Summary of Contents for Tangent EXEO CDP
-
Page 2: Table Of Contents
CONTENTS SAFETY INFORMATION IMPORTANT SAFETY INSTRUCTIONS ACCESSORIES CONNECTIONS REMOTE CONTROL INFORMATION FRONT PANEL INFORMATION REAR PANEL INFORMATION OPERATION AND FUNCTIONS TROUBLESHOOTING GUIDE SPECIFICATIONS... -
Page 3: Safety Information
SAFETY INFORMATION Caution: To reduce the risk of electric shock, do not remove Cover (or back) No user-serviceable parts inside. Refer servicing to qualified service personnel. This lightning flash with arrowhead symbol, within an equilateral triangle is intended to alert the user to the presence of uninstalled “dangerous voltage”... -
Page 4: Important Safety Instructions
IMPORTANT SAFETY INSTRUCTIONS CAUTION: READ THIS BEFORE OPERATING YOUR UNIT. READ AND FOLLOW INSTRUCTIONS: All the safety and operation instructions should be read before the product is operated. Follow all operation instructions within this manual. RETAIN INSTRUCTIONS: The safety and operation instructions should be retained for future reference. HEED WARNINGS: Comply with all warnings on the product and in the operation instructions. - Page 5 IMPORTANT SAFETY INSTRUCTIONS 13. SERVICING: Do not attempt to service this product yourself as opening or removing covers may expose you to dangerous voltage and may damage precision components. Refer all servicing to qualified service personnel. 14. LIGHTNING: For added protection during a lightning storm, or when it is left unattended and unused for long period of time, unplug it from the wall outlet and disconnect the antenna or cable system.
-
Page 6: Accessories
ACCESSORIES You should find the following accessories included: 1. Mains cord 2. RCA cord 3. Remote control + batteries AAA x 2 4. Operator’s Manual. -
Page 7: Connections
CONNECTIONS Amplifier systems How to connect the EXEO CDP to e.g. an EXEO AMP. -
Page 8: Remote Control Information
REMOTE CONTROL INFORMATION By using the provided remote control unit, the receiver can be REMOTE CONTROL OPERATION RANGE controlled from your listening position. To use the remote control unit, point it at the REMOTE SENSOR window of the Use the remote control unit within a range of about 7 receiver. - Page 9 Press to select the next track or chapter (MP3). Press and hold to fast forward and return to normal playback after release. 20. CDP Press this button to activate the EXEO CDP from Standby or to select MENU or INFO. 21. NET Does not apply.
-
Page 10: Front Panel Information
FRONT PANEL INFORMATION 1. Power On Press it to turn on the unit, press it again to turn off. 2. REWIND-FORWARD a. Rotate the knob clockwise or counterclockwise to scan the tracks forward or backwards. Press it once to stop the playback. (Note: when the unit is scanning fast forward, press the PREV-NEXT button once to resume normal playback. -
Page 11: Rear Panel Information
REAR PANEL INFORMATION ANALOG For connection to an amplifier e.g. EXEO AMP COAX Coaxial (75 ) SPDIF output. OPTICAL Optical (Toslink) SPDIF output AC MAINS INPUT For connection of mains voltage. Make sure that the plug is correctly inserted, and that the voltage corresponds to the text printed on the rear panel of the cabinet. -
Page 12: Operation And Functions
OPERATION AND FUNCTIONS ON, OFF and standby 1. Turn on the unit by pressing the Standby/ON button on the front panel or the CDP button on the remote control. 2. If you wish to turn off the unit to avoid any power consumption, you must remove the power cord. Load a disc To load a disc press the eject button on the remote control or on the front panel. -
Page 13: Troubleshooting Guide
TROUBLESHOOTING PROBLEM CAUSE/REMEDY No power when the unit is turn on - Switch on the current at the mains outlet socket. - Check that the plug has been correctly inserted into the socket. - The internal fuse has blown and must be replaced by a qualified service technician - The power cord has been damaged and must replaced No Sound... -
Page 14: Specifications
SPECIFICATIONS Power Parameter Value Note Standby Consumption 0.73W Idle Consumption 4.75W Play Consumption 5.6W Audio Parameter Value Note Line Level Outputs Connectors RCA (Phono), gold plated Case = Gnd, Tip = Signal RCA (Phono), gold plated Case = Gnd, Tip = Signal, 75Ω Coaxial Output Connector Optical Output Connector Toslink (JIS F05)
