Collaborative Table Legs
Model# LT-LNTLEGCSTR-4-XX
Model# LT-LNTLEGCSTR-6-XX
WARNING:
Adult Assembly Required
- Two adults recommended.
- Contains small parts, sharp points and edges.
- Do not stand, sit, kneel, climb, lean or pull on
unit for support.
- Never leave children unattended.
- Do not place unit near high heat or moisture.
TOOLS NEEDED
Phillips Screwdriver
BEFORE ASSEMBLING, MAKE SURE YOU HAVE ALL THE PARTS
A
Upper Leg
B
Lower Leg
Support
Extension
(4 or 6)
1
Install Upper Leg Supports into Receiver Plates
Slide the base plate of the Upper Leg Support (A) onto the receiver plate,
until the three pilot holes on the table are aligned and visible through the
corresponding holes on the leg base plate.
Install each Upper Leg Support (A) onto the Table Top with
three Phillips Screws (F) using a Phillips screwdriver.
Do not over tighten screws.
Parts List
C
E
Table Leg Glide
(4 or 6)
(4 or 6)
D
Locking Caster
F
(4 or 6)
G
Hex Screws
Hex Tool (1)
(8 or 12)
Phillips Screws
H
Wrench (1)
(12 or 18)
See Next Page
