Features
Minimal External Circuitry Requirements for Complete System Solution
Adjustable Output Power: 0 to 10 dBm Adjusted and Stabilized with External Resistor
PA Efficiency: up to 38% (433 MHz/10 dBm/3 V)
High FSK Sensitivity: -106 dBm at 20 kBaud/-109.5 dBm at 2.4 kBaud (433.92 MHz)
High ASK Sensitivity: -112.5 dBm at 10 kBaud/-116.5 dBm at 2.4 kBaud
(Carrier Level 433.92 MHz)
ASK/FSK Receiver Uses a Low-IF Architecture with High Selectivity, Blocking and Low
Intermodulation (Typical Blocking 55 dB at ±750 kHz/61 dB at ±1.5 MHz and
70 dB at ±10 MHz, System I1dBCP = -30 dBm/System IIP3 = -20 dBm)
Transmitter Uses Closed Loop Fractional-N Synthesizer for FSK Modulation with a
High PLL Bandwidth and an Excellent Isolation between PLL and PA
Tolerances of XTAL Compensated by Fractional-N Synthesizer with 800 Hz RF
Resolution
Low Inband Sensitivity Change of Typically ±1.8 dB within ±58 kHz Center Frequency
Change in the Complete Temperature and Supply Voltage Range
Supply Voltage Range: 2.4 V to 3.6 V or 4.4 V to 6.6 V
Temperature Range: -40°C to +105°C
Low Supply Current: 10.5 mA in RX and TX Mode (3 V/TX with 5 dBm)
Supply Voltage Switch, Supply Voltage Regulator, Reset Generation, Clock/Interrupt
Generation and Low Battery Indicator for Microcontroller
Integrated RX/TX-Switch, Single-ended RF Input and Output
Fully Integrated PLL with Low Phase Noise VCO and PLL Loop Filter
Sophisticated Threshold Control and Quasi Peak Detector Circuit in the Data Slicer
Configurable Self Polling and RX/TX Protocol Handling with FIFO-RAM Buffering of
Received and Transmitted Data
RSSI (Received Signal Strength Indicator)
Communication to Microcontroller with SPI Interface Working at Maximum 500 kBit/s
< 10 nA Typical System Power-down Current Including Microcontroller
Power Management via Different Operation Modes
5 Push Button Inputs and One Wake-up Input are Active in Power-down Mode
ESD Protection at all Pins (2 kV HBM, 200 V MM)
433.92 MHz, 868.3 MHz and 315 MHz without External VCO and PLL Components
Inductive Supply with Voltage Regulator if Battery is Empty (AUX Mode)
Efficient XTO Start-up Circuit (> -1.5 kW Worst Case Start Impedance)
Integrated XTAL Capacitors
226 kHz IF Frequency with 30 dB Image Rejection and 170 kHz Usable IF Bandwidth
Changing of Modulation Type ASK/FSK and Data Rate without Component Changes
Data Rate 1 to 20 kBaud Manchester FSK, 1 to 10 kBaud Manchester ASK
Small 7 ´ 7 mm QFN48 Package
Applications
Automotive Keyless Entry and Access Control Systems
Remote Control Systems
Alarm and Telemetry Systems
Energy Metering
Home Automation
Benefits
No SAW Device Needed in Key Fob Designs to Meet Automotive Specifications
Low System Cost Due to Very High System Integration Level
Only One Crystal Needed in System
Less Demanding Specification for the Microcontroller Due to Handling of Power-down
Mode, Delivering of Clock, Reset, Low Battery Indication and Complete Handling of
Receive/Transmit Protocol and Polling
Single-ended Design with High Isolation of PLL/VCO from PA and the Power Supply
Allows a Loop Antenna in the Key Fob to Surround the Whole Application
UHF ASK/FSK
Transceiver
ATA5811
ATA5812
Preliminary
Rev. 4689A–RKE–05/03
1

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the ATA5811 and is the answer not in the manual?

Questions and answers

Summary of Contents for Atmel ATA5811

  • Page 1 Low Inband Sensitivity Change of Typically ±1.8 dB within ±58 kHz Center Frequency Change in the Complete Temperature and Supply Voltage Range • ATA5811 Supply Voltage Range: 2.4 V to 3.6 V or 4.4 V to 6.6 V • Temperature Range: -40°C to +105°C •...
  • Page 2: General Description

    The device supports data rates of 1 kBaud to 20 kBaud (FSK) and 1 kBaud to 10 kBaud (ASK) in Manchester, Bi-phase and other codes in transparent mode. The ATA5811 can be used in the 433 MHz to 435 MHz and the 868 MHz to 870 MHz band, the ATA5812 in the 314 MHz to 316 MHz band.
  • Page 3: Pin Description

    ATA5811/ATA5812 Figure 2. Pinning QFN48 48 47 46 45 44 43 42 41 40 39 38 37 RSSI DEM_OUT RF_IN SDI_TMDI 433_N868 ATA5811/ATA5812 SDO_TMDO R_PWR PWR_H N_RESET RF_OUT VSINT XTAL2 13 14 15 16 17 18 19 20 21 22 23 24...
  • Page 4 Key input 4 (can also be used to switch on the system (active low) Key input 5 (can also be used to switch on the system (active low) RX_ACTIVE Indicates RX operation mode Not connected Not connected Ground/backplane ATA5811/ATA5812 4689A–RKE–05/03...
  • Page 5 ATA5811/ATA5812 Figure 3. Block Diagram 433_N868 Power RF transceiver Digital Control Logic Frontend Enable Supply R_PWR PA_Enable (ASK) VAUX TX_DATA (FSK) RF_OUT VSOUT Switches RX/TX Regulators PWR_H Fract.-N- FREQ PWR_ON Wakeup Frequency Reset RX_TX1 FREF Synthesizer TX/RX - Data Buffer...
  • Page 6: Application Circuits

    RKE uni-directional systems. The ATA5811/ATA5812 provides sufficient isolation and robust pulling behavior of internal circuits from the supply voltage as well as an integrated VCO inductor to allow this.
  • Page 7 ATA5811/ATA5812 Figure 5. Typical RKE Car or Sensor Base-station Application, 433.92 MHz SAW-Filter CDEM RSSI DEM_OUT RF_IN SDI_TMDI AVCC Microcontroller 433_N868 SDO_TMDO ATA5811/ATA5812 R_PWR PWR_H N_RESET 50O W RF_OUT VSINT connector XTAL2 13.25311 MHz C1 C2 VCC = 4.75V..5.25V Typical Car or Sensor Figure 5 shows a typical 433.92 MHz V...
  • Page 8 Figure 6. Typical RKE Key Fob Application, 433.92 MHz, 2 Batteries CDEM RSSI DEM_OUT RF_IN SDI_TMDI AVCC Microcontroller 433_N868 SDO_TMDO ATA5811/ATA5812 R_PWR PWR_H N_RESET VSINT RF_OUT XTAL2 13.25311 MHz Loop antenna Litihum Cells Typical Key Fob Figure 6 shows a typical 433.92 MHz 2-battery RKE key fob or sensor application. The external components are 11 capacitors, 1 resistor, 2 inductors and a crystal.
  • Page 9 ATA5811/ATA5812 RF Transceiver According to Figure 3, the RF transceiver consists of an LNA (Low-Noise Amplifier), PA (Power Amplifier), RX/TX switch, fractional-N frequency synthesizer and the signal pro- cessing part with mixer, IF filter, IF amplifier, FSK/ASK demodulator, data filter and data slicer.
  • Page 10 5 and 6. The measurements in Table 3 and Table 4 are based on the values of registers 5 and 6 according to Table 39. Figure 7. Input Matching to 50 W ATA5811/ATA5812 RF_IN Table 2. Input Matching to 50 W /MHz 433.92...
  • Page 11 ATA5811/ATA5812 Table 3. Measured Sensitivity FSK, ± 16 kHz, Manchester, dBm, BER = 10 BR_Range_0 BR_Range_0 BR_Range_1 BR_Range_2 BR_Range_3 RF Frequency 1.0 kBaud 2.4 kBaud 5.0 kBaud 10 kBaud 20 kBaud 315 MHz -110.0 dBm -110.5 dBm -109.0 dBm -108.0 dBm -107.0 dBm...
  • Page 12 ±58 kHz can be accepted for XTAL and XTO tolerances. Note: For the demodulator used in the ATA5811/ATA5812, the tolerable frequency offset does not change with the data frequency, hence, the value of ±58 kHz is valid for up to 1 kBaud.
  • Page 13 ATA5811/ATA5812 Figure 9 shows narrow band blocking and Figure 10 wide band blocking characteristics. T h e m e a s u r e m e n t s w e r e d o n e w i t h a u s e f u l s i g n a l o f 4 3 3 . 9 2 M H z / F S K / 20 kBaud/ ±...
  • Page 14 -30 dBm 70 dBC/76 dBS The ATA5811/ATA5812 can also receive FSK and ASK modulated signals if they are much higher than the I1dBCP. It can typically receive useful signals at 10 dBm. This is often referred to as the nonlinear dynamic range which is the maximum to minimum receiving signal which is 116 dB for 20 kBaud Manchester.
  • Page 15 ATA5811/ATA5812 The data filter of the ATA5811/ATA5812 implies a quasi peak detector. This results in a good suppression of above mentioned disturbes and exhibits a good carrier to Gaussian noise performance. The required useful signal to disturbing signal ratio to be received with a BER of 10 is less than 12 dB in ASK mode and less than 3 dB (BR_Range_0 ...
  • Page 16 Figure 13. FSK-modulated TX Spectrum (20 kBaud/ ± 16.17 kHz/Manchester Code) Ref 10 dBm Atten 20 dB Samp VAvg W1 S2 S3 FC Center 433.92 MHz Span 30 MHz Res BW 100 kHz VBW 100 kHz Sweep 7.5 ms (401 pts) ATA5811/ATA5812 4689A–RKE–05/03...
  • Page 17 ATA5811/ATA5812 Figure 14. Unmodulated TX Spectrum f FSK_L Ref 10 dBm Atten 20 dB Samp VAvg W1 S2 S3 FC Center 433.92 MHz Span 1 MHz Res BW 10 kHz Sweep 27.5 ms (401 pts) VBW 10 kHz Figure 15. FSK-modulated TX Spectrum (20 kBaud/ ± 16.17 kHz/Manchester Code)
  • Page 18 2.7 V, whereas the low power mode (PWR_H = L) can be used down to 2.4 V as can be seen in the section “Electrical Characteristics”. The supply blocking capacitor C2 (10 nF) has to be placed close to the matching net- work because of the RF current flowing through it. ATA5811/ATA5812 4689A–RKE–05/03...
  • Page 19 ATA5811/ATA5812 Figure 16. Power Setting and Output Matching AVCC ATA5811/ATA5812 RF_OUT R_PWR VPWR_H PWR_H Table 7. Measured Output Power and Current Consumption with VS1 = VS2 = 3 V, T = 25°C Frequency TX Current Output Power (MHz) (mA) (dBm)
  • Page 20 Table 10. Impedance of the RX/TX Switch RX_TX2 Shorted to GND Frequency Z(RX_TX1) TX Mode Z(RX_TX1) RX Mode (4.8 + j3.2) W (11.3 - j214) W (4.5 + j4.3) W (10.3 - j153) W 433.92 (5 + j9) W (8.9 - j73) W 868.3 ATA5811/ATA5812 4689A–RKE–05/03...
  • Page 21 ATA5811/ATA5812 Figure 17. Equivalent Circuit of the Switch RX_TX1 1.6 nH 2.5 pF 11 W Matching Network in TX Mode In TX mode the 20 mm long and 0.4 mm wide transmission line which is much shorter than l /4 is approximately switched in parallel to the capacitor C9 to GND. The antenna...
  • Page 22 XTAL found in its data sheet. C is the total actual load capacitance of the crystal in the circuit and consists of C and C in series connection. Figure 18. XTAL with Load Capacitance Crystal equivalent circuit ´ + (C ATA5811/ATA5812 4689A–RKE–05/03...
  • Page 23 ATA5811/ATA5812 £ ³ With C 14 fF, C 1.5 pF, C = 9 pF and C = 7.6 pF to 10.6 pF the pulling amounts £ ± £ ³ to P 100 ppm and with C 7 fF, C 1.5 pF, C = 9 pF and C = 7.4 pF to 10.6 pF...
  • Page 24 æ ö FREQ 20,5 ´ 64 5 ---------------------------------- 868.3 13.41191 - 16.37 kHz + 16.37 kHz è ø 16384 æ ö FREQ 20,5 ´ 24 5 ---------------------------------- 315.0 12.73193 - 15.54 kHz + 15.54 kHz è ø 16384 ATA5811/ATA5812 4689A–RKE–05/03...
  • Page 25 ATA5811/ATA5812 The variable FREQ depends on FREQ2 and FREQ3, which are defined by the bits FR0 to FR8 in control register 2 and 3 and is calculated as follows: FREQ = 3584 + FREQ2 + FREQ3 Only the range of FREQ = 3803 to 4053 of this register should be used because other-...
  • Page 26: Power Supply

    (Control Register 3) The supply voltage range of the ATA5811/ATA5812 is 2.4 V to 3.6 V or 4.4 V to 6.6 V. Pin VS1 is the supply voltage input for the range 2.4 V to 3.6 V and is used in battery applications using a single lithium 3 V cell.
  • Page 27 ATA5811/ATA5812 AVCC is the internal operation voltage of the RF transceiver and is feed via the switch SW_AVCC by VS1. AVCC must be blocked with a 68 nF capacitor (see Figure 4, Figure 5 and Figure 6). DVCC is the internal operation voltage of the digital control logic and is feed via the switch SW_DVCC by VS1 or VSOUT.
  • Page 28 < 3.5 V (typically) the transceiver is in OFF mode. In OFF mode AVCC, VAUX DVCC and VSOUT are disabled, resulting in very low power consumption (I is typi- S_OFF cally 10 nA). In OFF mode the transceiver is not programmable via the 4-wire serial interface. ATA5811/ATA5812 4689A–RKE–05/03...
  • Page 29 ATA5811/ATA5812 AUX Mode The transceiver changes from OFF mode to AUX mode if the voltage at pin VAUX > 3.5 V (typically). In AUX mode DVCC and VSOUT are connected to the auxil- VAUX iary power supply input (VAUX) via the voltage regulator V_REG2. In AUX mode the transceiver is programmable via the 4-wire serial interface, but no RX or TX operations are possible because AVCC = OFF.
  • Page 30 = 2.38 V (typ) Thres_2 = 2.3V (typ) Thres_1 VSOUT 1.5 V (typ) DVCC (AVCC) DVCC_RESET >2.38 V and the XTO is running VSOUT N_RESET Low_Batt (Status Register) VSOUT_EN (Control Register 3) >2.3 V and the XTO is running VSOUT ATA5811/ATA5812 4689A–RKE–05/03...
  • Page 31 ATA5811/ATA5812 Figure 24. Reset Logic, SR Latch Generates the Hysteresis in the NRESET Signal DVCC_OK DVCC_RESET ³ 1 XTO_OK VSOUT_EN NRESET VSOUT_OK LOW_BATT no change no change 1-Battery Application The supply voltage range is 2.4 V to 3.6 V and VAUX is not used.
  • Page 32: Microcontroller Interface

    2-Battery Application The supply voltage range is 4.4 V to 6.6 Vand VAUX is connected to an inductive supply. Figure 26. 2-Battery Application with Inductive Emergency Supply ATA5811/ATA5812 Microcontroller 4.4 V to 6.6 V VAUX RF - Transceiver AVCC Digital Control...
  • Page 33: Table Of Contents

    ATA5811/ATA5812 After the transceiver is turned on via pin PWR_ON = High, T1 = Low, T2 = Low, T3 = Low, T4 = Low or T5 = Low or the voltage at pin VAUX V > 3.5 V (typically) the con- VAUX trol registers are in the default state.
  • Page 34 Pin IRQ is set to 1 if the TX data buffer is empty Table 16. Control Register 1 (Function of Bit 5) AVCC_EN Function (default) ATA5812 Enables AVCC, if the ATA5811/ is in AUX mode Table 17. Control Register 1 (Function of Bit 4) Function 433/868 MHz 315 MHz ATA5811/ATA5812 4689A–RKE–05/03...
  • Page 35 ATA5811/ATA5812 Table 18. Control Register 1 (Function of Bit 2 and Bit 1) OPM1 OPM0 Function Idle mode (default) TX mode RX polling mode RX mode Table 19. Control Register 1 (Function of Bit 0) T_MODE Function TX and RX function via TX/RX data buffer (default)
  • Page 36 Table 27. Control Register 4 (Function of Bit 6, Bit 5, Bit 4, Bit 3 and Bit 2) Function Sleep = Sleep ´ 1024 ´ T ´ X Sleep4 Sleep3 Sleep2 Sleep1 Sleep0 Sleep DCLK Sleep = 10 ´ 1024 ´ T ´ X Sleep DCLK Sleep (default) ATA5811/ATA5812 4689A–RKE–05/03...
  • Page 37: Lim_Max4

    ATA5811/ATA5812 Table 28. Control Register 4 (Function of Bit 1) XSleep Function = 1; extended T off (default) Sleep Sleep = 8; extended T Sleep Sleep Table 29. Control Register 4 (Function of Bit 0) XLim Function XLim = 1; extended TLim_min, TLim_max off (default) = 2;...
  • Page 38 Table 34. Control Register 6 (Function of Bit 5, Bit 4, Bit 3, Bit 2, Bit 1 and Bit 0) Function Lim_max (Lim_max < 12 Are Not Applicable) = (Lim_max - 1) ´ T Lim_max5 Lim_max4 Lim_max3 Lim_max2 Lim_max1 Lim_max0 Lim_max XDCLK ´ = (28 - 1) Lim_max XDCLK (default) ATA5811/ATA5812 4689A–RKE–05/03...
  • Page 39 ATA5811/ATA5812 Status Register The status register indicates the current status of the transceiver and is readable via the 4-wire serial interface. Setting Power_On or P_On_Aux or an event on ST1, ST2, ST3, ST4 or ST5 is indicated by an IRQ.
  • Page 40 2.38 V (typically) and the XTO is settled. VSOUT Figure 28. Timing Pin Tn, Status Bit STn = 2.38 V (typ) Thres_2 VSOUT = 2.3 V (typ) Thres_1 DVCC, AVCC 1.5 V (typ) N_RESET Tn_IRQ (Status Register) IDLE Mode Mode ATA5811/ATA5812 4689A–RKE–05/03...
  • Page 41 ATA5811/ATA5812 If the transceiver is in any active mode (Idle, AUX, TX, RX, RX_Polling), an integrated debounce logic is active. If there is an event on pin Tn a debounce counter is set to 0 (T = 0) and started. The status is updated, an interrupt is issued and the debounce ´...
  • Page 42 > T PWR_ON PWR_ON_IRQ_1 PWR_ON PWR_ON_IRQ_2 PWR_ON = 2.38 V (typ) Thres_2 VSOUT = 2.3 V (typ) Thres_1 DVCC, AVCC 1.5 V (typ) N_RESET PWR_ON_IRQ_1 PWR_ON_IRQ_2 Power_On (Status Register) IDLE IDLE, AUX, RX, RX Polling, TX Mode Mode Mode ATA5811/ATA5812 4689A–RKE–05/03...
  • Page 43 ATA5811/ATA5812 Low Battery Indicator The status bit Low_Batt is set to 1 if the voltage on pin VSOUT V drops under VSOUT 2.38 V (typically). Low_Batt is set to 0 if V exceeds V and the status register is read via the...
  • Page 44 > VS1 + 0.5 V (typ) VAUX VAUX 3.5 V (typ) VAUX 2.0 V (typ) = 2.38 V (typ) Thres_2 VSOUT = 2.3 V (typ) Thres_1 DVCC N_RESET P_On_Aux (Status Register) IDLE, TX, RX, RX Polling Mode Mode Mode ATA5811/ATA5812 4689A–RKE–05/03...
  • Page 45: Transceiver Configuration

    ATA5811/ATA5812 Transceiver The configuration of the transceiver takes place via a 4-wire serial interface (CS, SCK, SDI_TMDI, SDO_TMDO) and is organized in 8-bit units. The configuration is initiated Configuration with a 8-bit command. While shifting the command into pin SDI_TMDI, the number of bytes in the TX/RX data buffer are available on pin SDO_TMDO.
  • Page 46 Bit 0 to Bit 4 describes the target address when reading or writing a control or sta- tus register. In all other commands Bit 0 to Bit 4 have no effect and should be set to 0 for compatibility reasons with future products. ATA5811/ATA5812 4689A–RKE–05/03...
  • Page 47 ATA5811/ATA5812 Table 36. Command Structure Command Bit 7 Bit 6 Bit 5 Bit 4 Bit 3 Bit 2 Bit 1 Bit 0 Read TX/RX data buffer Write TX/RX data buffer Read control/status register Write control register OFF command Delete IRQ...
  • Page 48: Operation Modes

    X must be replaced by VS1, 2 in 1 battery application, VS2 in 2 battery appli- cation or VS2, VAUX in car application (see section “Electrical Characteristics”). ´ ´ ´ IDLE_X Sleep Startup_PLL_X RX_X Startup_Sig_Proc Bitcheck Startup_PLL ----------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------- - Sleep Startup_PLL Startup_Sig_Proc Bit_check ATA5811/ATA5812 4689A–RKE–05/03...
  • Page 49 ATA5811/ATA5812 To save current it is recommended CLK and V be disabled during RX polling VSOUT mode. I does not include the current of the Microcontroller_Interface I and the cur- VSINT rent of an external device connected to pin VSOUT (e.g., microcontroller). If CLK...
  • Page 50 Output level on Pin RX_ACTIVE -> High S_RX T_MODE=1 and level on Pin CS=Low ? Start bit detected ? RX data stream available on Pin RX data stream is SDO_TMDO written into the TX/RX Data Buffer bit error ? flow_chart_polling_mode_v2.0.vsd ATA5811/ATA5812 4689A–RKE–05/03...
  • Page 51 ATA5811/ATA5812 Bit-check Mode In Bit-check mode the incoming data stream is examined to distinguish between a valid signal from a corresponding transmitter and signals due to noise. This is done by subse- quent time frame checks where the distance between 2 signal edges are continuously compared to a programmable time window.
  • Page 52 1 2 3 4 5 6 7 8 1 2 3 4 5 6 7 8 9 101112131415161718 1 2 3 4 5 6 7 8 9 10 11 12131415 1 2 3 4 5 6 7 XDCLK Startup_Sig_Proc Bit-check Start-up mode Bit-check mode ATA5811/ATA5812 4689A–RKE–05/03...
  • Page 53 ATA5811/ATA5812 Figure 44. Timing Diagram for Failed Bit-check (Condition CV_Lim < Lim_min) (Lim_min = 14, Lim_max = 24) RX_ACTIVE Bit check failed (CV_Lim < Lim_min) Bit check 1/2 Bit Demod_Out Bit-check counter 1 2 3 4 5 6 7 8 1 2 3 4 5 6 7 8 9 101112...
  • Page 54 – ´ Lim_min_2T T Lim_min_2T DCLK Upper limit of 2T: ) 2 ¤ Lim_max_2T Lim_min Lim_max Lim_max Lim_min – Lim_max_2T XDCLK If the result of Lim_min_2T or Lim_max_2T is not an integer value, it will be round up. ATA5811/ATA5812 4689A–RKE–05/03...
  • Page 55 ATA5811/ATA5812 If the TX/RX data buffer control logic detects the start bit, the data stream is written in the TX/RX data buffer byte by byte. The start bit is part of the first data byte and must be different from the bits of the preburst. If the preburst consists of a sequence of '00000...', the start bit must be a 1.
  • Page 56 Lim_min = 11 (52 µs) Lim_min = 11 (26 µs) Lim_min = 11 (13 µs) (13.41191) Lim_max = 38 (706 µs) Lim_max = 34 (315 µs) Lim_max = 32 (148 µs) Lim_max = 32 (74 µs) Lim_max = 32 (37 µs) ATA5811/ATA5812 4689A–RKE–05/03...
  • Page 57 ATA5811/ATA5812 TX Operation The transceiver is set to TX operation by using the bits OPM0 and OPM1 in the control register 1. Table 40. Control Register 1 OPM1 OPM0 Function TX mode Before activating TX mode, the TX parameters (baud rate, modulation scheme ... ) must be selected as illustrated in Figure 49.
  • Page 58 TX more Data Bytes ? TX Mode Write TX/RX Data Buffer (max. 16 - number of bytes still in Command: Delete_IRQ the TX/RX Data Buffer) Pin IRQ=1 ? Write Control Register 1 OPM1, OPM0: Set IDLE Idle Mode ATA5811/ATA5812 4689A–RKE–05/03...
  • Page 59 ATA5811/ATA5812 Figure 50. TX Transparent Mode (T_MODE = 1) Write Control Register 4 XLim: Don't care ASK/_NFSK: Select modulation Sleep0 ... Sleep4: Don't care XSleep: Don't care Write Control Register 3 FR7, FR8: Adjust f VSOUT_EN: Set VSOUT_EN = 1...
  • Page 60 Write control register 1 or (depends on IR0 and IR1 in control Write control register 4 or register 1). Write control register 5 or Write control register 6 or Successful Bit-check (P_MODE = 0) Command delete IRQ ATA5811/ATA5812 4689A–RKE–05/03...
  • Page 61: Absolute Maximum Ratings

    ATA5811/ATA5812 Absolute Maximum Ratings Parameters Symbol Min. Max. Unit Junction temperature °C Storage temperature +125 °C Ambient temperature +105 °C Supply voltage VS2 -0.3 +7.2 MaxVS2 Supply voltage VS1 -0.3 MaxVS1 Supply voltage VAUX -0.3 +7.2 MaxVAUX Supply voltage VSINT -0.3...
  • Page 62 “Electrical Characteristics”. No. Parameters Test Conditions Symbol Min. Typ. Max. Unit Type* RX_TX_IDLE Mode ATA5811 4, 10 = 0 V 433_N868 RF operating frequency ATA5811 4, 10 range = AVCC 433_N868...
  • Page 63 ATA5811/ATA5812 Electrical Characteristics: General (Continued) All parameters refer to GND and are valid for T = -40°C to +105°C, V = 2.4 V to 3.6 V (1-battery application), = 4.4 V to 6.6 V (2-battery application) and V = 4.75 V to 5.25 V (car application). Typical values are given...
  • Page 64 1. Pin numbers in brackets mean they were measured with RF_IN matched to 50 W according to Figure 7 with component val- Note: ues according to Table 2 and RF_OUT matched to 50 W according to Figure 16 with component values according to Table ATA5811/ATA5812 4689A–RKE–05/03...
  • Page 65 ATA5811/ATA5812 Electrical Characteristics: General (Continued) All parameters refer to GND and are valid for T = -40°C to +105°C, V = 2.4 V to 3.6 V (1-battery application), = 4.4 V to 6.6 V (2-battery application) and V = 4.75 V to 5.25 V (car application). Typical values are given...
  • Page 66 1. Pin numbers in brackets mean they were measured with RF_IN matched to 50 W according to Figure 7 with component val- Note: ues according to Table 2 and RF_OUT matched to 50 W according to Figure 16 with component values according to Table ATA5811/ATA5812 4689A–RKE–05/03...
  • Page 67 ATA5811/ATA5812 Electrical Characteristics: General (Continued) All parameters refer to GND and are valid for T = -40°C to +105°C, V = 2.4 V to 3.6 V (1-battery application), = 4.4 V to 6.6 V (2-battery application) and V = 4.75 V to 5.25 V (car application). Typical values are given...
  • Page 68 1. Pin numbers in brackets mean they were measured with RF_IN matched to 50 W according to Figure 7 with component val- Note: ues according to Table 2 and RF_OUT matched to 50 W according to Figure 16 with component values according to Table ATA5811/ATA5812 4689A–RKE–05/03...
  • Page 69 ATA5811/ATA5812 Electrical Characteristics: General (Continued) All parameters refer to GND and are valid for T = -40°C to +105°C, V = 2.4 V to 3.6 V (1-battery application), = 4.4 V to 6.6 V (2-battery application) and V = 4.75 V to 5.25 V (car application). Typical values are given...
  • Page 70 1. Pin numbers in brackets mean they were measured with RF_IN matched to 50 W according to Figure 7 with component val- Note: ues according to Table 2 and RF_OUT matched to 50 W according to Figure 16 with component values according to Table ATA5811/ATA5812 4689A–RKE–05/03...
  • Page 71 ATA5811/ATA5812 Electrical Characteristics: General (Continued) All parameters refer to GND and are valid for T = -40°C to +105°C, V = 2.4 V to 3.6 V (1-battery application), = 4.4 V to 6.6 V (2-battery application) and V = 4.75 V to 5.25 V (car application). Typical values are given...
  • Page 72 1. Pin numbers in brackets mean they were measured with RF_IN matched to 50 W according to Figure 7 with component val- Note: ues according to Table 2 and RF_OUT matched to 50 W according to Figure 16 with component values according to Table ATA5811/ATA5812 4689A–RKE–05/03...
  • Page 73 ATA5811/ATA5812 Electrical Characteristics: General (Continued) All parameters refer to GND and are valid for T = -40°C to +105°C, V = 2.4 V to 3.6 V (1-battery application), = 4.4 V to 6.6 V (2-battery application) and V = 4.75 V to 5.25 V (car application). Typical values are given...
  • Page 74 *) Type means: A = 100% tested, B = 100% correlation tested, C = Characterized on samples, D = Design parameter Note: 1. The voltage of VAUX may rise up to 2 V. The current I may not exceed 100 µA. VAUX ATA5811/ATA5812 4689A–RKE–05/03...
  • Page 75 ATA5811/ATA5812 Electrical Characteristic: 1-Battery Application (Continued) All parameters refer to GND and are valid for T = -40°C to +105°C, V = 2.4 V to 3.6 V typical values at = 3 V and T = 25°C. Application according to Figure 4. f = 315.0 MHz/433.92 MHz/868.3 MHz unless oth-...
  • Page 76 *) Type means: A = 100% tested, B = 100% correlation tested, C = Characterized on samples, D = Design parameter Note: 1. The voltage of VAUX may rise up to 2 V. The current I may not exceed 100 µA. VAUX ATA5811/ATA5812 4689A–RKE–05/03...
  • Page 77 ATA5811/ATA5812 Electrical Characteristics: 2-Battery Application All parameters refer to GND and are valid for T = -40 °C to +105 °C, V = 4.4 V to 6.6 V typical values at V = 6V and = 25°C. Application according to Figure 6. f = 315.0MHz/433.92 MHz/868.3 MHz unless otherwise specified...
  • Page 78 *) Type means: A = 100% tested, B = 100% correlation tested, C = Characterized on samples, D = Design parameter Note: 1. The voltage of VAUX may rise up to 2 V. The current I may not exceed 100 µA. VAUX ATA5811/ATA5812 4689A–RKE–05/03...
  • Page 79 ATA5811/ATA5812 Electrical Characteristics: Car Application All parameters refer to GND and are valid for T = -40°C to +105°C, V = 4.75 V to 5.25 V. Typical values at V = 5 V and T = 25°C. Application according to Figure 5. f = 315.0 MHz/433.92 MHz/868.3 MHz unless otherwise specified...
  • Page 80 Supply current in enabled S_TX TX_VS2_VAUX VSINT VSOUT 11.15 1922, S_TX TX mode CLK disabled S_TX TX_VS2_VAUX enabled VSOUT *) Type means: A = 100% tested, B = 100% correlation tested, C = Characterized on samples, D = Design parameter ATA5811/ATA5812 4689A–RKE–05/03...
  • Page 81 ATA5811/ATA5812 Digital Timing Characteristics All parameters refer to GND and are valid for T = -40°C to +105°C. V = 2.4 V to 3.6 V (1-battery application), = 4.4 V to 6.6 V (2-battery application) and V = 4.75 V to 5.25 V (car application), typical values at V 3 V and T = 25°C unless otherwise specified.
  • Page 82 31, 33 Out_disable CS disable time period 15.8 µs ´ T CS_disable DCLK *) Type means: A = 100% tested, B = 100% correlation tested, C = Characterized on samples, D = Design parameter ATA5811/ATA5812 4689A–RKE–05/03...
  • Page 83 ATA5811/ATA5812 Digital Timing Characteristics (Continued) All parameters refer to GND and are valid for T = -40°C to +105°C. V = 2.4 V to 3.6 V (1-battery application), = 4.4 V to 6.6 V (2-battery application) and V = 4.75 V to 5.25 V (car application), typical values at V 3 V and T = 25°C unless otherwise specified.
  • Page 84 8195 16.4 42, 43, µs ´ T ´ T Debounce time OFF mode DCLK DCLK 44, 45 *) Type means: A = 100% tested, B = 100% correlation tested, C = Characterized on samples, D = Design parameter ATA5811/ATA5812 4689A–RKE–05/03...
  • Page 85 ATA5811/ATA5812 Digital Port Characteristics All parameter refer to GND and valid for T = -40 °C to +105 °C, V = 2.4 V to 3.6 V (1 Battery Application) and = 4.4 V to 6.6 V (2 Battery Application) and V = 4.75 V to 5.25 V (Car Application) typical values at V...
  • Page 86 = 25 µA RX_ACTIVE DEM_OUT output Open drain output 17.15 0.15 Saturation voltage low = 250 µA DEM_OUT *) Type means: A = 100% tested, B = 100% correlation tested, C = Characterized on samples, D = Design parameter ATA5811/ATA5812 4689A–RKE–05/03...
  • Page 87: Ordering Information

    ATA5811/ATA5812 Ordering Information Extended Type Number Package Remarks ATA5811 QFN48 7 mm x 7 mm ATA5812 QFN48 7 mm x 7 mm Package Information 4689A–RKE–05/03...
  • Page 88 Electrical Characteristic: 1-Battery Application ......74 Electrical Characteristics: 2-Battery Application ......77 Electrical Characteristics: Car Application ........79 Digital Timing Characteristics ............81 Digital Port Characteristics ..............85 Ordering Information ................87 Package Information ................. 87 Table of Contents ................88 ATA5811/ATA5812 4689A–RKE–05/03...
  • Page 89 No licenses to patents or other intellectual property of Atmel are granted by the Company in connection with the sale of Atmel products, expressly or by implication. Atmel’s products are not authorized for use as critical components in life support devices or systems.

This manual is also suitable for:

Ata5812

Table of Contents
