STANDARD EQUIPMENT
• Alternator, 60 Ampere, 24V
• Fan guard structure
• Auto-decel
• Hydraulic track adjusters (each side)
• Automatic engine warm-up system
• Long lubricating intervals for implement
• Batteries, 126 Ah/2 x 12V
bushings
• Boom holding valve
• Multi-function color monitor
• Cab, capable OPG with optional bolt-on
• Power maximizing system
top guard
• PPC hydraulic control system
• Corrosion resistor
• Radiator & oil cooler dust proof net
• Counterweight
• Rear reflector
• Dry type air cleaner, double element
• Rear view mirror, RH, LH, rear,
• Electric horn
sidewise
• Engine, Komatsu SAA6D114E-3
• Seat belt, retractable
• Engine overheat prevention system
• Starting motor, 7.5 kW/24 v x 1
OPTIONAL EQUIPMENT
• Additional filter system for poor-quality fuel
• Cab accessories
• Air conditioner with defroster
—Rain visor
• Arm, 3185 mm 10'5" arm assembly,
—Sun visor
heavy-duty
• Cab front guard
• Batteries, 140 Ah/2 x 12 V
—Full height guard
• Bolt-on top guard (Operator Protective
—Half height guard
Guards level 2 (OPG))
• Cab with 2-piece pull up front window
• Boom, 6470 mm 21'3", heavy-duty
• Heater with defroster
SPECIAL PURPOSE BUCKET
• Ripper bucket for hard and rock ground
—Capacity
SAE heaped 0.9 m
3
1.18 yd
3
CECE heaped 0.8 m
3
1.05 yd
3
Width 1200 mm 47.2"
www.Komatsu.com
CEN00222-01
• Suction fan
• Track roller guards (full length)
• Track roller
—PC350-8, 7 each side
—PC350LC-8, 8 each side
• Track shoe
—PC350-8, 600 mm 24" triple grouser
—PC350LC-8, 600 mm 24" triple grouser
• Travel alarm
• Two-mode setting for boom
• Working light, 2 (boom and RH)
• Working mode selection system
• Rear view monitoring system
• Seat, suspension
• Seat, suspension with heater
• Service valve
• Track frame undercover
• Working lights, 2 on cab
Printed in Japan 200804 IP.As(05)
Materials and specifications are subject to change without notice.
is a trademark of Komatsu Ltd. Japan.
PC350
-8
PC350LC
-8
FLYWHEEL
HORSEPOWER
Gross: 194 kW 260 HP @ 1950 rpm
Net: 184 kW 246 HP @ 1950 rpm
OPERATING WEIGHT
PC350-8: 32600– 32960 kg
71,870– 72,660 lb
PC350LC-8: 33660– 34040 kg
74,210– 75,040 lb
PC
350
Photo may include optional equipment.
