  • Page 2 • 4mm turnbuckle wrench (TKR1103) - 5.5/7.0 two sided wrench (TKR1119) Disclaimer: Tekno RC is not responsible or liable for any property or personal damage, loss, or injury incurred as a a legally permitted RC track or facility. Warnings: Always double-check that your radio gear is working properly before operating vehicle. Never operate the vehicle indoors (unless the RC track is an indoor facility).
  • Page 3 Bag A TKR9114 *TKR5114XB TKRBB08165 (option) (overview) TKR5144B *TKR5144 TKR9150B (option) *TKR9150 (option) TKR9115B *TKR9115C (option) TKR9143 TKR5145B *TKR9145 TKR5145B (option) *TKR9145 (option) TKR9149 TKR9150B *TKR9149A *TKR9150 (option) (option) TKR5144B TKRBB08165 *TKR5144 (option) TKR9237 *TKR9117 TKR1325 x4 (option) TKR9114 *TKR5114XB (option) TKR9150B Step...
  • Page 4 Bag B TKR9114 *TKR5114XB (option) TKR5144B (overview) *TKR5144 TKR9143 (option) TKR9150B *TKR9150 (option) TKR9115B *TKR9115C (option) TKR9150B TKR5145B *TKR9150 *TKR9145 (option) (option) TKR5144B *TKR5144 (option) TKR9149 *TKR9149A (option) TKRBB08165 TKR5145B *TKR9145 (option) TKR9151 TKR1325 x4 TKR9114 *TKR5114XB (option) TKR9150B Step Step *TKR9150 (option)
  • Page 5 Bag C Front Gearbox (overview) TKR1603 TKR9268E TKR9416B TKR1443 TKRBB05145 TKR5075 TKR9416B TKR9153 TKR8777B TKR1226 TKRBB05145 TKR9017B TKR1301 TKR1301 TKR1525 TKR1222 TKR1525 x4pcs Step Step TKR1603 Thread Lock TKR9416B TKR5075 TKR1525 TKRBB05145 TKR9416B TKR1226 TKRBB05145 Grease TKR9153 TKR1222 Note: Apply a small Note: TKR1222 may not be required.
  • Page 6 Bag D Rear Gearbox (overview) TKR1603 TKR9416B TKRBB05145 TKR1443 TKR9181T TKR9153 TKR1525 TKR9095 TKR1201 x 4pcs TKR1226 TKRBB05145 TKR8727 TKR9181T TKR9269E TKR9017B TKR1222 TKR9416B TKR1301 TKR1525 x 4pcs TKR1525 x 6pcs TKR1603 Step Step Thread TKR1226 Lock TKRBB05145 TKR9416B TKR9095 TKR1525 TKR9416B TKRBB05145...
  • Page 7 Bag E (Sway Bar Bushings) Optional Sway Bars Rear End (sold separately) *TKR9190 - 2.2mm Assembly *TKR9192 - 2.3mm TKR9017B *TKR9193 - 2.4mm *TKR9090A *TKR9195 - 2.6mm (option) *TKR9196 - 2.7mm Stock Bushing - 3.0 *TKR9197 - 2.8mm Step *TKR9198 - 2.9mm TKR1601 *TKR9199 - 3.0mm TKR9290...
  • Page 8 Bag F Rear Hub/Camber Link Note: Make two of these assemblies. TKR9054B *TKR9054A Step (option) TKR9674 TKR9054B TKR9287 Thread Lock TKRBB12215 Optional CVD Setup TKR1603 TKRBB08165F Note: These parts are not included. TKR9674 *TKR8073 *TKR5071 (0mm) (Option) *TKR9671 (+2mm) *TKR5071X (light, 0mm) *TKR5071B (light, +1mm) Grease *TKR5071C (light, +2mm)
  • Page 9 Bag F TKR8052A Rear Camber Links TKR5187B TKR9059C Left Right Step TKR8052A TKR9093 TKR8052A TKR9093 TKR9059C TKR8052A TKR5187B Build Tip: Use some grease of Note: Notch always Actual Size Chapstick to make assembly and goes on left side of vehicle. future adjustments easier.
  • Page 10 Bag G (Sway Bar Bushings) Optional Sway Bars Front End (sold separately) *TKR9080 - 2.0mm Assembly *TKR9081 - 2.1mm *TKR9082 - 2.2mm TKR9017B *TKR9084 - 2.4mm *TKR9090A (option) *TKR9085 - 2.5mm *TKR9086 - 2.6mm Stock Bushing - 2.7 *TKR9088 - 2.7mm Step *TKR9089 - 2.8mm TKR1601...
  • Page 11 Bag H TKR1404 Front Spindle & TKR9047F Carrier Assembly *TKR9047A *TKR9047B *TKR9047C Step TKRBB12215 *TKR9047E *TKR9047G TKR9674 (+1mm) *TKR9047H *TKR5071 (0mm) (Option) TKR9087 *TKR9671 (+2mm) *TKR5071X (light, 0mm) *TKR5071B (light, +1mm) *TKR5071C (light, +2mm) (Option) Optional CVD Setup Note: These parts are not included. *TKR8073 TKR9141B Thread...
  • Page 12 Bag H Front Camber Links TKR8052A TKR5187B Step Left Right TKR9059C TKR9093 TKR8052A TKR9093 TKR8052A TKR9059C TKR8052A TKR5187B Front Camber Links Build Tip: Use some grease of Chapstick to make assembly and Actual Size Note: Notch always future adjustments easier. goes on left side of vehicle.

  • Page 13: Steering Assembly

    Bag I Step Steering TKR5103 TKR1403 Assembly TKR1403 Step Note: This piece is included TKRBB050825RS TKR8100C in the kit, and can be used in the place of the servo saver assembly, however it can damage your servo. TKRBB050825RS Run at your own risk. TKR9104 TKR9104 TKR5101X...
  • Page 14 Bag J Front End Assembly Step TKR9181T TKR1323 TKR9104 Step TKR9062B Note: Since the bumper is keyed TKR9102A into the chassis, you must back Thread Lock TKR1349 TKR1324 TKR1323 TKR1346 M3x10mm Flat Head Screw TKR1343 TKR1344 TKR1344 TKR1324 M3x12mm Flat Head Screw Step TKR1343 Note: Use assembly...

  • Page 15: Front/Rear Assembly

    Bag J TKR1443 TKR1447 Front/Rear Assembly TKR1443 Thread Step Lock Step TKR1211 M3 Lock Nut Flange Black TKR1221 M3x8mm Washer TKR1409 M3x20mm Button Head Screw TKR1409 TKR1443 M4x10mm Button Head Screw TKR1211 TKR1221 TKR1447 M4x16mm Button Head Screw...
  • Page 16 Bag K TKR9062B Center/Rear TKR9010 Assembly TKR9262 Step Thread TKR1344 TKR1343 x 5pcs Lock TKR1447 Step Step TKR1524 TKR1524 TKR1324 Thread M3x12mm Flat Head Screw Lock TKR9062B TKR9262 TKR9191 TKR1343 M4x10mm Flat Head Screw TKR1528 TKR1344 M4x12mm Flat Head Screw TKR9062B TKR1346 M4x15mm Flat Head Screw...
  • Page 17 Bag L Step Step Step Front Shock Assembly Refer to filling instructions on TKR1200 page 19 (stock ‘emulsion’ Step TKR6138 build), or page 20 (optional *TKR6130 ‘bladder’ build) during this step. *TKR6131 *TKR6160 TKR8730 TKR1264 *TKR6163 (Option) TKR8702 *TKR6003 TKR6017 *TKR6003B *TKR6017T (Option)

  • Page 18: Rear Shock Assembly

    Bag M Step Step Step Rear Shock Assembly Refer to filling instructions on TKR1200 page 19 (stock ‘emulsion’ build), or page 20 (optional Step TKR6139 ‘bladder’ build) during this step. *TKR6130 *TKR6131 TKR1264 TKR8730 *TKR6160 *TKR6163 (Option) TKR8702 *TKR6003 TKR6061 *TKR6003B Note: The kit supplied *TKR6061T...
  • Page 19 Shock Filling Instructions (Emulsion) For both front and rear shocks We've found it's easiest to complete steps 1 & 2 on each shock before moving on to step 3. By the time you've finished step 2 on the last shock, the first one will be ready for step 3. Step 1.
  • Page 20 Shock Filling Instructions (Bladder) For both front and rear shocks We've found it's easiest to complete steps 1-4 on each shock before moving on to step 5. By the time you've finished step 4 on the last shock, the first one will be ready for step 5. Step 1.
  • Page 21 Bag N TKR1525 TKR1221 ESC/Radio Tray install TKR1525 TKR1525 TKR1221 TKR1221 Step Note: Servo (not included) TKR1221 Note: We recommend using a servo with at least 300 oz/in torque. TKR9065 Step TKR5126 Note: Receiver (not included) TKR1601 Thread Lock TKR9065 TKR1401 TKR1325 TKR1325 x 4pcs...
  • Page 22 Bag N TKR9019 Battery Tray/Mud Guard TKR9026 TKR9026 Step TKR1344 TKR1344 TKR1402 TKR1402 Step TKR9024 TKR1402 TKR1402 TKR1228 Note: Motor, Pinion Gear, M4 Countersunk Washer Step Step & Set Screw for Pinion Gear (not included) TKR1346 TKR1344 TKR1228 M4x12mm Flat Head Screw For 36mm all condition, and 42mm onroad.

  • Page 23: Steering Linkage

    Bag O TKR1211 Actual Size Steering Linkage Step Step TKR9553M *TKR5253B TKR1221 (option) TKR5058A TKR5056 TKR5058A Note: A plastic steering servo horn is provided TKR5230 for convenience, TKR1327 however an aluminum steering servo horn is highly recommended. TKR5056 TKR1211 Step Servo Screw (not included) TKR1221...

  • Page 24: Final Assembly

    Bag P TKR1325 TKR1220 Final Assembly TKR1220 TKR9181T TKR8292W TKR9181T *TKR8292K Step *TKR8292Y (Option) Wing Hole Options (Use Dimples as Hole Cutting Guides) TKR1201 TKR1201 Most Downforce (Use as many holes as you see fit to fine tune the amount of downforce the wing creates.) Least Downforce TKR6686...
  • Page 25 Bag P Final Assembly Step TKR5116 Note: Wheels and tires (not included) *TKR5116B *TKR5116BR *TKR5116C (option) Step TKR1235 TKR1235 Note: It may be necessary to cut TKR1235 holes in the body for ventilation. Body Clip TKR5116 Wheel Nut...
  • Page 26 TKR9191 - Tapered Driveshaft (center, front, 7075, black ano, EB/ET48 2.0) TKR9194 - Sway Bar (rear, 2.5mm) TKR9236 - Decal Sheet (EB48 2.2) TKR5071X – Wheel Hubs (aluminum, lightened, gun metal ano, w/pins, 2pcs) TKR9268E - Shock Tower (split, front, 7075 CNC, GM ano, EB/NB48 2.x) TKR9269E - Shock Tower (rear, split, 7075 CNC, GM ano, EB/NB48 2.x)

  • Page 27: Setup Information

    Setup Information The purpose of making adjustments is to make the car go faster around the track, or to make it more controllable, or both if possible. A car that's easier to drive should produce lower, more consistent lap times. It will also inspire more confidence in the driver, which is always good when nerves start getting the best of you.
  • Page 28 Setup Information (continued) Front: vehicle may be twitchy and harder to drive. Thicker can increase on power steering and stability. We recommend Center: on-power rear traction but increases on-power steering and acceleration if traction is available. Thinner will Rear: steering and increases traction out of a corner. Going too thin will make your vehicle inconsistent, however. Thicker Using TKR9115C with TKR1261 will have less resistance to initial rotation versus TKR9115B, but will provide more consis- loads.
  • Page 29 Radio Adjustments and Information All Tekno RC vehicles are built out of the box with a neutral setup but are highly tunable to your individual driving needs. Before you start changing your setup on the car itself, it’s best to ensure you’re getting the best setup out of your radio.
  • Page 30 Ambient Temp: PLATE: (REAR) (FRONT) SWAY BAR BUSHINGS TOWER TKR9268E U - TKR9087 C - TKR8072 STANDOFF +2mm 115.5mm +4mm +4mm 500 CST TKR6138 TKR6032B TOWER TKR9269E U - TKR9087 (TKR9115C) U - TKR9287 U - TKR9287B C - TKR8072 STANDOFF - 4mm +2mm...

  • Page 31: General Warranty Information

    Conditions: • Shipping to Tekno RC or to you will not be included in the coupon. You will be responsible for shipping the part, along with the completed warranty form to the address listed below. You will also be responsible for the shipping cost of the replacement part.
  • Page 32 Tekno RC 10755 Scripps Poway Pkwy #598 San Diego CA 92131 info@teknorc.com...
