- Page 1 EN User Manual | Hob GK80TSPLCN...
-
Page 2: Table Of Contents
Welcome to Electrolux! Thank you for choosing our appliance. Get usage advice, brochures, trouble shooter, service and repair information: www.electrolux.com/support Subject to change without notice. CONTENTS 1. SAFETY INFORMATION................2 2. SAFETY INSTRUCTIONS................4 3. INSTALLATION....................6 4. PRODUCT DESCRIPTION................9 5. -
Page 3: General Safety
• Children should be supervised to ensure that they do not play with the appliance. • Keep all packaging away from children and dispose of it appropriately. • WARNING: The appliance and its accessible parts become hot during use. Keep children and pets away from the appliance when in use and when cooling down. -
Page 4: Safety Instructions
• Metallic objects such as knives, forks, spoons and lids should not be placed on the hob surface since they can get hot. • Do not use the appliance before installing it in the built-in structure. • Do not use a steam cleaner to clean the appliance. •... -
Page 5: Electrical Connection
• The separation panel has to cover the fuses removed from the holder), earth area under the hob completely. leakage trips and contactors. • The electrical installation must have an 2.2 Electrical Connection isolation device which lets you disconnect the appliance from the mains at all poles. The isolation device must have a contact WARNING! opening width of minimum 3 mm. -
Page 6: Installation
• Used oil, that can contain food remnants, • Clean the appliance with a moist soft can cause fire at a lower temperature than cloth. Use only neutral detergents. Do not oil used for the first time. use abrasive products, abrasive cleaning •... - Page 7 withstands a temperature of 90°C or higher. Speak to your local Service Centre. 3.4 Electrical connection Install the hob with a socket supply line. If there is no socket supply line, the fixed home electrical system must include an isolating device with at least a 3 mm-contact separation to enable a simultaneous and all- pole cut off from the mains (according to NIN...
- Page 8 25-40mm 25-40mm min. 25mm 25mm 35mm 23mm 520mm min. min. 25 mm 25mm min. 20 mm ENGLISH...
-
Page 9: Product Description
4. PRODUCT DESCRIPTION 4.1 Cooking surface layout Cooking zone Control panel 290 mm 290 mm 210 mm 165 mm 165 mm 145 mm 120/180 120/180 4.2 Control panel layout Use the sensor fields to operate the appliance. The displays, indicators and sounds tell which functions operate. -
Page 10: Daily Use
Sensor Function Comment field To select the cooking zone. To increase or decrease the time. Automatic Heat Up To activate and deactivate the function. Control bar To set a heat setting. 4.3 Heat setting displays Display Description The cooking zone is deactivated. The cooking zone operates. -
Page 11: The Heat Setting
• you spill something or put something on beginning and then continues to cook at the the control panel for more than 10 desired heating setting. seconds (a pan, a cloth, etc.). An acoustic signal sounds and the hob deactivates. Remove the object or clean the control To activate the function the cooking zone panel. -
Page 12: Child Safety Device
CountUp Timer (The count up timer) comes on. The heat setting is lowered to You can use this function to monitor how long the cooking zone operates. To deactivate the function, touch . The previous heat setting comes on. To set the cooking zone: touch again and again until the indicator of a necessary 5.8 Lock... -
Page 13: Hints And Tips
• - the sounds are off • you touch • Minute Minder comes down • - the sounds are on • Count Down Timer comes down To confirm your selection wait until the hob • you put something on the control panel. deactivates automatically. -
Page 14: Care And Cleaning
Heat setting Use to: Time Hints (min) 12 - 13 Heavy fry, hash browns, loin steaks, 5 - 15 Turn halfway through. steaks. Boil water, cook pasta, sear meat (goulash, pot roast), deep-fry chips. 7. CARE AND CLEANING not, the dirt can cause damage to the hob. WARNING! Take care to avoid burns. - Page 15 Problem Possible cause Remedy Pause operates. Refer to "Daily use". There is water or fat stains on the Clean the control panel. control panel. An acoustic signal sounds and the You put something on one or more Remove the object from the sensor hob deactivates.
-
Page 16: Technical Data
(it is in the corner of the glass booklet. surface) and an error message that comes 9. TECHNICAL DATA 9.1 Rating plate Model GK80TSPLCN PNC 949 596 640 01 Typ 60 HBD AA XO 400 V 2/3 50 - 60 Hz Made in Germany Ser.Nr. -
Page 17: Energy Saving
Length (L) and width (W) of non circular cooking Right rear L 16.5 cm zone W 29.0 cm Energy consumption per cooking zone (EC electric Left front 191.6 Wh/kg cooking) Left rear 194.9 Wh/kg Right front 188.0 Wh/kg Right rear 191.6 Wh/kg Energy consumption of the hob (EC electric hob) 191.5 Wh/kg... -
Page 18: Environmental Concerns
Warranty For each product we provide a two- conditions of use are not adhered to, if the year guarantee from the date of purchase or product is incorrectly installed, or in the event delivery to the consumer (with a guarantee of damage caused by external influences, certificate, invoice or sales receipt serving as force majeure, intervention by third parties or... - Page 20 867366210-B-122024...
