Programming i!-MacroManager

Programming i!-MacroManager
i!-MacroManager is implemented as a series of NetLinx modules to simplify adding macro
functionality to your program. To add any of the i!-MacroManager modules to your program,
simply add the module definition and all it's parameters to your code and integrate the sample touch
panel pages for that module into your touch panel design.
One simple way of doing this is to save the i!-MacroManager test file as an include file that you can
include into your main program. Then you can make any needed modifications to your include file.
To integrate the touch panel pages, copy each page and popup page from the i!-MacroManager test
touch panel file and paste it into your design. After copying the popup pages to the new file, you
will need to create the necessary popup groups and group the popup properly. As an option you can
base your design on the i!-MacroManager test touch panel file. If the channel and variable text
codes for i!-MacroManager conflict with existing channel or variable text codes, you can move
i!-MacroManager to another device using Power Assign and editing the touch panel devices in the
include file.
In order to use i!-MacroManager, you will need to program and define a series of actions through
i!-ConnectLinx. The i!-ConnectLinxEngineMod module is included with i!-MacroManager and
some simple examples appear in the i!-MacroManager test file. For complete documentation on
i!-ConnectLinx, download the i!-ConnectLinx install from the AMX web site.
Once the i!-ConnectLinx programming has been established, choose which i!-MacroManager
features you want to include in your program and add the corresponding module code and pages.
The following list describes the i!-MacroManager modules:

i!-MacroEngineMod

This is the macro engine module. This module executes macros and must always be included for
any i!-MacroManager functions. This module requires the i!-ConnectLinxEngineMod module.

i!-MacroEditorMod

This is the macro editor module. This module creates, edits and deletes macros. This module must
be used to create macros but is not required to run the macros. Since this module creates macros,
you will likely include this module in your program. This module requires the
i!- ConnectLinxEngineMod, i!-MacroEngineMod and KeyboardMod modules.

i!-MacroExecuteMod

This is the macro execute module. This module allows the user to dynamically assign a macro to a
touch panel button and run the macro when the button is pressed. This is the most common method
of macro execution; therefore you will likely include this module in your program. This module
requires the i!-MacroEngineMod module.

i!-MacroSchedulerEngineMod

This is the macro scheduler engine module. This module allows the scheduling and scheduled
execution of macros. This module is only needed if you want to support the scheduling of macros.
This module requires the i!-MacroEngineMod module.
