- Page 1 88530-BS ROTARY HAMMER 1100W INSTRUCTION MANUAL SAVE THIS MANUAL ! You will need this manual for safety instructions, operating procedures and warranty. Put it and the original sales receipt in a safe dry place for future reference.
-
Page 2: Important Safety Information
SAFETY IMPORTANT SAFETY INFORMATION General Power Tool Safety Warnings WARNING: Read all safety warnings and instructions. Failure to follow the warnings and instructions may result in electric shock, fire and/or serious injury. Save all warnings and instructions for future reference. The term ”power tool“ in the warnings refers to your mains-operated (corded) power tool or battery-operated (cordless) power tool. - Page 3 SAFETY turning the power tool on. A wrench or a key before making any adjustments, changing le attached to a rotating part of the power tool accessories, or storing power tools. Such may result in personal injury. preventive safety measures reduce the risk of 15.
- Page 4 SAFETY Rotary Hammer Safety WARNING complete stop. Moving parts can grab the surface and pull the tool out of your control. 1. Wear ear protectors with rotary hammers. 9. When using a handheld power tool, maintain a Exposure to noise can cause hearing loss. firm grip on the tool with both hands to resist 2.
-
Page 5: Vibration Safety
SAFETY Vibration Safety This tool vibrates during use. Repeated or medical advice as soon as possible. long-term exposure to vibration may cause 2. Do not smoke during use. Nicotine reduces the temporary or permanent physical injury, blood supply to the hands and fingers, particularly to the hands, arms and shoulders. -
Page 6: Specifications
SPECIFICATIONS SPECIFICATIONS WARNING Electrical Rating 230V~50Hz No Load Speed 770/min The electric hammer chisel power tool noise output may exceed 85dB(A) at the Impact Force 4.5J workplace. In this instance, wear ear Input Power 1100W protection. Impact Rate 4200bpm Wear safety-hearing protection Max In Steel 13mm Wear Dust mask... -
Page 7: Before Use
SETUP SETUP Before Use Read the ENTIRE IMPORTANT SAFETY INFORMATION section at the beginning of this manual including all text under subheadings therein before set up or use of this product. WARNING: TO PREVENT SERIOUS INJURY FROM ACCIDENTAL OPERATION: Turn the Power Switch of the tool off... - Page 8 SETUP ACCESSORIES & CARTON CONTENTS DESCRIPTION Rotaryhammer Use only accessories recommended for this Chisels electric hammer chisel. Follow instructions Drill Bits that accompany accessories. Use of improper Grease Tube accessories may cause injury to the operator Wrench or damage to the cordless drill. Auxiliary Handle Do not use any accessory unless you have Carbon Brush...
- Page 9 SETUP OPERATING INSTRUCTIONS Always make sure the power tool is isolated from the power supply before fitting any attachment Handle (Fig1) Always make sure the fixed handle is secure before any job takes place as a loose handle could invite injuries. Fig1 Fitting a chisel bit into the Hex housing (Fig3) Fig3...
- Page 10 SETUP Switching the chisel on/off (Fig2) The chisel has an On/Off switch (Fig 2) built in to the handle. Holding the chisel with both hands simply squeeze the trigger and the motor will start. To switch off release the trigger. Trigger switch Fig2...
-
Page 11: Maintenance And Servicing
MAINTENANCE AND SERVICING MAINTENANCE AND SERVICING This electric hammer chisel does not have reverse direction, so always take care not to force the chisel in case the chisel bit gets stuck. Always make sure you keep the chisel going in and out to remove debris. - Page 12 MAINTENANCE AND SERVICING Hammer chisel prior to operation 1. Power source 3. Power switch Ensure that the power source to be utilized Ensure that the power switch is in the off conforms to the power requirements specified position before any work is carried out on the on the product nameplate.
-
Page 13: Maintenance And Inspection
MAINTENANCE AND SERVICING MAINTENANCE Oil feeding Caution. Prior to oil feeding, always disconnect the rubber packing attached below the oil the plug from the power supply receptacle. Since gauge. an oil chamber is built in this electric hammer 3. Check the oil level once daily, confirming that oil chisel, it can be used for approximately 20 days is filled. - Page 14 MAINTENANCE AND SERVICING Always keep carbon brushes clean and ensure greatly increase the chances of injury. that they slide freely within the brush holders. Replacement steps. Be prepared for binding and bit The carbon brush can be removed by removing breakthrough.
-
Page 15: Troubleshooting
MAINTENANCE AND SERVICING Troubleshooting Problem Possible Causes Likely Solutions Tool will not start. 1. Cord not connected. 1. Check that cord is plugged in. 2. No power at outlet. 2. Check power at outlet. If outlet is 3. Tool’s thermal reset breaker unpowered, turn off... -
Page 16: Ce Declaration Of Conformity
CE DECLARATION OF CONFORMITY SUZHOU TOLSEN TOOLS CO.,LTD. Building No.2, Zhenxing Road, Hexing, Jinfeng Town, Zhangjiagang City ，Jiangsu Province, China Declare that the product Electric hammer Ratings:230V-50Hz;1100W Serial number: N/A Complies with the essential health and safety requirements of the... - Page 17 SUZHOU TOLSEN TOOLS CO.,LTD. www.tolsentools.com TOLSEN is a trademark or registered trademark of TOLSEN TOOLS. All rights reserved. MADE IN CHINA...
