 4-29 The one level includes 16 channels. See Figure 4-30. You can left click to select a channel on the tree and then drag it to the preview window on the left pane. Once the channel is on the preview window, the channel number on the channel tree becomes grey and it is null now (can not be selected).

  • Page 69: Search

    4.5.8 Search Click button , system goes to search interface. Please refer to chapter 4.8.1 4.5.9 Alarm Status Click button , system goes to alarm status interface. It is to view device status and channel status. Please refer to chapter 4.10.3. 4.5.10 Channel Info Click button , system goes to the channel information setup interface.

  • Page 70: Usb Device Auto Pop-Up

    ， system goes to the USB Manager interface. It is to view USB information, Click backup and update. Please refer to chapter 4.8.2, chapter 4.9.4, chapter 4.10.5.10, and chapter 4.10.5.12 for detailed information. 4.6 USB Device Auto Pop-up After you inserted the USB device, system can auto detect it and pop up the following dialogue box.

  • Page 71: Operation

    Figure 4-33 4.8 Operation 4.8.1 Search Click search button in the main menu, search interface is shown as below. See Figure 4-34. Usually there are three file types:  R: Regular recording file.  A: External alarm recording file.  M: Motion detection recording file...
  • Page 72 Figure 4-34 Please refer to the following sheet for more information. Name Function  Display Here is to display the searched picture or file.  window Support 1/4/9/16-window playback.  Here you can select to search the picture or the recorded file. ...
  • Page 73  selection In 9-window playback mode, you can switch between 1-8 and 9-16 channels.  pane. In 16-window playback mode, you can switch between1-16 and 17-32 channels.  The time bar will change once you modify the playback mode or the channel option.
  • Page 74 ► Slow play In playback mode, click it to realize various slow play modes such as slow play 1, slow play 2, and etc. Fast forward  In playback mode, click to realize various fast play modes such as fast play 1,fast play 2 and etc.
  • Page 75  For one device, if there is a backup in process, you can not start a new backup operation.  It is to edit the file. ●Please play the file you want to edit and then click this button when you want to edit.
  • Page 76 channel This function is null if there is no record file or system is in smart search process. when playback 4.8.1.1 Smart Search During the multiple-channel playback mode, double click one channel and then click the button, system begins smart search. System supports 396(22*18 PAL) and 330(22*15 NTSC) zones.

  • Page 77: Mark Playback

     After you searched files, system implement accurate playback once you click Play for the first time.  System does not support accurate playback for picture.  System supports synchronization playback and non-synchronous playback. The synchronization playback supports all channels and non-synchronous playback only supports accurately playback of current select channel.

  • Page 78: Backup

    Here you can set to begin playback from previous N seconds of the mark time. Note Usually, system can playbacks previous N seconds record if there is such kind of record file. Otherwise, system playbacks from the previous X seconds when there is such as kind of record.
  • Page 79 Client Operation for network download backup operation. Click backup button, you can see an interface is shown as in Figure 4-39. Here is for you to view devices information. You can view backup device name and its total space and free space. The device includes CD-RW, DVD burner, USB device, flash disk, eSATA backup.
  • Page 80 Figure 4-40 √ before channel name. You can use Fn or cancel System only backup files with a button to delete √ after file serial number. Click Start button, system begins copy. At the same time, the backup button becomes stop button.

  • Page 81: Shut Down

    When the system completes backup, you can see a dialogue box prompting successful backup.  File format: Click the file format; you can see there are two options: DAV/ASF. The file name format usually is: Channel number+Record type+Time. In the file name, the YDM format is Y+M+D+H+M+S.

  • Page 82: Hdd Information

    Figure 4-43 4.9.1.1 HDD Information Here is to list hard disk type, total space, free space, video start time and status. See Figure 4-44.  SATA: 1-8 here means system max supports 8 HDDS (It depends on the product you purchased).

  • Page 83: Record Info

    Figure 4-44 Double click one HDD information; you can see the HDD SMART information. See Figure 4-45. Figure 4-45 4.9.1.2 Record Info It is to view record start time and end time. See Figure 4-46.
  • Page 84 Figure 4-46 4.9.1.3 BPS Here is for you to view current video data stream (KB/s) and occupied hard disk storage (MB/h). See Figure 4-47. Figure 4-47 4.9.1.4 Version Here is for you to view some version information such as version number, built date, serial number and etc.

  • Page 85: Event

    Figure 4-48 4.9.2 Event It is to display device status and channel status. See Figure 4-49. Figure 4-49 4.9.3 Network...

  • Page 86: Online Users

    4.9.3.1 Online Users Here is for you to manage online users. See Figure 4-50. You can disconnect one user or block one user if you have proper system right. Max disconnection setup is 65535 seconds. System detects there is any newly added or deleted user in each five seconds and refresh the list automatically.

  • Page 87: Network Test

    Figure 4-51 4.9.3.3 Network Test Network test interface is shown as in Figure 4-52.  Destination IP: Please input valid IPV4 address or domain name.  Test: Click it to test the connection with the destination IP address. The test results can display average delay and packet loss rate and you can also view the network status as OK, bad, no connection and etc.

  • Page 88: Log

    Figure 4-52 4.9.4 Log Here is for you to view system log file. System lists the following information. See Figure 4-53. Log types include system operation, configuration operation, data management, alarm event, record operation, account manager, log clear, file operation and etc. It optimized reboot log.

  • Page 89: Remote Log

    Figure 4-53 Select an item on the list and then click the Details button or double click the log item, you can view the detailed information such as log time, log type, log user, IP address and etc. See Figure 4-54. Figure 4-54 4.9.4.1 Remote Log In this interface, you can search the IPC log information of the corresponding channel.

  • Page 90: Setting

    select another channel (doe not need to click Search button again), you can view remote connection log. Figure 4-55 4.10 Setting 4.10.1 Camera 4.10.1.1 Remote Device (For digital channel only) 4.10.1.1.1 Remote Device In the main menu, from Camera ->Remote, you can go to an interface shown as in Figure 4-56.
  • Page 91  Delete: Please select one device in the Added device list and then click remove.  Status: means connection is OK and means connection failed.  Delete；Select a device on the Added device list, click Delete button, system disconnect device first and then remove its name from the list. ...
  • Page 92 Figure 4-57 4.10.1.1.2 Channel Status Here you can view the IPC status of the corresponding channel such as motion detect, video loss, tampering, alarm and etc. See Figure 4-58.  IPC status: : Front-end does not support. : Front-end supports. There is alarm event from current front-end.
  • Page 93 Figure 4-59 4.10.1.1.4 Remote Upgrade It is to update the camera. From main menu->setting->camera->remote, the interface is shown as below. See Figure 4-60. Click Browse button and then select the upgrade file. Then select a channel (or you can select device type filter to select several devices at the same time.) Click Start upgrade button to update.
  • Page 94 4.10.1.2 Image The image interface is shown as below. See Figure 4-61(analog channel) and Figure 4-62(digital channel).  Channel: Select a channel from the dropdown list.  Saturation: It is to adjust monitor window saturation. The value ranges from 0 to 100. The default value is 50.
  • Page 95  Auto: The auto white balance is on. System can auto compensate the color temperature to make sure the vide color is proper.  Sunny: The threshold of the white balance is in the sunny mode.  Night: The threshold of the white balance is in the night mode. ...
  • Page 96 Figure 4-62 4.10.1.3 Encode It is to set video bit stream, picture bit stream, video overlay parameter and etc. 4.10.1.3.1 Video Video setting includes the following items. See Figure 4-63.  Channel: Select the channel you want.  Type: Please select from the dropdown list. There are three options: regular/motion detect/alarm.
  • Page 97 Figure 4-63 4.10.1.3.2 Snapshot Here you can set snapshot mode, picture size, quality and frequency. See Figure 4-64.  Snapshot mode: There are two modes: regular and trigger. If you set timing mode, you need to set snapshot frequency. If you set trigger snapshot, you need to set snapshot activation operation.
  • Page 98 4.10.1.3.3 Overlay Overlay interface is shown as in Figure 4-65.  Cover area: Here is for you to set cover area. You can drag you mouse to set proper section size. In one channel video, system max supports 4 zones in one channel. ...
  • Page 99 Figure 4-66 4.10.1.3.4 Channel Name It is to modify channel name. It max supports 31-character. See Figure 4-67. Figure 4-67 4.10.1.3.5 Channel Type It is to set channel type. Each channel supports analog connection/analog HD connection/network camera connection (Slight function difference may be found). The network camera connection shall begin with the last channel.

  • Page 100: Network

    Figure 4-68 4.10.2 Network 4.10.2.1 TCP/IP The single network adapter interface is shown as in Figure 4-69 and the dual network adapters interface is shown as in Figure 4-70  Network Mode : Includes multiple access, fault tolerance, and load balancing ...
  • Page 101  Main Network Card: Please select eth0/eth1 (optional).after enable multiple access function. Note: Some series support the above three configurations and supports functions as multiple-access, fault-tolerance and load balancing.  IP Version: There are two options: IPv4 and IPv6. Right now, system supports these two IP address format and you can access via them.
  • Page 102 Figure 4-69 Figure 4-70 4.10.2.2 Connection The connection setup interface is shown as in Figure 4-71.  Max connection: system support maximal 128 users. 0 means there is no connection limit.  TCP port: Default value is 37777.  UDP port: Default value is 37778.
  • Page 103  HTTP port: Default value is 80.  HTTPS port: Default value is 443.  RTSP port: Default value is 554. Important: System needs to reboot after you changed and saved any setup of the above four ports. Please make sure the port values here do not conflict. Figure 4-71 4.10.2.3 WIFI The WIFI interface is shown as below.
  • Page 104 Figure 4-72  WIFI working status: Here you can view current connection status. Please note:  After successful connection, you can see WIFI connection icon at the top right corner of the preview interface.  When the hotspot verification type is WEP, system displays as AUTO since the device can not detect its encryption type.
  • Page 105  AUTH: It is the authentication mode. It supports PAP/CHAP.  Dial number: Please input 3G network dialup number you got from your ISP.  User name: It is the user name for you to login the 3G network.  Password: It is the password for you to login the 3G network.

  • Page 106: Ddns Setup

    Figure 4-74 4.10.2.6 DDNS Setup DDNS setup interface is shown as in Figure 4-75. You need a PC of fixed IP in the internet and there is the DDNS software running in this PC. In other words, this PC is a DNS (domain name server). In network DDNS, please select DDNS type and highlight enable item.
  • Page 107 Figure 4-75 Please note NNDS type includes: CN99 DDNS, NO-IP DDNS, Quick DDNS, Dyndns DDNS and sysdns DDNS. All the DDNS can be valid at the same time, you can select as you requirement. Private DDNS function shall work with special DDNS server and special Professional Surveillance Software (PSS).
  • Page 108  Domain name：There are two modes: Default domain name and customized domain name. Except default domain name registration, you can also use customized domain name (You can input your self-defined domain name.) After successful registration, you can use domain name to login installed of the device IP. ...
  • Page 109  Default: Click it to restore default setup. In this case, the trusted sites and blocked sites are both null. Note:  If you enabled trusted sites, only the IP in the trusted sites list can access the device.  If you enabled blocked sites, the IP in the blocked sites can not access the device.
  • Page 110  Title: Please input email subject here. System support English character and Arabic number. Max 32-digit.  Receiver: Please input receiver email address here. System max supports 3 email boxes. System automatically filters same addresses if you input one receiver repeatedly.
  • Page 111 -> Serv-U Administator. Now you can set user password and FTP folder. Please note you need to grant write right to FTP upload user. See Figure 4-79. Figure 4-79 You can use a PC or FTP login tool to test setup is right or not. For example, you can login user ZHY to FTP://10.10.7.7 and then test it can modify...
  • Page 112 After completed channel and weekday setup, you can set two periods for one each channel. Click the Test button, you can see the corresponding dialogue box to see the FTP connection is OK or not. Figure 4-81 4.10.2.10 UPnP The UPNP protocol is to establish a mapping relationship between the LAN and the WAN. Please input the router IP address in the LAN in Figure 4-69.
  • Page 113 Important: When you are setting the router external port, please use 1024~5000 port. Do not use well-known port 1~255 and the system port 256~1023 to avoid conflict. For the TCP and UDP, please make sure the internal port and external port are the same to guarantee the proper data transmission.
  • Page 114 You can set in the following interface. See Figure 4-84. Figure 4-84 Please enable the SNMP function. Use the corresponding software tool (MIB Builder and MG-SOFT MIB Browser. You still need two MIB file: BASE-SNMP-MIB, DVR-SNMP-MIB) to connect to the device. You can get the device corresponding configuration information after successfully connection.
  • Page 115 Figure 4-85 Here you can set a multiple cast group. Please refer to the following sheet for detailed information.  IP multiple cast group address -224.0.0.0-239.255.255.255 -“D” address space  The higher four-bit of the first byte=”1110”  Reserved local multiple cast group address -224.0.0.0-224.0.0.255 -TTL=1 When sending out telegraph -For example...

  • Page 116: Alarm Centre

    Multiple cast PORT: 3666. After you logged in the Web, the Web can automatically get multiple cast address and add it to the multiple cast groups. You can enable real-time monitor function to view the view. Please note multiple cast function applies to special series only. 4.10.2.13 Alarm Centre This interface is reserved for you to develop.
  • Page 117 Figure 4-87 2) The proxy server software developed from the SDK. Please open the software and input the global setup. Please make sure the auto connection port here is the same as the port you set in the previous step. 3) Now you can add device.

  • Page 118: Event

    Figure 4-88 4.10.3 Event 4.10.3.1 Detect In the main menu, from Setting->Event->Detect, you can see motion detect interface. See Figure 4-89. There are three detection types: motion detection, video loss, tampering.  The video loss has no detection region and sensitivity setup and tampering has no detection region setup.
  • Page 119 click ENTER button to exit current setup. Do remember click save button to save current setup. If you click ESC button to exit the region setup interface system will not save your zone setup. The analog channel supports 4 zones. For the digital channel, please make sure your network camera supports 4 zones.
  • Page 120  PTZ activation: Here you can set PTZ movement when an alarm occurs. Such as go to preset, tour &pattern when there is an alarm. Click “select” button, you can see an interface is shown as in Figure 4-91  Record Delay: System can delay the record for specified time after alarm ended.
  • Page 121 Figure 4-90 Figure 4-91...
  • Page 122 Figure 4-92 Figure 4-93 Motion detect here only has relationship with the sensitivity and region setup. It has no relationship with other setups. 4.10.3.1.2 Video Loss In Figure 4-89, select video loss from the type list. You can see the interface is shown as in Figure 4-94.This function allows you to be informed when video loss phenomenon occurred.
  • Page 123 Please refer to chapter 4.10.3.1.1 motion detection for detailed information. Figure 4-94 4.10.3.1.3 Tampering When someone viciously masks the lens, or the output video is in one-color due to the environments light change, the system can alert you to guarantee video continuity. Tampering interface is shown as in Figure 4-95.
  • Page 124 Figure 4-95 4.10.3.2 Alarm Before operation, please make sure you have properly connected alarm devices such as buzzer. In the main menu, from Setting->Event->Alarm, you can see alarm setup interface. See Figure 4-96. There are four alarm types. See Figure 4-96 to Figure 4-99. ...
  • Page 125  Period: Click set button, you can see an interface is shown as in Figure 4-101. There are two ways for you to set periods. There are max 6 periods in one day. There are four record types: regular, motion detection (MD), Alarm, MD & alarm. ...
  • Page 126 activation snapshot when alarm occurs, and otherwise system just operates the schedule snapshot.  Video matrix: Check the box here to enable this function. When an alarm occurs, SPOT OUT port displays device video output. It displays video (1-window tour) from alarm activation channel you select at the Record channel item.
  • Page 127 Figure 4-97 Figure 4-98...
  • Page 128 Figure 4-99 Figure 4-100...
  • Page 129 Figure 4-101 Figure 4-102 4.10.3.3 Abnormality There are two types: HDD/Network.  HDD: HDD error, no disk, no space. See Figure 4-103 and Figure 4-104.  Network: Disconnection, IP conflict, MAC conflict. See Figure 4-105.  Alarm output: Please select alarm activation output port (multiple choices). ...
  • Page 130  Latch: Here you can set corresponding delaying time. The value ranges from 1s-300s. System automatically delays specified seconds in turning off alarm and activated output after external alarm cancelled.  Show message: system can pop up the message in the local screen to alert you when alarm occurs.
  • Page 131 Figure 4-104 Figure 4-105...

  • Page 132: Alarm Output

    4.10.3.4 Alarm Output Here is for you to set proper alarm output such as schedule, manual. Please highlight icon to select the corresponding alarm output. After all the setups please click OK button, system goes back to the previous menu. See Figure 4-106.
  • Page 133  : Click it to delete a record type from one period.  Record Type: Please check the box to select corresponding record type. There are four types: Regular/MD (motion detect)/Alarm/MD&Alarm.  Week day: There are eight options: ranges from Saturday to Sunday and all. ...
  • Page 134 Figure 4-109 Please highlight icon to select the corresponding function. After completing all the setups please click save button, system goes back to the previous menu. There are color bars for your reference. Green color stands for regular recording, yellow color stands for motion detection and red color stands for alarm recording. The white means the MD and alarm record is valid.
  • Page 135 Figure 4-110 Figure 4-111 4.10.4.1.1.1 Quick Setup Copy function allows you to copy one channel setup to another. After setting in channel 1, click Copy button, you can go to interface Figure 4-112. You can see current channel name is grey such as channel 1. Now you can select the channel you wan to paste such as channel 5/6/7.
  • Page 136 Figure 4-112 4.10.4.1.1.2 Redundancy Redundancy function allows you to memorize record file in several disks. When there is file damage occurred in one disk, there is a spare one in the other disk. You can use this function to maintain data reliability and safety. ...
  • Page 137  In main menu, from Setting->Camera->Encode->Snapshot interface, here you can input snapshot mode as regular, size, quality and frequency. See Figure 4-114.  In main menu, from Setting->Camera->Encode->Schedule interface, please enable snapshot function. See interface on the right of Figure 4-115. Please refer to the following figure for detailed information.
  • Page 138 Figure 4-115 4.10.4.1.2.2 Trigger Snapshot Please follow the steps listed below to enable the activation snapshot function. After you enabled this function, system can snapshot when the corresponding alarm occurred.  In main menu, from Setting->Camera->Encode->Snapshot interface, here you can input snapshot mode as trigger, size, quality and frequency.
  • Page 139 Figure 4-117 Figure 4-118 4.10.4.1.2.3 Priority Please note the activation snapshot has the higher priority than schedule snapshot. If you have enabled these two types at the same time, system can activate the activation snapshot when alarm occurs, and otherwise system just operates the schedule snapshot.
  • Page 140 In the main menu, from Setting->Network->FTP, you can set FTP server information. Please enable FTP function and then click save button. See Figure 4-119. Please boot up corresponding FTP server. Please enable schedule snapshot (Chapter 4.10.4.1.2.1) or activation snapshot (Chapter 4.10.4.1.2.2) first, now system can upload the image file to the FTP server. Please input corresponding...
  • Page 141 Figure 4-120 4.10.4.3 Record 4.10.4.3.1 Record Control Note: You need to have proper rights to implement the following operations. Please make sure the HDD has been properly installed. There are three ways for you to go to manual record menu. ...
  • Page 142 Figure 4-121 4.10.4.3.2 Snapshot Operation Check the corresponding box to enable/disable schedule snapshot function. See Figure 4-122. Figure 4-122 Tips You can check All button after the corresponding status to enable/disable all-channel snapshot function.
  • Page 143 4.10.4.4 Advanced It is to set HDD group, and HDD group setup for main stream, sub stream and snapshot operation 4.10.4.4.1 HDD Important HDD group and quota mode can not be valid at the same time. System needs to restart once you change the mode here. The HDD group mode is shown as in Figure 4-123.
  • Page 144 Figure 4-124 Figure 4-125...
  • Page 145 Figure 4-126 4.10.4.5 Quota Here you can set channel storage capacity. See Figure 4-127. Select a channel from the dropdown list and then select corresponding HDD quota. Figure 4-127...

  • Page 146: Hdd Detect

    Click Quota Statistics, you can go to the following interface. You can view HDD capacity you set for each channel. See Figure 4-128. Figure 4-128 4.10.4.6 HDD Detect The HDD detect function is to detect HDD current status so that you can clearly understand the HDD performance and replace the malfunction HDD.
  • Page 147 Figure 4-129 4.10.4.6.2 Detect Report After the detect operation, you can go to the detect report to view corresponding information. The detect report interface is shown as below. See Figure 4-130. Figure 4-130...
  • Page 148 Click View, you can see the detailed information such as detect result, backup and S.M.A.R.T. See Figure 4-131 and Figure 4-132. Figure 4-131 Figure 4-132...

  • Page 149: System

    4.10.5 System 4.10.5.1 General 4.10.5.1.1 Device General setting includes the following items. See Figure 4-133.  Device ID: Please input a corresponding device name here.  Device No: Here you can set device number.  Language: System supports various languages: Chinese (simplified), Chinese (Traditional), English, Italian, Japanese, French, Spanish (All languages listed here are optional.
  • Page 150 Figure 4-133 4.10.5.1.2 Date and Time The interface is shown as in Figure 4-134.  Date format: There are three types: YYYYY-MM-DD: MM-DD-YYYYY or DD-MM-YYYY.  Date separator: There are three denotations to separate date: dot, beeline and solidus.  DST: Here you can set DST time and date.
  • Page 151 Figure 4-134 4.10.5.1.3 Holiday Holiday setup interface is shown as in Figure 4-135. Click Add new holiday button, you can input new holiday information. See Figure 4-136. Here you can set holiday name, repeat mode and start/end time. Note  When you enable Holiday settings and schedule setup at the same time, holiday setting has the priority.
  • Page 152 Figure 4-135 Figure 4-136 4.10.5.2 Display 4.10.5.2.1 Display Display setup interface is shown as below. See Figure 4-137.  Transparency: Here is for you to adjust transparency. The value ranges from 128 to 255.
  • Page 153  Channel name: Here is for you to modify channel name. System max support 25-digit (The value may vary due to different series). Please note all your modification here only applies to DVR local end. You need to open web or client end to refresh channel name.
  • Page 154 Figure 4-138 4.10.5.2.3 Tour Here you can activate tour function. Click Setup button, you can see an interface shown as in Figure 4-139  Enable tour: Highlight box here to enable this function.  Interval: System supports 1/8/-window tour. Input proper interval value here. The value ranges from 5-120 seconds.
  • Page 155  On the navigation bar, click to enable/disable tour function. Figure 4-139 4.10.5.2.4 Zero-channel Encoding Click zero-channel encoding button, you can go to the following interface. See Figure 4-140.Here you can enable and set zero-channel encoding function so that you can view several video sources at one channel.
  • Page 156 Figure 4-140 4.10.5.3 Video Matrix 4.10.5.3.1 BNC Here you can set matrix output channel and its interval. System supports 1/4-window (and etc) SPOT tour. See Figure 4-141.
  • Page 157 Figure 4-141 4.10.5.3.2 HDMI This function is for some series only. The HDMI interface is shown as in Figure 5-85. It is to set the HD video matrix output tour function of the HDMI port 2. You can set tour channel, resolution, and interval. System support 1/4-window tour.
  • Page 158 Figure 4-142 4.10.5.4 RS232 RS232 interface is shown as below. There are five items. See Figure 4-143.  Function: There are various devices for you to select. Console is for you to use the COM or mini-end software to upgrade or debug the program. The control keyboar d is for you to control the device via the special keyboard.
  • Page 159 Figure 4-143 4.10.5.5 PTZ The pan/tilt/zoom setup includes the following items. Please select channel first. See Figure 4-144.  PTZ type: There are two options: local/remote. Please select remote if you are connecting to the network PTZ.  Protocol: Select corresponding PTZ protocol such as PELCOD. ...
  • Page 160 Figure 4-144 4.10.5.6 ATM/POS The ATM/POS function is for financial areas. It includes Sniffer, information analysis and title overlay function. The Sniffer mode includes COM and network. 4.10.5.6.1 COM Type The COM interface is shown as below. See Figure 4-145. ...
  • Page 161 Figure 4-145 4.10.5.6.2 Network Type The network type interface is shown as below. See Figure 4-146. Here we take the ATM/POS protocol to continue. There are two types: with or without the protocol according to client’s requirements. With the protocol For ATM/POS with the protocol, you just need to set the source IP, destination IP (sometimes you need to input corresponding port number).
  • Page 162 Without the protocol For the ATM/POS without the protocol, the interface is shown as in Figure 4-147. Source IP refers to host IP address that sends out information (usually it is the device host.) Destination IP refers to other systems that receive information. Usually you do not need to set source port and target port.
  • Page 163 Figure 4-148 Click Add button, you can add audio file and import the audio file via the USB device. See Figure 4-149. Figure 4-149 4.10.5.7.2 Schedule It is to set schedule broadcast function. You can play the different audio files in the specified periods.
  • Page 164 Figure 4-150 4.10.5.8 Account Here is for you to implement account management. See Figure 4-151. Here you can:  Add new user  Modify user  Add group  Modify group  Modify password. For account management please note:  For the user account name and the user group, the string max length is 6-byte.
  • Page 165  About user account and MAC. When you add a new user, you can input the MAC address of current user. Only the user of the same MAC address can access the device remotely.(MAC address is for the device of the same LAN.) If you leave MAC address item in blank when you add a new user, the user of any MAC address can access the device remotely.
  • Page 166 4.10.5.8.1 Add/Modify Group Click add group button, the interface is shown as below. See Figure 4-152. Here you can input group name and then input some memo information if necessary. There are total 98 rights such as control panel, shut down, real-time monitor, playback, record, record file backup, PTZ, user account, system information view, alarm input/output setup, system setup, log view, clear log, upgrade system, control device and etc.

  • Page 167: Auto Maintain

    Click add user button, the interface is shown as in Figure 4-153. Please input the user name, password, select the group it belongs to from the dropdown list. Then you can check the corresponding rights for current user. For convenient user management, usually we recommend the general user right is lower than the admin account.

  • Page 168: Config Backup

    Figure 4-154 4.10.5.10 Config Backup The configuration file backup interface is shown as below. See Figure 4-155. This function allows you to import/export system configuration. You can use this function when there are several devices need the same setup.  Export: Please connect the peripheral device first and then go to the following interface.
  • Page 169 Figure 4-155 4.10.5.11 Default Click default icon, system pops up a dialogue box. You can highlight to restore default factory setup. See Figure 5-26.  Camera  Network  Event  Storage  System Please highlight icon to select the corresponding function. After all the setups please click save button, system goes back to the previous menu.
  • Page 170 Figure 4-156 4.10.5.12 Update Here is for you to view hardware features, software version, built date, release SN information and etc. You can also update system here. See Figure 4-48.  Start: Please insert the USB device that have the update file to the device and then click the Start button to begin the update.

  • Page 171: Web Operation

    5 WEB OPERATION Slightly difference may be found in the interface due to different series. 5.1 Network Connection Before web client operation, please check the following items:  Network connection is right  DVR and PC network setup is right. Please refer to network setup(main menu->Setting->Network) ...

  • Page 172: Lan Mode

    Figure 5-2 5.3 LAN Mode For the LAN mode, after you logged in, you can see the main window. See Figure 5-3. Figure 5-3 This main window can be divided into the following sections.  Section 1: there are five function buttons: Live（chapter 5.4）, setup (chapter 5.8), search (chapter 5.10), alarm (chapter 5.11), and logout (chapter 5.12).

  • Page 173: Section 3: Start Dialogue Button

     Section 2: There are channel number and one button: Start all. Start all button is to enable/disable all-channel real-time monitor. Click it the button becomes yellow. See Figure 5-4. Figure 5-4 Please refer to Figure 5-5 for main stream and extra stream switch information. Figure 5-5 ...

  • Page 174: Real-Time Monitor

    Figure 5-8  Section 6: From the left to the right ,you can see video quality/fluency/ full screen/1-window/4-window/6-window/8-window/9-window/13-window/16-window/20- window/25-window/36-window.. You can set video fluency and real-time feature priority.  Section 7: PTZ operation panel. Please refer to chapter 5.5 for detailed information. ...

  • Page 175: Ptz

     1: Digital zoom: Click this button and then left drag the mouse in the zone to zoom in. right click mouse system restores original status.  2: Local record. When you click local record button, the system begins recording and this button becomes highlighted.

  • Page 176: Image/Relay-Out

    Parameter Function You can turn on or turn off the light/wiper. Light and wiper 3D Intelligent Positioning You can click this icon to display or hide the PTZ control platform. Figure 5-11 5.6 Image/Relay-out Select one monitor channel video and then click Image button in section 8, the interface is shown as Figure 5-12.

  • Page 177: Wan Login

    Figure 5-13 5.7 WAN Login In WAN mode, after you logged in, the interface is shown as below. See Figure 5-14. Figure 5-14 Please refer to the following contents for LAN and WAN login difference. 1) In the WAN mode, system opens the main stream of the first channel to monitor by default.

  • Page 178: Setup

    Figure 5-15 Important The window display mode and the channel number are by default. For example, for the 16-channel, the max window split mode is 16. 3) Multiple-channel monitor, system adopts extra stream to monitor by default. Double click one channel, system switches to single channel and system uses main stream to monitor.
  • Page 179 Figure 5-16 Figure 5-17 Please refer to the following sheet for log parameter information. Parameter Function Click Device search button, you can view the searched device Device search information on the list. It includes device IP address, port, device name, manufacturer and type. Select a device in the list and then click Add button, system can connect the device automatically and add it to the Added device list.
  • Page 180 Parameter Function Delete Click , you can delete the remote connection of the corresponding channel. : Connection succeeded. Connection status : Connection failed. Delete Select a device in the Added device list and then click Delete button, system can disconnect the device and remove it from the Added device list.
  • Page 181 Figure 5-19 Please refer to the following sheet for detailed information. Parameter Function Channel Please select a channel from the dropdown list. Period It divides one day (24 hours) to two periods. You can set different hue, brightness, and contrast for different periods. It is to adjust monitor video brightness and darkness level.
  • Page 182 Gain The gain adjust is to set the gain value. The smaller the value is, the low the noise is. But the brightness is also too low in the dark environments. It can enhance the video brightness if the value is high.
  • Page 183 video according to the device feature (The general bright of the video or there is IR light or not.)  B/W: The device outputs the black and white video.  Sensor: It is to set when there is peripheral connected IR light.
  • Page 184 dropdown list. Please note the option may vary due to different series. Frame Rate PAL：1～25f/s；NTSC：1～30f/s.  Bit Rate Main stream: You can set bit rate here to change video quality. The large the bit rate is , the better the quality is. Please refer to recommend bit rate for the detailed information.
  • Page 185 Click it; you can copy current channel setup to other channel(s). Copy 5.8.1.3.3 Video Overlay The video overlay interface is shown as in Figure 5-22. Figure 5-22 Please refer to the following sheet for detailed information. Parameter Function Cover-area Check Preview or Monitor first. Click Set button, you can privacy mask the specified video in the preview or monitor video.

  • Page 186: Network

    Please click the Save button to save current setup. Figure 5-23 5.8.1.4 Channel Name Here you can set channel name. See Figure 5-24. Please note this function is for analog channel only. Figure 5-24 5.8.2 Network 5.8.2.1 TCP/IP The TCP/IP interface is shown as in Figure 5-25. Figure 5-25 Please refer to the following sheet for detailed information.
  • Page 187 DHCP mode to auto search the IP.  If you select the static mode, you need to set the IP/submask/gateway manually.  If you select the DHCP mode, you can view the IP/submask/gateway from the DHCP.  If you switch from the DHCP mode to the static mode, you need to reset the IP parameters.
  • Page 188 number if necessary. HTTP port The default value is 80. You can input the actual port number if necessary. HTTPS The default value is 443. You can input the actual port number if necessary. RTSP port The default value is 554. 5.8.2.3 WIFI Please note this function is for the device of WIFI module.
  • Page 189 Please refer to the following sheet for detailed information. Parameter Function WLAN type Here you can select 3G network type to distinguish the 3G module from different ISP. The types include WCDMA， CDMA1x and etc. APN/Dial No. Here is the important parameter of PPP. Authorization It includes PAP,CHAP,NO_AUTH.
  • Page 190 Figure 5-30 5.8.2.6 DDNS The DDNS interface is shown as in Figure 5-31. The DDNS is to set to connect the various servers so that you can access the system via the server. Please go to the corresponding service website to apply a domain name and then access the system via the domain.
  • Page 191 2) Function Introduction The quick DDNS client has the same function as other DDNS client end. It realizes the bonding of the domain name and the IP address. Right now, current DDNS server is for our own devices only. You need to refresh the bonding relationship of the domain and the IP regularly.
  • Page 192 5.8.2.8 Email The email interface is shown as in Figure 5-33. Figure 5-33 Please refer to the following sheet for detailed information. Parameter Function Please check the box here to enable email function. Enable Input server address and then enable this function. SMTP Server Port Default value is 25.
  • Page 193 Parameter Function function is very useful when there are too many emails activated by the abnormity events, which may result in heavy load for the email server. Please check the box here to enable this function. Health mail enable This function allows the system to send out the test email to Update period check the connection is OK or not.
  • Page 194 Figure 5-35 5.8.2.11 SNMP The SNMP interface is shown as in Figure 5-36. The SNMP allows the communication between the network management work station software and the proxy of the managed device. It is reserved for the 3 party to develop. Figure 5-36 Please refer to the following sheet for detailed information.
  • Page 195 Parameter Function and one group of the managers. Please make sure the device and the proxy are the same. The read community will read/write/access all the objects the SNMP supported in the specified name. The default setup is write. The destination address of the Trap information from the proxy Trap address program of the device.
  • Page 196 5.8.2.14 Alarm Centre The alarm centre interface is shown as below. See Figure 5-39. This interface is reserved for you to develop. System can upload alarm signal to the alarm centre when local alarm occurs. Before you use alarm centre, please set server IP, port and etc. When an alarm occurs, system can send out data as the protocol defined, so the client-end can get the data.
  • Page 197 Figure 5-41 You can see the corresponding prompt. See Figure 5-42. Now the server certificate is successfully created. Figure 5-42 5.8.2.15.2 Download root certificate In Figure 5-40, click button, system pops up a dialogue box. See Figure 5-43. Figure 5-43 Click Open button, you can go to the following interface.
  • Page 198 Figure 5-44 Click Install certificate button, you can go to certificate wizard. See Figure 5-45. Figure 5-45 Click Next button to continue. Now you can select a location for the certificate. See Figure 5-46.
  • Page 199 Figure 5-46 Click Next button, you can see the certificate import process is complete. See Figure 5-47. Figure 5-47 Click Finish button, you can see system pops up a security warning dialogue box. See Figure 5-48.
  • Page 200 Figure 5-48 Click Yes button, system pops up the following dialogue box, you can see the certificate download is complete. See Figure 5-49. Figure 5-49 5.8.2.15.3 View and set HTTPS port From Setup->Network->Connection, you can see the following interface. See Figure 5-50. You can see HTTPS default value is 443.

  • Page 201: Event

    5.8.3 Event 5.8.3.1 Video detect 5.8.3.1.1 Motion Detect The motion detect interface is shown as in Figure 5-51. Figure 5-51 Figure 5-52...
  • Page 202 Figure 5-53 Figure 5-54 Please refer to the following sheet for detailed information. Parameter Function Enable You need to check the box to enable motion detection function. Please select a channel from the dropdown list.
  • Page 203 Parameter Function Period Motion detection function becomes activated in the specified periods. See Figure 5-52. There are six periods in one day. Please draw a circle to enable corresponding period. Click OK button, system goes back to motion detection interface, please click save button to exit.
  • Page 204 Here you can set PTZ movement when alarm occurs. Such as go Activation to preset X. See Figure 5-54. Video Matrix This function is for motion detect only. Check the box here to enable video matrix function. Right now system supports one-channel tour function.
  • Page 205 Figure 5-56 5.8.3.2 Alarm Before operation, please make sure you have properly connected alarm devices such as buzzer. The input mode includes local alarm and network alarm. 5.8.3.2.1 Local Alarm The local alarm interface is shown as in Figure 5-57. It refers to alarm from the local device.
  • Page 206 Figure 5-58 Figure 5-59 Please refer to the following sheet for detailed information. Parameter Function Enable You need to check the box to enable this function. Please select a channel from the dropdown list. Period This function becomes activated in the specified periods. There are six periods in one day.
  • Page 207 Parameter Function whole week. Click OK button, system goes back to local alarm interface, please click save button to exit. System only memorizes one event during the anti-dither Anti-dither period. The value ranges from 5s to 600s. There are two options: NO/NC. Sensor type Record channel System auto activates motion detection channel(s) to...
  • Page 208 Figure 5-60 5.8.3.2.3 IPC External Alarm IPC external alarm interface is shown as below. See Figure 5-61. For setup information, please refer to chapter 5.8.3.2.1. Figure 5-61 5.8.3.2.4 IPC Offline Alarm IPC offline alarm is shown as in Figure 5-62 . For setup information, please refer to chapter 5.8.3.2.1.
  • Page 209 Figure 5-62 5.8.3.3 Alarm Output It is to set alarm output mode. See Figure 5-63. Figure 5-63 5.8.3.4 Abnormality It includes two types: HDD error/Network error. HDD error: No disk, disk error, disk no space. See Figure 5-64 and Figure 5-65. Network error: Net disconnection, IP conflict and MAC conflict.
  • Page 210 Figure 5-64 Figure 5-65 Figure 5-66 Please refer to the following sheet for detailed information. Parameter Function Event The abnormal events include: No disk, disk error, disk no space, net Type disconnection, IP conflict and MAC conflict. You can set one or more items here. Less than: You can set the minimum percentage value here (For disk not space only).

  • Page 211: Storage

    Parameter Function Show System can pop up a message to alarm you in the local host screen if message you enabled this function. Alarm System can upload the alarm signal to the centre (Including alarm upload centre. Send If you enabled this function, System can send out an email to alert you Email when an alarm occurs.
  • Page 212 Figure 5-68 Figure 5-69 Please refer to the following sheet for detailed information. Parameter Function Channel Please select a channel from the dropdown list. Pre-record Please input pre-record time here. The value ranges from 0 to 30.

  • Page 213: Local Storage

    Parameter Function Redundancy Check the box here to enable redundancy function. Please note this function is null if there is only one HDD. Snapshot Check the box here to enable snapshot function. Holiday Check the box here to enable holiday function. Setup Click the Setup button, you can set record period.
  • Page 214 Figure 5-71 5.8.4.3 Manual Record The interface is shown as in Figure 5-72. Figure 5-72 Please refer to the following sheet for detailed information. Parameter Function Here you can view channel number. Channel The number displayed here is the max channel amount of your device.
  • Page 215 5.8.4.4.1 Main Stream The main stream interface is shown as in Figure 5-73. Here you can set corresponding HDD group to save main stream. Figure 5-73 5.8.4.4.2 Sub Stream The sub stream interface is shown as in Figure 5-74. Here you can set corresponding HDD group to save sub stream. Figure 5-74 5.8.4.4.3 Snapshot The snapshot interface is shown as in Figure 5-75.

  • Page 216: Setting

    5.8.4.5 Quota It is to set channel storage capacity. See Figure 5-76. Select a channel from the dropdown list and then select corresponding HDD quota. Figure 5-76 5.8.5 Setting 5.8.5.1 General The general interface includes general, date/time and holiday setup. 5.8.5.1.1 General The general interface is shown as in Figure 5-77.
  • Page 217 Standard Here is for you to select working mode when hard disk is full. There HDD full are two options: stop recording or rewrite. If current working HDD is overwritten or the current HDD is full while the next HDD is no empty, then system stops recording, If the current HDD is full and then next HDD is not empty, then system overwrites the previous files.
  • Page 218 Holiday setup interface is shown as in Figure 5-79. Here you can click Add box to add a new holiday and then click Save button to save. Figure 5-79 5.8.5.2 Display Display interface includes GUI, TV adjust, Tour and zero-channel encoding. 5.8.5.2.1 GUI Here you can set background color and transparency level.
  • Page 219 Figure 5-81 5.8.5.2.3 Tour The tour interface is shown as in Figure 5-82. Here you can set tour interval, split mode, motion detect tour and alarm tour mode. Figure 5-82 Please refer to the following sheet for detailed information. Parameter Function Check the box here to enable tour function.

  • Page 220: Video Matrix

    Figure 5-83 Please refer to the following sheet for detailed information. Parameter Function This function is disabled by default. Check the box here to enable Enable this function so that you can control the zero-channel encoding function at the WEB. Compression System default setup is H.264.
  • Page 221 Figure 5-84 5.8.5.3.2 HDMI This function is for some series only. The HDMI interface is shown as in Figure 5-85. It is to set the HD video matrix output tour function of the HDMI port 2. You can set tour channel, resolution, and interval. System support 1/4-window tour.
  • Page 222 The RS232 interface is shown as in Figure 5-86. Figure 5-86 Please refer to the following sheet for detailed information. Parameter Function Select the corresponding dome protocol. Protocol Default setup is console. Select the baud rate. Baud Rate Default setup is 115200. Data Bit The value ranges from 5 to 8.
  • Page 223 Figure 5-87 Please refer to the following sheet for detailed information. Parameter Function Select speed dome connected channel. Channel There are two modes:Local/remote. PTZ type Please select corresponding protocol from the dropdown list. Protocol Set corresponding dome address. Default value is 1. Please note Address your setup here shall comply with your dome address;...
  • Page 224  Overlay mode: There are two options: preview and encode. Preview means overlay the card number in the local monitor video. Encode means overlay the card number in the record file.  Overlay Position: Here you can select the proper overlay position from the dropdown list.
  • Page 225 For the ATM/POS without the protocol, the interface is shown as in Figure 5-90. Source IP refers to host IP address that sends out information (usually it is the device host.) Destination IP refers to other systems that receive information. Usually you do not need to set source port and target port.
  • Page 226 Figure 5-92 5.8.5.7.2 Schedule It is to set schedule broadcast function. You can play the different audio files in the specified periods. See Figure 5-93. Figure 5-93 5.8.5.8 Account Note:  For the character in the following user name or the user group name, system max supports 6-digits.
  • Page 227  User management adopts group/user modes. The user name and the group name shall be unique. One user shall be included in only one group. 5.8.5.8.1 User name In this interface you can add/remove user and modify user name. See Figure 5-94. Figure 5-94 Add user: It is to add a name to group and set the user rights.
  • Page 228 Figure 5-95 Modify user It is to modify the user property, belonging group, password and rights. See Figure 5-96. Modify password It is to modify the user password. You need to input the old password and then input the new password twice to confirm the new setup. Please click the OK button to save. Please note, the password ranges from 1-digit to 6-digit.
  • Page 229 Figure 5-96 5.8.5.8.2 Group The group management interface can add/remove group, modify group password and etc. The interface is shown as in Figure 5-97. Figure 5-97 Add group: It is to add group and set its corresponding rights. See Figure 5-98. Please input the group name and then check the box to select the corresponding rights.
  • Page 230 includes: shutdown/reboot device, live view, record control, PTZ control and etc. Figure 5-98 Modify group Click the modify group button, you can see an interface is shown as in Figure 5-99. Here you can modify group information such as remarks and rights. Figure 5-99...
  • Page 231 5.8.5.9 Auto maintain The auto maintain interface is shown as in Figure 5-100. Here you can select auto reboot and auto delete old files interval from the dropdown list. If you want to use the auto delete old files function, you need to set the file period. Click Manual reboot button, you can restart device manually.

  • Page 232: Information

    5.8.5.12 Upgrade The upgrade interface is shown as in Figure 5-103. Please select the upgrade file and then click the update button to begin update. Please note the file name shall be as *.bin. During the upgrade process, do not unplug the power cable, network cable, or shutdown the device.

  • Page 233: Connection Log

    Figure 5-105 Please refer to the following sheet for log parameter information. Parameter Function Log types include: system operation, configuration operation, data Type operation, event operation, record operation, user management, log clear. Set the start time of the requested log. Start time Set the end time of the requested log.

  • Page 234: Online User

    Figure 5-106 5.9.4 Online User The online user interface is shown as in Figure 5-107. Figure 5-107 5.10 Playback Click Playback button, you can see an interface is shown as in Figure 5-108. Please set record type, record date, window display mode and channel name. You can click the date on the right pane to select the date.
  • Page 235 Figure 5-108 Then please click File list button, you can see the corresponding files in the list. See Figure 5-109. Figure 5-109 Select a file you want to play and then click Play button, system can begin playback. You can select to playback in full-screen. Please note for one channel, system can not...
  • Page 236 playback and download at the same time. You can use the playback control bar to implement various operations such as play, pause, stop, slow play, fast play and etc. See Figure 5-110. Figure 5-110 Select the file(s) you want to download and then click download button, you can see an interface shown as in Figure 5-111.
  • Page 237 Figure 5-111 HD Transcoding When the bandwidth is limited, you can use this function to transfer the HD bit stream to the specified lower resolution and then playback. It is to reduce network load. In Figure 5-108, select the playback period and then select playback mode and channel(s). Check the box to enable HD transcoding function and then click the Set button;...

  • Page 238: Alarm

    Figure 5-114 Watermark Watermark interface is shown as In Figure 5-113. Please select a file and then click Verify button to see the file has been tampered with or not Figure 5-115 5.11 Alarm Click alarm function, you can see an interface is shown as Figure 5-116. Here you can set device alarm type and alarm sound setup (Please make sure you have enabled audio function of corresponding alarm events.).

  • Page 239: Log Out

    Figure 5-116 Please refer to the following sheet for detailed information. Type Parameter Function Alarm Video loss System alarms when video loss occurs. Type Motion detection System alarms when motion detection alarm occurs. Tampering System alarms when camera is viciously masking. Disk full System alarms when disk is full.

  • Page 240: Un-Install Web Control

    Figure 5-117 5.13 Un-install Web Control You can use web un-install tool “uninstall web.bat” to un-install web control. Please note, before you un-installation, please close all web pages, otherwise the un-installation might result in error.

  • Page 241: Professional Surveillance System

    6 Professional Surveillance System Besides Web, you can use our Professional Surveillance Software (PSS) to login the device. For detailed information, please refer to PSS user’s manual.

  • Page 242: Faq

    7 FAQ 1. DVR can not boot up properly. There are following possibilities:  Input power is not correct.  Power connection is not correct.  Power switch button is damaged.  Program upgrade is wrong.  HDD malfunction or something wrong with HDD ribbon. ...
  • Page 243  DVR and monitor resistance is not compatible.  Video transmission is too long or degrading is too huge.  DVR color or brightness setup is not correct. 6. Can not search local records. There are following possibilities:  HDD ribbon is damaged. ...
  • Page 244  PTZ decoder setup, connection or installation is not correct.  Cable connection is not correct.  PTZ setup is not correct.  PTZ decoder and DVR protocol is not compatible.  PTZ decoder and DVR address is not compatible. ...
  • Page 245  MAC address conflict.  PC or DVR network card is not good. 16. Burn error /USB back error. There are following possibilities:  Burner and DVR are in the same data cable.  System uses too much CPU resources. Please stop record first and then begin backup.
  • Page 246  Camera quality is too low. Lens is dirty. Camera is installed against the light. Camera aperture setup is not correct.  HDD capacity is not enough.  HDD is damaged. 22. Can not playback the downloaded file. There are following possibilities: ...

  • Page 247: Daily Maintenance

    29. After I connected to the IP channel, there multiple-window output is OK, but there is no one-window output. There are following possibilities:  Check there is video from the IP channel or not. Please go to the main menu->info->System->BPS to view bit stream real-time information. ...

  • Page 248: Appendix A Hdd Capacity Calculation

    Appendix A HDD Capacity Calculation Calculate total capacity needed by each DVR according to video recording (video recording type and video file storage time). Step 1: According to Formula (1) to calculate storage capacity that is the capacity of each channel needed for each hour, unit Mbyte. ...
  • Page 249 448K 196M 512K 225M 640K 281M 768K 337M 896K 393M 1024K 450M 1280K 562M 1536K 675M 1792K 787M 2048K 900M...

  • Page 250: Appendix B Compatible Backup Devices

    Appendix B Compatible backup devices Appendix B-1 Compatible USB list Manu factor Model Capacity Sandisk Cruzer Micro 512M Sandisk Cruzer Micro Sandisk Cruzer Micro Sandisk Cruzer Freedom 256M Sandisk Cruzer Freedom 512M Sandisk Cruzer Freedom Sandisk Cruzer Freedom DataTraveler Ⅱ Kingston DataTraveler Ⅱ...

  • Page 251: Appendix B-2 Compatible Sd Card List

    Kingston Data Traveler 32GB Aigo L8315 16GB Sandisk 16GB Kingston Data Traveler Locker+ 32GB Netac U228 Appendix B-2 Compatible SD Card list Brand Standard Capacity Card type Transcend SDHC6 16GB Kingston SDHC4 Kingston Kingston Sandisk SDHC2 Small Sandisk Small Appendix B-3 Compatible Portable HDD list Brand Model Capacity...
  • Page 252 Samsung TS-H653 Ver.F Samsung SH-224BB/CHXH SONY DRU-V200S SONY DRU-845S SONY AW-G170S Pioneer DVR-217CH Appendix B-6 Compatible SATA HDD List NOTE: Please upgrade the DVR firmware to latest version to ensure the accuracy of the table below. Here we recommend HDD of 500G to 4T capacity. Port Manufacturer Series...
  • Page 253 Seagate Seagate Pipeline HD2 ST31000322CS SATA Seagate Seagate Pipeline HD2 ST1000VM002 SATA Seagate Seagate Pipeline HD2 ST1500VM002 SATA Seagate Seagate Pipeline HD2 ST2000VM002 SATA Seagate Seagate Pipeline HD2 ST2000VM003 SATA Seagate Seagate Constellation ST3500514NS 500G SATA Seagate Seagate Constellation ST31000524NS SATA Seagate Seagate Constellation...
  • Page 254 Westem Digital Cariar SE WD2500JS 250G SATA Westem Digital Cariar SE16 WD7500KS 750G SATA Westem Digital Cariar SE16 WD5000KS 500G SATA Westem Digital Cariar SE16 WD4000KD 400G SATA Westem Digital Cariar SE16 WD3200KS 320G SATA Westem Digital Cariar SE16 WD2500KS 250G SATA Westem Digital...
  • Page 255 Hitachi HitachiCinemaStar™ HCP725050GLA380 500G SATA 5K500 Hitachi HitachiCinemaStar™ HCT721050SLA360 500G SATA 7K1000.B Hitachi HitachiCinemaStar™ HCT721075SLA360 750G SATA 7K1000.B Hitachi HitachiCinemaStar™ HCT721010SLA360 SATA 7K1000.B Maxtor DiamondMax 20 STM3320820AS 320G SATA Maxtor DiamondMax 20 STM3250820AS 250G SATA...

  • Page 256: Compatible Cd/Dvd Burner List

    Appendix C Compatible CD/DVD Burner List NOTE: Please upgrade the DVR firmware to latest version to ensure the accuracy of the table below. And you can use the USB cable with the model recommended to set USB burner. Manufacturer Model Port Type Type Sony...

  • Page 257: Appendix D Compatible Displayer List

    Appendix D Compatible Displayer List Please refer to the following sheet form compatible displayer list. Brand Model Dimension (Unit: inch) BENQ（LCD） ET-0007-TA 19-inch (wide screen) DELL（LCD） E178FPc 17-inch BENQ（LCD） Q7T4 17-inch BENQ（LCD） Q7T3 17-inch HFNOVO（LCD） LXB-L17C 17-inch 22 寸(wide screen) SANGSUNG（LCD）...

  • Page 258: Appendix E Compatible Switcher

    Appendix E Compatible Switcher Brand Model network working mode D-LinK DES-1016D 10/100M self-adaptive D-LinK DES-1008D 10/100M self-adaptive Five network modes 1. AUTO 2. HALF-10M Ruijie RG-S1926S 3. FULL-10M 4 .HALF-100M 5. FULL-100M H3C-S1024 10/100M self-adaptive TP-LINK TL-SF1016 10/100M self-adaptive TP-LINK TL-SF1008+ 10/100M self-adaptive...

  • Page 259: Appendix F Compatible Wireless Mouse List

    Appendix F Compatible Wireless Mouse List Please refer to the following sheet for compatible SD card brand. Brand Model Rapoo 3500 Logitech M215 Shuangfeiyan Tianyao G7-630...
  • Page 260 Appendix G Earthing 1. What is the surge? Surge is a short current or voltage change during a very short time. In the circuit, it lasts for microsecond. In a 220V circuit, the 5KV or 10KV voltage change during a very short time (about microseconds) can be called a surge.
  • Page 261  Signal lightning arrester: This device is mainly used in the PC network, communication system. The connection type is serial connection. Once you connected the signal lightning arrestor with the signal port, it can cut the channel of the thunderstorm to the device, and on the other hand, it can discharge the current to the ground to guarantee the device proper work.
  • Page 262 conductance of the ground conductor. In the high-frequency circuit, you need to use the multiple-point ground mode and each cable needs to connect to the ground. The length shall be less than the 1/20 of the signal wavelength. Mixed ground: The mix ground consists of the feature of the one-point ground and multiple-point ground.
  • Page 263  The thunder proof ground shall adopt the special ground cable from the monitor control room to the ground object. The ground cable adopts copper insulation cable or wire and its ground section shall be more than 20mm2.  The ground cable of the monitor system can not short circuit or mixed connected with the strong alternative current cable.
  • Page 264 For L (live cable) Turn the digital multimeter to 750V AC, use your one hand to hold the metal end, and then the other hand insert the pen to the L port of the socket. See the following figure. If the multimeter shows 120, then you can see current live cable connection is standard.

  • Page 266: Appendix H Toxic Or Hazardous Materials Or Elements
