Adjusting The Monitor - Asus ROG STRIX OLED XG32UCWG User Manual

• The VESA wall mount kit (100 x 100 mm) is purchased separately.
• Use only the UL Listed Wall Mount Bracket with minimum weight/load
22.7kg (Screw size: M4 x 10 mm).
2.4

Adjusting the monitor

• For optimal viewing, we recommend that you look at the full face of the
monitor, then adjust the monitor to the angle that is most comfortable for you.
• Hold the stand to prevent the monitor from falling when you change its angle.
• You can adjust the monitor's angle from +20˚ to -5˚, and it allows 25˚ swivel
adjustment from either left or right. You can also adjust the monitor's height
within 110 mm.
(Tilt)
ASUS XG32UCWG Series OLED Monitor
(Height adjustment)
(Swivel)
110mm
2-3
