Page 1: Washing Machine
Ofrecido por www.electromanuales.com WASHING MACHINE ZWF 1011 W INSTRUCTION BOOKLET 35.292.995/1... -
Page 2: Important Safety Information
Always unplug the appliance and turn off the water malfunctioning. Contact your local Zanussi supply after use. Electrolux Service Centre. Always insist on genuine ● Do not overload the appliance. See relevant section Zanussi Electrolux spare parts. in the instruction book. -
Page 3: Table Of Contents
Ofrecido por www.electromanuales.com For the User Maintenance and Cleaning 17-18 Descaling Important Safety Information After each wash Your New Washing Machine Maintenance Wash External cleaning Description of the Appliance Cleaning the dispenser drawer Door locked light Cleaning the drawer recess Detergent dispenser drawer Cleaning the pump Child Safety Feature... -
Page 4: Your New Washing Machine
Ofrecido por www.electromanuales.com Your New Washing Machine Your new washing machine meets all modern requirements for effective treatment of laundry with low water, energy and detergent consumption. ● The programme selector dial combines the In the interest function of programme and temperature selection, of the environment making it easier to set the programme. -
Page 5: Description Of The Appliance
Ofrecido por www.electromanuales.com Description of the Appliance 1 Detergent dispenser drawer 2 Programme guide 3 Control panel 4 Door opening handle 5 Drain pump 6 Adjustable feet Detergent dispenser drawer Prewash Main wash Fabric softener C0069... -
Page 6: The Control Panel
Ofrecido por www.electromanuales.com The Control Panel 1 Programme guide 3 Prewash button Select this option if you wish your laundry to be Programme Option buttons prewashed before the main wash (not available for wool). The prewash ends with a short spin in programmes for Depending on the programme, different functions can cotton and synthetic fabrics, whereas in the programme be combined. -
Page 7: Programme Information
Ofrecido por www.electromanuales.com ATTENTION! If you turn the programme selector dial to another programme when the machine is working, the lights of the programme progress display start to flash. The machine will not perform the new selected programme. Programme information After the machine has started, only the running phase Wool pilot light stays on. -
Page 8: Operating Sequence
Ofrecido por www.electromanuales.com Operating Sequence Before the first wash, we recommend that you pour 2 3. Select the required programme litres of water into the main wash compartment Turn the programme selector dial to the programme the detergent drawer in order to activate the ECO valve. The light “Start / Pause”... -
Page 9: Start The Programme
Ofrecido por www.electromanuales.com 6. Start the programme 10.Opening the door after the programme has started Before starting the machine check that: ● the appliance is plugged in First set the machine to pause by pressing the “Start / Pause” button. Wait two or three minutes for the door ●... -
Page 10: Washing 2 Kg Of Mixed Fabrics At 50°C
Ofrecido por www.electromanuales.com WASHING 2 KG OF MIXED FABRICS AT 50°C 4. Select the required programme Suppose you have 2 kg of lightly soiled mixed fabrics to wash. They are rather delicate fabrics and should not be Turn the programme selector dial to the programme washed at a high temperature. -
Page 11: At The End Of The Programme
Ofrecido por www.electromanuales.com To start the selected programme, press the “Start / Pause” button; the corresponding light stops flashing. Only the “washing” pilot light stays on. The machine starts operating. 8. At the end of the programme The machine stops automatically. If the (rinse hold) option has been selected, the phase light “End”... -
Page 12: Washing Hints
Ofrecido por www.electromanuales.com ● Do NOT overload the machine. Weigh the laundry the For wool, use gentle detergent only in small first few times you use the appliance. quantities. ● Bleach is very corrosive; it should be used with care The average weights of the most common items are and kept out of reach of children. -
Page 13: Which Detergent
Ofrecido por www.electromanuales.com And in which form? Which detergent?..Not only are there different types of detergent, but they To ensure you obtain the best wash results from your are also available in different forms. Whether you chose appliance, it is important to use the right detergent in a powder or liquid in traditional or compact form is your everyday wash, and only detergents recommended your own personal choice. -
Page 14: Wash Care Symbols
Ofrecido por www.electromanuales.com Wash care labels inside garments recommend how to launder your clothes with the best results. The care labelling code is in line with care labelling used in the rest of Europe. The symbols used make it easy to select the correct programme on your washing machine. -
Page 15: Washing Programmes
Ofrecido por www.electromanuales.com Washing Programmes Programmes for cotton and linen Progr. Wash programme/ Degree of soil Programme Max. Possible time Description Washing symbol and type of laundry dial position options load mins. Wash at 90°C For heavy soiled cotton 5 kg WHITES 3 rinses Prewash... - Page 16 Ofrecido por www.electromanuales.com Programmes for synthetics, mixed fabrics, delicates and wool Progr. Programme Wash programme/ Degree of soil Possible Max. Description time Washing symbol and type of laundry dial position options load mins. COLOUR-FAST Wash at 60 °C FABRICS Synthetic or mixed Wash at 50 °C MINIMUM IRON fabrics, underwear,...
-
Page 17: Maintenance And Cleaning
Ofrecido por www.electromanuales.com Maintenance and Cleaning Before any maintenance or cleaning is carried out you must DISCONNECT the appliance from the electricity supply. Descaling The water we use normally contains lime. It is a good idea to periodically use a water softening powder in the C0072 C0073 machine. -
Page 18: Cleaning The Water Inlet Filter
Ofrecido por www.electromanuales.com • When no more water comes out, unscrew the pump Clean the filter using a hard bristle brush. cover and remove it. Always keep a cloth nearby to Tighten up the inlet hose. dry up spillage of water when removing the cover. P1090 P1115 The dangers of freezing... - Page 19 Ofrecido por www.electromanuales.com Certain problems are due to lack of simple maintenance or oversights, which can be solved easily without calling out an engineer. Before contacting your local Service Force Centre, please carry out the checks listed below. During machine operation it is possible that the “End” light flashes to indicate that the machine is not working. •...
-
Page 20: Something Not Working
4. The model and serial number of the appliance (found Service Force Centre covering your post code area. on the rating plate - see picture). For the address of your local Zanussi Electrolux Service 5. The purchase date Force Centre and further information about Service... -
Page 21: Guarantee Conditions
● Appliances found to be in use within a commercial Standard guarantee conditions environment, plus those which are subject to rental We, Zanussi Electrolux undertake that if, within 12 agreements. months of the date of the purchase, this Zanussi ●... -
Page 22: Installation Instructions
Ofrecido por www.electromanuales.com Installation Instructions It is dangerous to alter the specifications or attempt to modify this product in any way. Care must be taken to ensure that the appliance does not stand on the electrical supply cable. Any electrical work required to install this appliance should be carried out by a qualified electrician or competent person. -
Page 23: Unpacking
Ofrecido por www.electromanuales.com Unpacking ■ Plug the 3 holes with the plastic plugs which you All transit bolts and packing must be removed can find in the envelope containing the instruction before using the appliance booklet. You are advised to keep all the packaging for re-use in case the appliance has to be transported again. -
Page 24: Water Inlet
Ofrecido por www.electromanuales.com Water inlet Connect the hose to a tap with a 3/4” thread. Do not use previously used hoses for water connection. “U” piece supplied P1199 Place the drain hose into your standpipe, which should have an internal diameter of approximately 38mm thus P1088 ensuring there is an air break between the drain hose and standpipe. -
Page 25: Levelling
Ofrecido por www.electromanuales.com 2. Onto a sink outlet spigot. If the outlet spigot has not been used before, remove any blanking plug that may be in place. P1051 Any necessary adjustment can be made with a spanner. Accurate levelling prevents vibration, noise and P1197 displacement of the machine during operation. -
Page 26: Electrical Connection
Ensure that the cut off plug is disposed of safely. Should the appliance power supply cable need to be replaced, this should be carried out by your local Zanussi Electrolux Service Force Centre. Note When the appliance is installed the power supply cable must be accessible. - Page 27 Ofrecido por www.electromanuales.com...
- Page 28 Ofrecido por www.electromanuales.com From the Electrolux Group. The world’s No. 1 choice The Electrolux Group is the world's largest producer of powered appliances for kitchen, cleaning and outdoor use. More than 55 million Electrolux Group products (such as refrigerators, cookers, washing machines, vacuum cleaners, chain saws and lawn mowers) are sold each year to a value of approx.
