Zupapa 14009D User Manual

Small rectangle trampoline
Hide thumbs
Table of Contents

Advertisement

Quick Links

Download this manual
Zupapa Small Rectangle Trampoline
User Manual
Read, understand, and follow guidelines in this manual
before (dis)assembling, using your trampoline.
*Recommend for children aged 3 to 6
*Not for commercial use
*Trampoline Weight Capacity:220lbs
*Swing Weight Capacity:110lbs
*Horizontal Bar Weight Capacity:150lbs
Zupapa Small Rectangle Trampoline comply with ASTM F963-17 (U.S.) standard.
Costumer Service:official@zupapa.us

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the 14009D and is the answer not in the manual?

Questions and answers

Related Manuals for Zupapa 14009D

Summary of Contents for Zupapa 14009D

  • Page 1 Read, understand, and follow guidelines in this manual before (dis)assembling, using your trampoline. *Recommend for children aged 3 to 6 *Not for commercial use *Trampoline Weight Capacity:220lbs *Swing Weight Capacity:110lbs *Horizontal Bar Weight Capacity:150lbs Zupapa Small Rectangle Trampoline comply with ASTM F963-17 (U.S.) standard. Costumer Service:official@zupapa.us...

  • Page 2: Table Of Contents

    • If you have any questions, suggestions, and (or) comments, please feel free to contact us at your earliest convenience. Zupapa® Customer Happiness Executives are standing behind to help out all the time. We promise you are sure to receive a reply in 12 hours.

  • Page 3: About Zupapa

    For the mesh materials, instead of the most widely-used PP (polypropylene) in the market, we've upgraded them to PE (polyeth- ylene) which is more durable and stretchable. You can rest assured to take a Zupapa® Small Rectangle Trampoline home for years of enjoy-ment.

  • Page 4: Safety Instructions

    Zupapa Small Rectangle Trampoline make it easy to enjoy bounce at home. However, the risk of injuries accompanies as with any kind of sports. To enjoy the Zupapa® Small Rectangle Trampoline , whether you are the supervisor or the jumper, you should read, understand, and practice the safety instructions as below.
  • Page 5 • Do not allow the player to take alcohol or drugs before using the trampoline. Supervisor’s Role in Preventing Accidents • Do not allow the player to jump into/off of the pad. • Do not allow the player to crawl underneath the trampoline. •...

  • Page 6: Parts List

    You can refer to the following chart for the part number, diagram, description, and quantity of each size. When you need the replacement(s), get in touch with Zupapa® Customer Happiness Executives, we are ready to make you 100% satisfied. Do not forget to provide the order number, part number, quantity, and pictures or video clips (if applicable) so that you can get what you need as soon as possible.
  • Page 7 41.3” Part Number Diagram Description Quantity L-shaped Leg with 2 Pin L-shaped Lower Net Pole with 2 Pin L-shaped Lower Net Pole with 1Pin Medium Net Pole Curved Net Pole with 1 Male End Curved Net Pole with 2 Female End Horizontal Net Pole(33.86inch) Horizontal Bar Pole(35.83inch) Bottom Safety Net...
  • Page 8 41.3” Part Number Diagram Description Quantity Screw Set(M6*75mm)-Hammock Chair Screw Set(M6*40 mm)-Horizontal Net Pole Screw Set(M6*65 mm)-Horizontal Bar Pole Spanner Hex Wrench Figure-8 Clamp Set Galvanized Spring Spring Loading Tool Horizontal Bar Set Hammock Chair Basketball Set A pair of Gloves...

  • Page 9: Assembly

    1. Check and confirm you have all labeled parts according to the chapter Parts List. If you need any replacement(s), feel free to reach out to Zupapa® Customer Happiness Executives with the ORDER NUMBER, PART NUMBER, REQUIRED QUANTITY for each part, and photos or videos (if applicable).
  • Page 10 STEP 1 - FRAME INSTALLATION 1.1 Support Assembly Picture1 As shown above, connect the L-shaped Leg with 2 Pin（#8） to L-shaped Leg with 1 Pin（#7）. Assemble the other set in the same manner. 1.2 Top Rail Assembly Picture2 As shown above, connect the left L-shaped top rail（#3）& right L-shaped top rail（#4） to short horizontal top rail (#6). Assemble the other set in the same manner.
  • Page 11 Picture3 As shown above, connect the two long horizontal top rails (#5) to the assembled frame Picture 2 . Picture4 As shown above,connect the assembled legs from Picture 1 to the to the assembled frame picture 3. The installed structure is shown in the Picture.
  • Page 12 STEP 2 - SPRING LOADING INSTRUCTION AND ATTACH THE TRAMPOLINE MAT TO THE FRAME Picture5 Picture6 Connect the jumping mat with spring pad(#1) to Connect the galvanized springs(#21) with the V-ring and the trampoline frame by attaching a spring to the two the aligned hole on the main frame.Please use the spring V-rings closest to each corner.
  • Page 13 Picture9 Picture10 Next, please tidy up the spring pad. Attach the hook of the elastic strap to the V-rings circling around the outside of the top rail frame. Picture11 Picture display after installation.
  • Page 14 STEP 3 - NET POLES AND NET ASSEMBLY Picture12 As shown in the diagram, the medium net pole(#11) is first connected to the L-shaped lower net pole with 1pin (#10), then joins with L-shaped lower net pole with 2 pin (#9), and finally connects to another medium net pole (#11) to form a complete assembly.Assemble the other set in the same manner.
  • Page 15 Picture14 Note: The zipper is on the wide side. As shown in the picture, put the safety net (#2) on the 4 medium net poles.Note: Evenly pull down the safety net. Picture15 First, thread the two curved poles (#12 and #13) through the top of the safety net from both sides, first connecting them to the middle pole, then join them in the center.
  • Page 16 Picture16 M6*40mm As shown in the diagram, the horizontal net pole passes through the wide side above the safety net and is secured to the installed net pole structure using screws(#17,M6*40mm).Assemble the other set in the same manner. Note:Do not tighten the screws yet; wait until the two horizontal net poles are installed before tightening them. Picture17 Evenly pull down the netting, smooth it out.
  • Page 17 Picture18 First, select the appropriate location and thread the elastic Then, proceed to install them one by one clockwise until the hooks at the bottom of the safety net (#2) through the loops entire bottom safety net is secured. Finally, fasten the two above the bottom safety net (#16), hanging them on the pieces of Velcro together.
  • Page 18 STEP 4 - HORIZONTAL BAR ASSEMBLY Picture20 M6*65 Secure the horizontal bar pole(#15) to the middle hole of the curved net pole with a screw (#17, M6*65mm), threading the screw upwards from below. Picture21 Fix the two lifting rings on the horizontal bar pole（#15）.
  • Page 19 STEP 5-HAMMOCK CHAIR ASSEMBLY Please note: When using the hammock chair, always face the side without the zipper. We offer two hammock chair installation options to accommodate users of different heights: Option 1: Suitable for taller users, this method does not require an adjustable rope. Simply thread the hammock chair through the U-shaped screw(M6*75mm) and secure it directly to the curved net pole for a straightforward setup.
  • Page 20 STEP 6-BASKETBALL SET ASSEMBLY Randomly stick "Z-shaped "EVA foam Use the board screws to secure the two Next, weave the basketball net on the back of the backboard to "L"-shaped brackets to the backboard. around the rim. cushion the impact on the netting Finally, hang the backboard on the outer side of the wide end of the trampoline.

  • Page 21: Disassembly

    • This product must be assembled and disassembled by adult. MAINTENANCE With proper care and maintenance, the Zupapa® Small Rectangle Trampoline are capable of providing your family with many years of fun and enjoyment. Always inspect the trampoline and replace any worn, overused, damaged, or missing parts before each use, and be cautious of the following conditions: •...
  • Page 22 • Damages caused by weather (including but not limited to winds, rains, snow) are excluded from the warranty. You can either email Zupapa or the retailer with the inquiry details, order number, and pictures or videos (if applicable) if you need to claim for the warranty.
