- Page 1 All manuals and user guides at all-guides.com WASHING MACHINE ZWF 1421S ZWF 1521W ZWF 1621S ZWF 1621W Spin Programme ZWF 1621 Whites 95° Handwash 30° Whites Economy 60° Wool 40° Coloured Economy 40° Wool Cold Colour care 30° Miniprogram 30°/30’...
-
Page 2: Important Safety Information
All manuals and user guides at all-guides.com Important Safety Information It is most important that this instruction book should be retained with the appliance for future reference. Should the appliance be sold or transferred to another owner, or should you move house and leave the appliance, always ensure that the book is supplied with the appliance in order that the new owner can get to know the functioning of the appliance and the relevant warnings. -
Page 3: Table Of Contents
All manuals and user guides at all-guides.com Contents For the User Washing Hints 13-14 Which detergent?..Important Safety Information And in which form? Your New Washing Machine Wash Care Symbols Description of the Appliance Washing Programmes 16-17 Detergent dispenser drawer Maintenance and Cleaning 18-19 Child safety feature... -
Page 4: Your New Washing Machine
All manuals and user guides at all-guides.com Your New Washing Machine Your new washing machine meets all modern requirements for effective treatment of laundry with low water, energy and detergent consumption. ● The programme selector dial combines the In the interest function of programme and temperature selection, of the environment making it easier to set the programme. -
Page 5: Description Of The Appliance
All manuals and user guides at all-guides.com Description of the Appliance 1Detergent dispenser drawer 2 Programme guide 3 Control panel 4 Door opening handle 5 Drain pump 6 Adjustable feet Detergent dispenser drawer Prewash Main wash Fabric softener C0063 Child safety feature This machine incorporates a special child safety feature to prevent small children from being trapped inside the machine. -
Page 6: The Control Panel
All manuals and user guides at all-guides.com The Control Panel ZWF 1621W Spin Programme ZWF 1621 Whites 95° Handwash 30° Whites Economy Wool 60° 40° Coloured Economy 40° Wool Cold Colour care Miniprogram 30° 30°/30’ Synthetics 60° Rinses Synthetics Drain 12 H 40°... -
Page 7: Programme Progress Display
All manuals and user guides at all-guides.com 8 Spin speed selector dial • set the washing machine to PAUSE by pressing the Start/Pause button; This dial allows you to reduce the final and the • press the Delay Start button once, the light relevant to intermediate spin speeds or to select the NO SPIN or the selected delay goes off . -
Page 8: Programme Information
All manuals and user guides at all-guides.com Drain Programme For emptying out the water of the last rinse in programmes with the RINSE HOLD option. Turn first the programme selector dial to O, then select Drain programme and depress the Start/Pause button. -
Page 9: Operating Sequence
Open the door by carefully pulling the door handle Turn the selector dial to the required position. outwards. ZWF 1421S ZWF 1521W Place the laundry in the drum, one item at a time, shaking them out as much as possible. Close the door. -
Page 10: Select The Required Option
All manuals and user guides at all-guides.com 6. Select the Delay Start Start the new programme by depressing the “Start/Pause” button. Before you start the programme, if you wish to delay the start, press the Delay Start button repeatedly, to 9. -
Page 11: Washing 2.5 Kg Of Mixed Fabrics At 40°C
All manuals and user guides at all-guides.com 4. Select the required WASHING 2.5 KG OF MIXED FABRICS AT 40°C programme Suppose you have 2.5 kg of lightly soiled mixed fabrics to wash. They are rather delicate fabrics and should not Turn the programme selector dial to the 40 programme be washed at a high temperature. -
Page 12: Start The Machine
All manuals and user guides at all-guides.com 7. Start the machine 8. At the end of the programme Before starting up the machine check that: The machine stops automatically. ● the appliance is plugged in If the RINSE HOLD option has been selected, the ●... -
Page 13: Washing Hints
All manuals and user guides at all-guides.com Washing Hints Do NOT overload the machine. Weigh the laundry the Very small items (handkerchiefs, ribbons, socks etc) first few times you use the appliance. should be washed in a washing bag or a pillow case. ●... -
Page 14: Which Detergent
All manuals and user guides at all-guides.com And in which form? Which detergent?..Not only are there different types of detergent, but they To ensure you obtain the best wash results from your are also available in different forms. Whether you chose appliance, it is important to use the right detergent in a powder or liquid in traditional or compact form is your everyday wash, and only detergents recommended... -
Page 15: Wash Care Symbols
All manuals and user guides at all-guides.com Wash Care Symbols Wash care labels inside garments recommend how to launder your clothes with the best results. The care labelling code is in line with care labelling used in the rest of Europe. The symbols used make it easy to select the correct programme on your washing machine. -
Page 16: Washing Programmes
All manuals and user guides at all-guides.com Washing Programmes Programmes for cotton and linen and synthetics Progr. Degree of soil Wash programme/ Programme Max. Possible time Description and type of laundry Washing symbol dial position options load mins. Wash at 95°C Prewash For heavy soiled cotton Whites... - Page 17 All manuals and user guides at all-guides.com Washing Programmes Programmes for delicates , handwash wool and Miniprogram Progr. Programme Wash programme/ Degree of soil Max. Possible Description time Washing symbol and type of laundry dial position load options mins. Wash at 40 °C Prewash Delicate fabrics, for 3 rinses...
-
Page 18: Maintenance And Cleaning
All manuals and user guides at all-guides.com Maintenance and Cleaning Before any maintenance or cleaning is carried out you must DISCONNECT the appliance from the electricity supply. Descaling The water we use normally contains lime. It is a good idea to periodically use a water softening powder in the C0067 C0066 machine. -
Page 19: Cleaning The Water Inlet Filter
All manuals and user guides at all-guides.com up spillage of water when removing the cover. Clean the filter using a hard bristle brush. Tighten up the inlet hose. P1115 P1090 Remove any objects from the pump impeller by • rotating it. The dangers of freezing If the machine is exposed to temperatures below 0°C, certain precautions should be taken. -
Page 20: Something Not Working
All manuals and user guides at all-guides.com Something Not Working Certain problems are due to lack of simple maintenance or oversights, which can be solved easily without calling out an engineer. Before contacting your local Service Force Centre, please carry out the checks listed below. During machine operation it is possible that the “End”... -
Page 21: Service And Spare Parts
For Customer Service in Ireland please contact us at the guarantee service calls. address below: Zanussi Electrolux-Electrolux Group (Irl) Ltd Long Mile Road - Dublin 12 Republic of Ireland Tel: +353 (0)1 4090751 Email: service.eid@electrolux.ie Mod. -
Page 22: Customer Care Department
Standard guarantee conditions ● Appliances found to be in use within a commercial environment, plus those which are subject to rental We, Zanussi Electrolux, undertake that if, within 12 agreements. months of the date of the purchase, this ZANUSSI ●... -
Page 23: Installation Instructions
All manuals and user guides at all-guides.com Installation Instructions It is dangerous to alter the specifications or attempt to modify this product in any way. Care must be taken to ensure that the appliance does not stand on the electrical supply cable. Any electrical work required to install this appliance should be carried out by a qualified electrician or competent person. -
Page 24: Unpacking
All manuals and user guides at all-guides.com Unpacking All transit bolts and packing must be removed before using the appliance. You are advised to keep all the packaging for re-use in case the machine is to be transported again. Using a spanner unscrew and remove the two rear bottom screws. -
Page 25: Water Inlet
All manuals and user guides at all-guides.com Water inlet Connect the hose to a tap with a 3/4” thread. Do not use previously used hoses for water connection. “U” piece supplied P1199 Place the drain hose into your standpipe, which should have an internal diameter of approximately 38mm thus P1088 ensuring there is an air break between the drain hose... -
Page 26: Levelling
All manuals and user guides at all-guides.com 2. Onto a sink outlet spigot. If the outlet spigot has not been used before, remove any blanking plug that may be in place. P1051 Any necessary adjustment can be made with a spanner. Accurate levelling prevents vibration, noise and P1197 displacement of the machine during operation. -
Page 27: Electrical Connection
All manuals and user guides at all-guides.com The wires in the mains lead are coloured in accordance with the following code: Green and Yellow - Earth Blue - Neutral Brown - Live GREEN & YELLOW SHOWER SINK TOILET BATH BIDET WASHING MACHINE DISHWASHER... - Page 28 All manuals and user guides at all-guides.com From the Electrolux Group. The world’s No. 1 choice The Electrolux Group is the world's largest producer of powered appliances for kitchen, cleaning and outdoor use. More than 55 million Electrolux Group products (such as refrigerators, cookers, washing machines, vacuum cleaners, chain saws and lawn mowers) are sold each year to a value of approx.
