Note: This manual is downloaded from https://thewaykar.com/
Important Safety Information
⚠ WARNING
Read all instructions before using this dehumidifier. Failure to follow these instructions may result in fire, electrical shock, or serious
injury.
Safety Precautions
Always plug the unit into a grounded electrical outlet
Never operate the unit with a damaged cord or plug
Do not use extension cords with this appliance
Keep the unit away from heat sources and direct sunlight
Do not block air intake or exhaust vents
Never insert fingers or objects into the unit
Disconnect power before cleaning or servicing
Do not operate in temperatures below 41°F (5°C)
Ensure proper ventilation around the unit (minimum 12 inches clearance)
WAYKAR DEHUMIDIFIER
User Manual & Operating Instructions
Model: WK-D035A / WK-D050A Series
Advertisement
Table of Contents
Related Manuals for Waykar WK-D035A Series
Summary of Contents for Waykar WK-D035A Series
- Page 1 WAYKAR DEHUMIDIFIER User Manual & Operating Instructions Model: WK-D035A / WK-D050A Series Note: This manual is downloaded from https://thewaykar.com/ Important Safety Information ⚠ WARNING Read all instructions before using this dehumidifier. Failure to follow these instructions may result in fire, electrical shock, or serious injury. Safety Precautions Always plug the unit into a grounded electrical outlet Never operate the unit with a damaged cord or plug Do not use extension cords with this appliance Keep the unit away from heat sources and direct sunlight Do not block air intake or exhaust vents Never insert fingers or objects into the unit Disconnect power before cleaning or servicing Do not operate in temperatures below 41°F (5°C) Ensure proper ventilation around the unit (minimum 12 inches clearance)
-
Page 2: Product Specifications
Product Specifications Specification WK-D035A WK-D050A Dehumidification Capacity 35 Pints/Day 50 Pints/Day Coverage Area Up to 3,000 sq ft Up to 4,500 sq ft Water Tank Capacity 1.8 Gallons 1.8 Gallons Power Consumption 590W 700W Voltage 115V AC, 60Hz Operating Temperature 41°F - 95°F (5°C - 35°C) Dimensions (W×D×H) 15.4" × 11.0" × 24.3" 15.4" × 11.0" × 24.3" Weight 39.5 lbs 41.2 lbs Noise Level < 48 dB Setup and Installation Initial Setup Remove the dehumidifier from packaging and inspect for any damage during shipping. Allow the unit to stand upright for at least 4 hours before first use if it was transported on its side. Place the unit on a flat, stable surface with at least 12 inches of clearance on all sides. Ensure the water tank is properly installed and the drainage hose connection is secure. Plug the unit into a grounded electrical outlet rated for at least 15 amps. ⚠ CAUTION Do not operate the dehumidifier immediately after unpacking. Allow it to acclimate to room temperature for at least 30 minutes. Placement Guidelines Position away from walls and furniture to ensure proper airflow Place on a level surface to prevent water leakage Avoid areas with direct sunlight or heat sources Ensure adequate ventilation around the unit Keep away from curtains, bedding, or other fabrics that could block airflow... -
Page 3: Control Panel And Features
Control Panel and Features Digital Display Current Humidity: Shows the current relative humidity percentage Target Humidity: Displays the desired humidity level (30-80%) Timer Display: Shows remaining time when timer is active Error Codes: Displays diagnostic codes when issues occur Control Buttons Power Button: Turns the unit on and off Humidity +/-: Adjusts target humidity level Fan Speed: Cycles through Low, Medium, High, and Auto settings Timer: Sets automatic shut-off time (1-24 hours) Mode: Switches between Normal, Laundry, and Continuous modes Filter Reset: Resets the filter replacement indicator Operating Modes Normal Mode: Maintains set humidity level automatically Laundry Mode: Maximum dehumidification for faster clothes drying Continuous Mode: Runs continuously regardless of humidity level Auto Mode: Automatically adjusts fan speed based on humidity difference... - Page 4 Operation Instructions Basic Operation Press the Power button to turn on the unit. The display will show the current room humidity. Use the Humidity +/- buttons to set your desired humidity level (recommended: 45-55%). Select your preferred fan speed or leave on Auto for optimal performance. The unit will automatically cycle on and off to maintain the set humidity level. Monitor the water tank level and empty when the "Tank Full" indicator appears. Water Tank Management Check the water level regularly through the transparent water tank When the tank is full, the unit will stop automatically and display "Tank Full" Remove the tank by pulling it straight out from the unit Empty the water and rinse the tank with clean water Reinstall the tank firmly until it clicks into place Continuous Drainage Option For continuous operation without tank emptying: Locate the drainage port on the back of the unit. Connect the provided drainage hose to the port. Route the hose to a floor drain, sink, or outside drainage area. Ensure the hose has a downward slope for proper drainage. Remove the water tank's rubber stopper to enable continuous drainage.
-
Page 5: Maintenance And Care
Maintenance and Care Regular Maintenance Schedule Weekly: Empty and clean water tank Bi-weekly: Clean air intake filter Monthly: Wipe down exterior surfaces Quarterly: Deep clean internal components Annually: Professional service check (if needed) Filter Cleaning Turn off and unplug the dehumidifier. Remove the front grille by pulling it forward. Take out the washable air filter. Rinse the filter with lukewarm water and mild detergent. Allow the filter to dry completely before reinstalling. Reinstall the filter and front grille. Press and hold the Filter Reset button for 3 seconds to reset the indicator. Exterior Cleaning Unplug the unit before cleaning Use a soft, damp cloth to wipe the exterior Do not use abrasive cleaners or solvents Ensure all surfaces are dry before plugging in ⚠ WARNING Never spray water directly on the unit or submerge any part in water. This can cause electrical shock or damage to the unit. -
Page 6: Troubleshooting Guide
Troubleshooting Guide Problem Possible Cause Solution Unit won't start No power supply Check power connection Water tank not properly installed Reinstall water tank firmly Room temperature too low Ensure room temperature is above 41°F Not removing moisture Dirty air filter Clean or replace filter Blocked air vents Clear vents of obstructions Room too cold Increase room temperature Refrigerant leak Contact customer service Excessive noise Unit not level Level the unit properly Loose parts Check for loose screws Dirty fan blades Clean fan area Ice formation Room temperature too low Increase room temperature Dirty evaporator coils Clean coils Low refrigerant Contact service technician Water leakage Tank not properly seated Reinstall tank correctly Cracked tank Replace damaged tank Blocked drainage Clear drainage pathway Auto-shutoff not working Faulty humidity sensor... -
Page 7: Storage And Winterization
Storage and Winterization Long-term Storage Turn off and unplug the dehumidifier. Empty the water tank completely and clean thoroughly. Remove and clean the air filter, allow to dry completely. Wipe down all exterior surfaces. Leave the unit in a dry location for 24 hours to ensure all internal moisture evaporates. Cover the unit with a cloth or plastic cover to prevent dust accumulation. Store in a dry, temperature-controlled environment. Preparing for Next Season Remove storage cover and inspect for any damage Reinstall the clean air filter Wipe down exterior surfaces Allow unit to acclimate to room temperature for 30 minutes Perform a test run to ensure proper operation... -
Page 8: Warranty Information
Warranty Information Limited Warranty Coverage Waykar provides a limited warranty on this dehumidifier: Parts and Labor: 2 years from date of purchase Compressor: 5 years from date of purchase Coverage: Manufacturing defects and component failures under normal use Warranty Exclusions Damage due to misuse, abuse, or negligence Normal wear and tear (filters, cosmetic damage) Damage from power surges or electrical issues Units serviced by unauthorized technicians Commercial or rental property use To Obtain Warranty Service 1. Contact Waykar customer service at the number provided in your documentation 2. Provide proof of purchase and model number 3. Describe the issue and any troubleshooting steps taken 4. Follow the instructions provided by the service representative Customer Support Contact Information For technical support, warranty claims, or product questions: Website: https://thewaykar.com/ Email: support@waykar.com Phone: 1-800-WAYKAR-1 (1-800-929-5271) Hours: Monday-Friday, 9 AM - 6 PM EST Before Calling Support Please have the following information ready: Model number (located on the unit's rating plate) Serial number Date of purchase and proof of purchase Description of the problem Any error codes displayed Waykar Dehumidifier User Manual Version 2.1 | Last Updated: January 2025 Downloaded from: https://thewaykar.com/ © 2025 Waykar. All rights reserved.
