Operator's Manual
GT-2000
KEY
PART NUMBER QTY
DESCRIPTION
REMARKS
GRASS TRIMMER
PARTS CATALOG
MODEL GT-2000
SERIAL NUMBER 001001 & UP
ECHO, INCORPORATED
400 OAKWOOD ROAD
LAKE ZURICH, IL 60047
999222024234
09/99
1
Advertisement
Related Manuals for Echo GT-2000
Summary of Contents for Echo GT-2000
- Page 1 GT-2000 PART NUMBER QTY DESCRIPTION REMARKS GRASS TRIMMER PARTS CATALOG MODEL GT-2000 SERIAL NUMBER 001001 & UP ECHO, INCORPORATED 400 OAKWOOD ROAD LAKE ZURICH, IL 60047 999222024234 09/99...
- Page 2 GT-2000 ENGINE, EXTERNAL/INTERNAL/CRANKCASE/FAN HOUSING/COVER S/N 151954 & UP...
- Page 3 GT-2000 ENGINE, EXTERNAL/INTERNAL/CRANKCASE/FAN HOUSING/COVER PART NUMBER QTY DESCRIPTION REMARKS 10151448730 COVER, CYLINDER 10101147630 CYLINDER S/N 001001 - 151953 10101106560 CYLINDER S/N 151954 & UP 90016205022 BOLT, H.S. 5X22 10101044331 GASKET, CYLINDER BASE USE KIT 88900042031 10000044330 PISTON KIT (S/N 001001 - 151953) INCLUDES ITEMS 6, 7, 8 & 10 10000048730 PISTON KIT (S/N 151954 &...
- Page 4 GT-2000 STARTER, IGNITION, CLUTCH S/N 151955 & UP...
- Page 5 17722742030 GUIDE, ROPE ------------------ ROPE, STARTER USE BULK ROPE 999444 00040 DIA. 3mm (.12 IN.) X 890 mm (35 IN.) 17722042030 SPRING, REWIND 17723244332 CASE, STARTER 90016204016 SCREW 4X16 89011849130 LABEL, ECHO 16202152130 LEAD S/N 151955 & UP REVISED 09/99...
- Page 6 GT-2000 INTAKE, AIR CLEANER, EXHAUST, FUEL SYSTEM S/N 151387 & UP *OPTIONAL AIR FILTER (HD) FOR UNITS S/N 001001 - 151386...
- Page 7 GT-2000 INTAKE, AIR CLEANER, EXHAUST, FUEL SYSTEM PART NUMBER QTY DESCRIPTION REMARKS 90052800005 NUT, WING 5 S/N 001001 - 151386 21041752730 WING STUD S/N 151387 & UP 13031306560 COVER, AIR CLEANER S/N 001001 - 151386 13031306562 COVER, AIR CLEANER S/N 151387 & UP 13031006560 FILTER, AIR S/N 001001 - 151386...
- Page 8 GT-2000 DRIVE SHAFT, HANDLES, THROTTLE...
- Page 9 S/N 184858 & UP 900527 00006 NUT, WING 6 S/N 001001 - 184857 900030 00008 NUT 1/4-20 S/N 184858 & UP 890168 44330 LABEL, CAUTION 900242 05016 SCREW 5X16 699016 44330 KNIFE, CORD 900500 00005 NUT 5 890118 48830 LABEL, ECHO...
- Page 10 GT-2000 CARBURETOR S/N 001001 - 151954...
- Page 11 GT-2000 CARBURETOR S/N 001001 - 151954 PART NUMBER QTY DESCRIPTION REMARKS 12520048731 CARBURETOR C1U-K29 INCLUDES THE FOLLOWING ITEMS 12534452130 SCREW 12534252130 COVER, DIAPHRAGM DIAPHRAGM GASKET, DIAPHRAGM 12533942030 SCREW ARM, VALVE SPRING, COIL VALVE, NEEDLE 12532715130 CLIP PLUG, WELCH 12531642030 VALVE, THROTTLE 12531413930 SCREW 12531942030...
- Page 12 GT-2000 CARBURETOR S/N 151955 & UP...
- Page 13 GT-2000 CARBURETOR S/N 151955 & UP PART NUMBER QTY DESCRIPTION REMARKS 12520049030 CARBURETOR C1U-K47 INCLUDES THE FOLLOWING ITEMS 12534452130 SCREW 12534213210 COVER, DIAPHRAGM DIAPHRAGM GASKET, DIAPHRAGM 12533942030 SCREW ARM, VALVE SPRING, COIL VALVE, NEEDLE 12532715130 CLIP PLUG, WELCH 12531649030 VALVE, THROTTLE 12531413930 SCREW 12531942030...
- Page 14 GT-2000 ACCESSORIES 99944200240 99944200240 99944200240 99944200020 99944200020 99944200020 99944200240 99944200240 99944200020 99944200020 1 1 1 1 1 2 2 2 2 2 3 3 3 3 3 4 4 4 4 4 5 5 5 5 5 1 1 1 1 1 6 6 6 6 6 2 2 2 2 2 7 7 7 7 7...
- Page 15 GT-2000 ACCESSORIES PART NUMBER QTY DESCRIPTION REMARKS 99944200240 2-LINE SEMI-AUTOMATIC TRIMMER HEAD 69621052730 HOUSING 215703 EYELET 69621152730 SHAFT, BOLT 69621652730 SPRING 69621452730 SPOOL W/O LINE 215407 BUTTON 69621752730 COVER 99944200020 GT MANUAL HEAD DRUM, CORD REEL 69621442030 REEL, CORD 215100 WEED BUTCHER 215111 MAXI-CUT...
