Trinity GC-SL
S2707
Revision 1.02
Copyright © TYAN Computer Corporation, 2001-2002. All rights reserved. No part of this manual
may be reproduced or translated without prior written consent from TYAN Computer Corp.
All registered and unregistered trademarks and
ompany names contained in this manual are
property of the r respective owners including, but not limited to the following.
TYAN, Trinity GC-SL S2707 are trademarks of TYAN Computer Corporation.
Intel, Pentium, and combinations thereof are trademarks of Intel Corporation.
Adaptec is a trademark of Adaptec, Incorporated.
AMI, AMIBIOS are trademarks of American Megatrends, Incorporated.
Microsoft, Windows are trademarks of Microsoft Corporation.
National is a trademark of National Semiconductor.
Promise is a trademark of Promise Technology.
IBM, PC, AT, and PS/2 are trademarks of IBM Corporation.
Winbond is a trademark of Winbond Electronics Corporation.
Portable Document Format (PDF) is a trademark of Adobe Corporation.
Information contained in this document is furnished by TYAN Computer Corporation and has been
reviewed for accuracy and reliability prior to printing. TYAN assumes no liability whatsoever, and
disclaims any express or implied warranty, relating to sale and/or use of TYAN products including
liability or warranties relating to fitness for a particular purpose or merchantability. TYAN retains the
right to make changes to product descriptions and/or specifications at any time, without notice. In
no event will TYAN be held liable for any direct or indirect, incidental or consequential damage,
loss of use, loss of data or other malady resulting from errors or inaccuracies of information
contained in this document.
1
http://www.TYAN.com

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the TRINITY GC-SL and is the answer not in the manual?

Questions and answers

Subscribe to Our Youtube Channel

Summary of Contents for TYAN TRINITY GC-SL

  • Page 1 In no event will TYAN be held liable for any direct or indirect, incidental or consequential damage, loss of use, loss of data or other malady resulting from errors or inaccuracies of information contained in this document.
  • Page 2: Table Of Contents

    3.4 Power ……………………………………………Page 32 3.5 Boot ……………………………………………Page 32 3.6 Security ……………………………………………Page 32 3.7 Exit ……………………………………………Page 32 Chapter 4: Diagnostics ……………………………………………Page 33 4.0 Beep Codes ……………………………………………Page 33 4.1 Flash Utility ……………………………………………Page 33 Appendix: Glossary ……………………………………………Page 34 Technical Support ……………………………………………Page 39 http://www.TYAN.com...
  • Page 3: Before You Begin

    1x Cable set: 9-pin Serial 1x Trinity GC -SL User’s Manual 1x Trinity GC -SL Quick Reference guide 1x TYAN driver CD 1x Adaptec SCSI driver diskette (if optional SCSI included) 1x Promise RAID driver diskette (if optional RAID included)
  • Page 4: Chapter 1: Introduction

    The Trinity GC-SL is designed to fit a variety of applications, including the space-restricted 1U/2U chassis and pedestals. Remember to visit Tyan’s web si t e at http://www.tyan.com . There you can find information on all of Tyan’s products with FAQs, a complete distributors list, and BIOS setting explanations.
  • Page 5 Microsoft Windows XP port connector • Four USB ports (2 rear connectors and TYAN reserves the right to add support or 2 front side USB headers for an optional cable) discontinue support for any OS with or • PS/2 keyboard and mouse ports without notice.
  • Page 6: Chapter 2: Board Installation

    (1) Ground yourself properly before removing your motherboard from the antistatic bag. Unplug the power from your computer power supply and then touch a safely grounded object to release static charge (i.e. power supply case). For the safest conditions, Tyan recommends wearing a static safety wrist strap.
  • Page 7: Board Image

    2.0 – Board Image The following is an image of the S2707 Trinity GC-SL. The above photograph is purely representative. Due to engineering updates and new board revisions, certain components may change and or be repositioned. The picture above may or may not look exactly like the board you received.
  • Page 8: Board Parts

    2.1 – Board Parts This jumper diagram is representative of the latest board revision available at the time of publishing. The board you receive may or may not look exactly like the above diagram. The board parts are not to scale. http://www.tyan.com...
  • Page 9: Jumper Settings

    3-pin CPU fan connector with PWM fan control and fan speed reading FAN2 3-pin fan connector with PWM fan control and fan speed reading FAN3 3-pin fan connector with PWM fan control and fan speed reading FAN4 3-pin CPU fan connector with fan speed reading http://www.tyan.com...
  • Page 10: Front Panel Connector (J22)

    Pin 13 Pin 14 Pin 15 Pin 16 Reset Reset SLP_SW SLP_SW Intrusion (signal) (GND) (signal) (GND) Pin 1 Pin 2 Pin 3 Pin 4 Pin 5 Pin 6 Pin 7 Pin 8 Power Power Power LED + (green) (yellow) http://www.tyan.com...
  • Page 11: Clear Cmos (Jp1)

    Open (default) the jumper to set the 64-bit slot to PCI-X mode. Close the jumper to set the 64-bit slot to PCI mode. (JP11) PCI-X (PCI slot 1) Frequency Selection Open the jumper to set the slot to 100MHz. Close (default) the jumper to set the slot to 133MHz. http://www.tyan.com...
  • Page 12: Intel 82545Em Gigabit Nic (Jp22)

    (non-SCSI) or with optional AIC-7901. 2.7 – Onboard LAN - Intel 82545EM Gigabit NIC (JP22) Enabled Open the jumper(s) to enable the Onboard Intel 82545EM Gigabit (default) Ethernet chip. CLOSE the jumper(s) to disable the Onboard Intel 82545EM Gigabit Disabled Ethernet chip. http://www.tyan.com...
  • Page 13: Onboard Intel 82545Em Lan Led Header (J38)

    OPEN the jumper(s) to enable the Intel 82551QM/82540EM NIC chip. (default) Disabled CLOSE the jumper(s) to disable the Intel 82551QM/82540EM NIC port. 2.10 – Onboard Intel 82551QM/82540EM LAN LED Header (J40) Pin 1 LED_YEL+ Pin 2 LED_YEL Pin 3 LED_ GRN+ Pin 4 LED_GRN http://www.tyan.com...
  • Page 14: Onboard Ati Rage Xl Graphics

    Chassis Intrusion Header to sound an alarm when the chassis is being opened without authorization. Another 4-pin chassis intrusion header, J34, is included in the PCB design as a manufacturing loading option. (optional) Pin 4 Pin 3 Pin 2 Pin1 Intrusion http://www.tyan.com...
  • Page 15: Cpu Thermal Trip (J23)

    Cooling fans help keep the system more stable and operating reliably for its product life. +12Volts (Max. 1 Ampere) fans supported (FAN4 Max. 1.25 Ampere) PWM Fan Control Fan Tachometer/Speed Reading CPUFAN1 FAN2 FAN3 FAN4 2.18 – Serial Port Headers (COM 2) http://www.tyan.com...
  • Page 16: Usb Header (J30)

    Pin 8 Pin 10 USB_2+ USB_2- POWER Pin 1 Pin 3 Pin 5 Pin 7 Pin 9 USB_3- USB_3+ POWER Note: The external USB cable is optional and not included in standard shipping box. 2.20 – Mounting the Motherboard http://www.tyan.com...
  • Page 17 These studs are usually metal and are gold in color. Usually, the chassis manufacturer will pre-install the support studs. - Memory Type: The S2707 Trinity GC-SL only supports Registered DDR memory with ECC. Non-registered or non-ECC DDR memory modules will NOT be supported.
  • Page 18: Installing The Memory

    The following diagram shows the types of RAM modules you may encounter depending on your board: Here are a few key points to note before installing memory into your Trinity GC-SL: At least ONE Registered DDR module with ECC must be installed for the system...
  • Page 19 To avoid bending and damaging your motherboard, place it on its anti-static bag and onto a flat surface, and then proceed with memory installation. YOU MUST unplug the power connector to the motherboard before performing NOTE system hardware changes, to avoid damaging the board or expansion device. http://www.tyan.com...
  • Page 20: Installing The Processor & Heatsink

    Pentium 4 processors are supported by this motherboard. Check www.TYAN.com for CPU compatibility information. NOTE: Tyan is not liable for damage as a result of operating an unsupported configuration. The processor you choose may not look exactly like the one pictured above, nor will the socket look exactly the same.
  • Page 21 Once the bracket is aligned, press down on the four white pegs on the bracket until they insert securely, locking bracket onto motherboard. Then proceed to installing the heatsink. Instructions on how to install heatsinks should be provided with the heatsink itself. http://www.tyan.com...
  • Page 22: Attaching Drive Cables

    Attaching IDE drive cabling is simple. These cables are “keyed” to only allow them to be connected in the correct manner. Tyan motherboards have two on-board IDE channels, each supporting two drives. The black connector designates the Primary channel, while the white connector designates the Secondary channel.
  • Page 23 Usually signifies that the cable on the drive is on backwards, which is a common issue. Drive activity light is constantly on Reverse the cable at the floppy drive end and try again. http://www.tyan.com...
  • Page 24: Installing Add-In Cards

    Before continuing onto the next section on connecting External Devices, make sure everything is properly connected. Typically, jumpers and case wiring are the most common causes of troubleshooting frustration, http://www.tyan.com...
  • Page 25: Connecting External Devices

    The following diagram will detail the ATX port stack for this motherboard: S2707 Trinity GC-SL Optional 32-bit PCI 1Gbit Ethernet Port (Intel 82540EM) Depending on the individual motherboard design, the PS/2 keyboard and mouse ports may sometimes have their positions swapped.
  • Page 26: Installing The Power Supply

    +12V power wire. Power connectors for CPU Number of 12-V power wire Max. Current Rating VRM source 4--pin square connector only 12 Amperes 4--pin aux. connector only 6 Amperes 4--pin square plus 4-pin aux. 18 Amperes connectors http://www.tyan.com...
  • Page 27: Finishing Up

    In the rare circumstance that you have experienced difficulty, even though the instructions herein were followed, you can find help by asking your vendor for assistance. If they are not available for assistance, please find setup information and documentation online at our website or by calling your vendor’s support line. http://www.tyan.com...
  • Page 28: Chapter 3: Bios

    (hard drive, CD-ROM, etc). If one is found, the BIOS will launch that operating system and hand control over to it. You can enter the BIOS setup by pressing the [Delete ] key when the machine boots up and begins to show the memory count. http://www.tyan.com...
  • Page 29 Chipset section unless you are absolutely sure of the outcome. The Chipset defaults were carefully chosen by Tyan or your system manufacturer for the best performance and reliability. Even a seemingly small change to the Chipset setup options may cause the system to become unstable or unusable.
  • Page 30: Main Bios Setup

    Setting items on this screen to incorrect values may cause the system to malfunction Super IO Configuration IDE Configuration Floppy Configuration All settings discussed in following sections. Boot Settings Configuration Peripheral Device Configuration System Health Monitor Remote Access Configuration http://www.tyan.com...
  • Page 31: Chipset

    Allocate IRQ to PCI [Yes] Assigns an IRQ to PCI video card. [Enabled] USB Function Turns onboard USB ports On or Off. Legacy USB [Auto] Enables USB legacy devices and functions. Support ARMD Emulation [Hard Disk] Dependent on HDD specifications. Type http://www.tyan.com...
  • Page 32: Power

    Exit and save options. Exist Discarding Changes Exit but don’t save options. Load Optimal Defaults Loads the BIOS setup with default settings. Load Failsafe Defaults Loads the BIOS setup with more conservative settings Discard Changes Discards any changes made. http://www.tyan.com...
  • Page 33: Chapter 4: Diagnostics

    Please check our website for memory compatibility. Before calling your vendor or calling TYAN Tech Support, be sure that you know how many beeps your board made, and how long the beeps were. Also have other information such as your attached add-in cards, drives and OS to help speed up the support process and come to a possible solution faster.
  • Page 34: Appendix: Glossary

    SRAM instead of in the slower DRAM. Note that the cache is also much smaller than your system memory: a typical cache size is 512KB, while you may have as much as 4GB or more of system memory. http://www.tyan.com...
  • Page 35 EEPROM (Electrically Erasable Programmable ROM): also called Flash BIOS, is a ROM chip which can, unlike normal ROM, be updated. This allows you to keep up with changes in the BIOS programs without having to replace the BIOS chip. Tyan’s BIOS updates can be found at http://www.tyan.com .
  • Page 36 PCI (Peripheral Component Interconnect): a 32 or 64-bit local bus (data pathway) which is faster than the ISA bus. Local buses are those which operate within a single system (as opposed to a network bus, which connects multiple systems). http://www.tyan.com...
  • Page 37 Serial port: called as such because it transmits the eight bits of a byte of data along one wire, and receives data on another single wire (that is, the data is transmitted in serial form, one bit after another). Sleep/Suspend mode: in this mode, all devices except the CPU shut down. http://www.tyan.com...
  • Page 38 ZIF Socket (Zero Insertion Force socket): these sockets make it possible to insert CPUs without damaging the sensitive CPU pins. The CPU is lightly placed in an open ZIF socket, and a lever is pulled down. This shifts the processor over and down, guiding into the board and locking it into place. http://www.tyan.com...
  • Page 39: Technical Support

    Return Merchandise Authorization (RMA) number. The RMA number should be prominently displayed on the outside of the shipping carton and the package should be mailed prepaid. Tyan will pay to have the board shipped back to you. http://www.tyan.com...
  • Page 40 Danger of explosion if battery is incorrectly replaced. Replace only with the same or equivalent type recommended by manufacturer. Dispose of used battery according to manufacturer instructions and in accordance with your local regulations. Document #: D1485 - 102 http://www.tyan.com...
