  • Page 2 5.5/7.0 two sided wrench (TKR1119) Disclaimer: Tekno RC is not responsible or liable for any property or personal damage, loss, or injury incurred as a result of using this product. This kit is meant for use by persons 14 years of age or older and in the strict con nes of a legally permitted RC track or facility.
  • Page 3 Bag A TKR6514 Center Di erential (overview) TKR5144 TKR6550 TKR6511 TKR6514 TKR6515 TKR6514 TKR6513X TKR6550 TKR6517 Note: Gears will feel a bit tight at first. Please run 3-4 packs on the track for break-in before evaluating the internal gear mesh. TKR6522 TKR1303 x4 TKR6514...
  • Page 4 Bag B TKR6514 Front and Rear Di erential (overview) TKR5144 TKR6550 TKR6511 TKR6514 TKR6515 TKR6514 TKR6513X TKR6550 TKR6517 Note: Gears will feel a bit tight at first. Please TKR6512 run 3-4 packs on the track for break-in before evaluating the internal gear mesh. TKR1303 x4 TKR6514 Once broken in, it is advised to rebuild each di...

  • Page 5: Steering Assembly

    Bag C Steering Assembly TKR6627 (overview) TKR6627 TKR6526 TKRBB040725 TKR6526 TKR6207 TKRBB040725 TKR6208 TKR6526 TKRBB040725 TKR1221 TKR1402 TKRBB040725 TKR1402 Step TKR6207 TKR1221 TKR6208 TKR6526 TKR6208 TKR1221 TKR6627 Step TKR6526 TKR6627 TKR1221 M3x8mm Washer TKRBB040725 TKR6526 TKR1402 M3x8mm Button Head Screw TKRBB040725 TKR6207 M3x6mm Ball Stud...
  • Page 6 Bag C (assembly from previous page) TKRBB10154 Front Bulkhead Assembly (overview) TKR1402 TKR1602 TKR6597 TKRBB05114 TKRBB05114 TKR6551 TKRBB10154 TKR6547 TKR1301 Step Step TKR1602 Thread Lock TKRBB040725 TKR6629 Note: Use a 5.5mm nut driver to install TKR6597 steering posts. TKRBB05114 TKRBB040725 TKR6519 TKRBB05114 TKR6551...
  • Page 7 Bag D TKR1403 TKR6208 Rear Bulkhead/ Wing Mount TKR6665 TKR1201 TKR6581 Assembly TKR6538 *TKR6582C *TKR6582XC TKRBB10154 TKR1602 (overview) (Option) TKR6519 TKR1405 TKR6597 TKR6551 TKR6546 TKRBB05114 TKR6547 TKR1402 TKR1301 4pcs TKR1403 TKR1411 TKR6208 TKR6597 TKR1602 Step Step Thread TKRBB05114 Lock TKR6551 TKR1403 Thread Lock...

  • Page 8: Rear End Assembly

    Bag E Rear End TKR6610 - 1.7mm Below options sold separately. Assembly *TKR6610 - 1.5mm *TKR6610 - 1.6mm *TKR6610- 1.8mm *TKR6610- 1.9mm Step (Option) TKR6547 TKR1601 Note: Do not over-tighten. (”C” Block) Step Stock Position Note: With these center dot inserts, Anti-Squat = 2°...
  • Page 9 Bag F Rear Hub/CVA Assembly TKR6856 Grease TKR6270R TKR1609 Note: This screw TKR6545 TKR6572 only needs to be Thread snug. Do not Step Lock over-tighten. TKR6856 TKRBB10154 TKRBB06124 TKR5571M Rear Hub Orientation TKR1229 *TKR5571A *TKR5571 Front *TKR1654X (+1mm) *TKR1654 (+1mm) (Option) Left Right...
  • Page 10 Bag F Rear Camber Links TKR6253 Left/Right x 2pcs Build Tip: Use some grease or Chapstick on the threads to help prevent “pop-o ” when TKR6250 adjustments are being made. Build Note: Hold the turnbuckle stationary Step with pliers and push the rod end hard onto the turnbuckle while turning at the same time.
  • Page 11 Bag G Front End (”B” Block) Assembly Stock Position Note: With these stock settings, Kick Up is: 10.5° For reference: With center dot inserts, Kick Up = 10° Step TKR6544 TKR6541 TKR6544 TKR1329 (”A” Block) Step Stock Position TKR1405 Note: With these center dot inserts, Arm Sweep = 0°...
  • Page 12 Bag H DO NOT SKIP Front Spindle/CVA Assembly THIS STEP! TKR1221 Note: These are steering stop screws. They provide a mechanical limit to the Step steering throw and make the car easier to drive by greatly improving the TKR1400 consistency of the steering. TKR6856 Grease TKR6573F...
  • Page 13 Bag H TKR6253 TKR6253 Steering Links TKR6252 Right Build Tip: Use some grease or Chapstick on the threads to help prevent “pop-o ” when adjustments are being made. TKR6252 Build Note: Hold the turnbuckle stationary with pliers and push the rod end hard onto the Left Step turnbuckle while turning at the same time.
  • Page 14 Bag H TKR6253 TKR6253 Front Camber Links TKR6252 Right Build Tip: Use some grease or Chapstick on the threads to help prevent “pop-o ” when adjustments are being made. TKR6252 Build Note: Hold the turnbuckle stationary Left with pliers and push the rod end hard onto the Step turnbuckle while turning at the same time.
  • Page 15 Bag I Thread Front/Center Lock TKR1401 Assembly Step TKR6546 TKR6501 TKR1322 TKR1323 Step TKR6538 TKR6586 TKR1323 TKR6530 TKR6634 Step TKR1322 M3x8mm Flat Head Screw TKR1323 M3x10mm Flat Head Screw TKR1323 TKR1323 Thread TKR1401 Lock M3x6mm Button Head Screw...
  • Page 16 Bag I TKR6634 Center/Rear Assembly TKR1402 TKR6634 Step TKRBB10154 Thread Lock TKR6634 *TKR6635C (Option) TKRBB10154 TKR6600 Step Step Use with Use with Use with No Riser 1mm Riser 2mm Riser TKR1211 Same / Reversed Note: Refer to TKR6538 page 25 when using the optional bulkhead risers.
  • Page 17 Bag J Step Step Step Front Shock Assembly Thread Lock Refer to filling TKR1245 instructions on Step page 19 during this step. TKR6705 *TKR6731 *TKR6732 (Option) TKR6712 Note: 1.7mm *TKR6712A piston with (Option) TKR6712 writing up. TKR6703 *TKR6703T (Option) TKR6707 Note: Use green slime or oil on shock shaft...

  • Page 18: Rear Shock Assembly

    Bag K Step Step Step Rear Shock Thread Assembly Lock Refer to filling TKR1245 instructions on page 19 during Step this step. TKR6705 *TKR6731 *TKR6732 (Option) TKR6712 *TKR6712A (Option) Note: 1.8mm piston with TKR6712 writing up. TKR6704 *TKR6704T (Option) TKR6707 Note: Use green slime or oil on shock shaft...
  • Page 19 Shock Filling Instructions For both front and rear shocks We've found it's easiest to complete steps 1 & 2 on each shock before moving on to step 3. By the time you've finished step 2 on the last shock, the first one will be ready for step 3. Step 1.

  • Page 20: Final Assembly

    Bag L TKR1403 Motor (not included) Step Final Assembly TKR1221 Steering servo (not included) Note: We recommend using a low profile servo with at least 150 oz/in torque and metal gears. Running less than TKR1522 our recommended rating will increase the chance of premature servo failure.
  • Page 21 Bag L Step Final Assembly Actual Size TKR6526 *TKR6563A 3.00 (Option) Step TKR6207 Note: Always press on with T logo visible. TKR6253 TKR5230 TKR6253 Step TKR6685 TKR6586 TKR1323 TKR1323 TKR5126 TKR1601 Step Cap Head Screw (not included) TKR1323 M3x10mm Flat Head Screw SERVO HORN ALIGNMENT Step TKR1601...
  • Page 22 Bag M Final Assembly TKR6538 Step TKR6634 *TKR6598C (Option) TKR1321 TKR1403 TKR1403 TKR1403 TKR1402 Thread Lock Step TKR6634 TKR1321 *TKR6635C TKR5230 M3x6mm Flat Head Screw (Option) TKR1402 M3x8mm Button Head Screw TKR1403 M3x10mm Button Head Screw TKR5230 M3x18 Threaded Rod Bag N Wing TKR1323...
  • Page 23 Bag N TKR6686 Body/Tires TKR6686 Step TKR6686 TKR6686 Thumb Screw Assembly Step TKR6586 *TKR6503C TKR6280 (Option) TKR5125 Wheels/Tires (not included) BATTERY INSTALLATION TKR6274 TKR6274 TKR6608 Step Note: For hook and loop tape placement. Look for indentations on the side walls of the body. TKR1235 Body Clip TKR1235...
  • Page 24 Bag O Step Optional Low Profile TKR1403 Servo Mounting Steering servo (not included) Note: We recommend using TKR1221 a low profile servo with at least 150 oz/in torque and metal Step TKR6526 gears. Running less than our *TKR6563A recommended rating will (Option) increase the chance of premature servo failure.
  • Page 25 Optional Di Shim Options Di Shims/ Option A: NO RISER Option B: 1mm RISER Option C: 2mm RISER Front Sway Bar (rough track) (most tuning options) (smooth track) Stock C and D Blocks Stock C and D Blocks (Higher Roll Center) (TKR6542B) (TKR6542B) Stock Camber Plate...

  • Page 26: Setup Information

    Set Up Information The purpose of making adjustments is to make the car go faster around the track, or to make it more controllable, or both if possible. A car that's easier to drive should produce lower, more consistent lap times. It will also inspire more confidence in the driver, which is always good when nerves start getting the best of you.

  • Page 27: Sway Bars

    7.5T 20/81 tooth 21/81 tooth back and forth without moving the pinion gear. Tekno RC is 8.5T 20/76 or 21/81 21/76 or 22/81 not responsible for damage done to your electronic equipment 10.5T...
  • Page 28 Maintenance: Performing regular maintenance will greatly improve your on track consistency and also extend the life of your vehicle. Going through critical areas of the vehicle regularly will also allow you to find possible issues before they become a problem that may cost you a race. Follow the guidelines below for maximum performance. Bearing Maintenance: Bearings should always be smooth and free in order to preform their function.
  • Page 29 TKR6500 - EB410 1/10th Comptetion 4x4 Buggy Complete Kit Parts List Shocks List TKR5125 - O-Ring (ESC tray, 3pcs) TKR6701 - Locking Shock Rod End and Spring Perch Set (13mm shocks) TKR5126 - Antenna tube (universal, w/ caps, 5pcs) TKR6703 - Shock Shafts (front, steel, EB410, 2pcs) TKR5230 - Steering linkage (M3x18mm threaded rod, 10pcs) TKR6704 - Shock Shafts (rear, steel, EB410, 2pcs) TKR5571M - Wheel Hexes (12mm, steel, lightened, 4pcs)

  • Page 30: Setup Sheet

    Setup Sheet Name: Date: Event: Box Setup (starting point) Track: Size: Traction: Indoor Outdoor Small Medium Large High Surface: Type: Smooth Bumpy Rutted Dirt Clay Carpet Astroturf Condition: Dusty Muddy Bumpsteer/Ackermann/Steering Stop: Suspension: Shocks: WASHERS WASHERS FRONT REAR FRONT REAR WASHERS RIDE HEIGHT 18mm...
  • Page 32 Tekno RC 10755 Scripps Poway Pkwy #598 San Diego CA 92131...
