ENID WIDESPREAD FAUCET INSTALLATION
BEFORE YOU BEGIN
We recommend consulting a professional if you are
unfamiliar with installing plumbing fixtures. Signature
Hardware accepts no liability for any damage to the
faucet, plumbing, sink, counter top, or for personal injury
during installation.
Observe all local plumbing and building codes.
Unpack and inspect the faucet for damage. If any
damage is found, contact our Customer Relations team
at 1-866-855-2284.
GETTING STARTED
Ensure that you have gathered all the required
materials that are needed for the installation.
For these instructions, it is assumed that the old
faucet has been completely removed and any
necessary repairs or modifications to the water
supply have been completed.
TOOLS AND MATERIALS:
Plumbers
Thread
Tape*
Sealant*
Adjustable
Small
Wrench*
Bucket*
Phillips
Screwdriver*
Basin
Wrench*
*not included
Installation
1. Ensure that the water supply below your sink is
completely shut off by turning the shutoff valves all the
way to the right.
Tip: Place a small bucket below your workspace to
catch any water that may drip during the installation
process.
OFF
2. Remove the T-connector, lock nut, and rubber
gasket from the spout body. Set the spout into the
center faucet hole.
Enid Widespread Faucet Installation Instructions
1
Advertisement
Related Manuals for Signature Hardware ENID 357449
Summary of Contents for Signature Hardware ENID 357449
- Page 1 ENID WIDESPREAD FAUCET INSTALLATION BEFORE YOU BEGIN Installation We recommend consulting a professional if you are 1. Ensure that the water supply below your sink is unfamiliar with installing plumbing fixtures. Signature completely shut off by turning the shutoff valves all the Hardware accepts no liability for any damage to the way to the right.
- Page 2 ENID WIDESPREAD FAUCET INSTALLATION 3. From under the counter, slide the rubber gasket back 5. From under the counter, slide the rubber gasket back onto the spout body and secure using the lock nut. onto the handle valve followed by the metal washer. Hand tighten the lock nut, then use a basin wrench to Secure the handle valve to the counter by hand finish tightening.
- Page 3 ENID WIDESPREAD FAUCET INSTALLATION 7. Use the provided braided water lines to connect the 9. Once installation is complete, turn the main water hot and cold handle valves to the spout’s T-connector. supply back on from underneath your sink. Check for Use an adjustable wrench to tighten, but be careful not any leaks underneath.
- Page 4 1. Dissasemble the drain assembly and lay the parts you are unfamiliar with installing bathroom aside, in the same order they were removed. See the fixtures and plumbing. Signature Hardware illustration below as a reference if needed. accepts no liability for any damage to the floor, walls, plumbing, or personal injury...
- Page 5 DRAIN INSTALLATION 6. Thread the lock nut onto the drain flange. Hand tighten until secure, then finish tightening with a basin wrench once the drain is properly aligned. Important: Be careful not to overtighten, which could crack a porcelain sink or stone countertop. COUNTERTOP COUNTERTOP COUNTERTOP...
- Page 6 DRAIN INSTALLATION 2. Apply plumber’s tape to the threading on the 4. Insert the drain flange and tailpiece through the top tailpiece, then reattach the tail piece to the pop-up of your sink’s drain hole. drain flange. COUNTERTOP COUNTERTOP 3. Slide the flat rubber gasket up the tailpiece until it 5.
