Glenair 600-061 Operating Instructions Manual

Qpl qualified one piece knife and blade banding tool
Hide thumbs

Advertisement

Quick Links

Download this manual
QPL Qualified
One Piece Knife and Blade
Banding Tool
600-058 and 600-061
Operating Instructions
© 07/21 Glenair, Inc.
990-99344
CAGE Code 06324
Printed in U.S.A.
GLENAIR, INC. • 1211 AIR WAY • GLENDALE, CA 91201-2497
818-247-6000 • FAX 818-500-9912 www.glenair.com
1

Advertisement

loading
Need help?

Need help?

Do you have a question about the 600-061 and is the answer not in the manual?

Questions and answers

Related Manuals for Glenair 600-061

Summary of Contents for Glenair 600-061

  • Page 1 QPL Qualified One Piece Knife and Blade Banding Tool 600-058 and 600-061 Operating Instructions © 07/21 Glenair, Inc. 990-99344 CAGE Code 06324 Printed in U.S.A. GLENAIR, INC. • 1211 AIR WAY • GLENDALE, CA 91201-2497 818-247-6000 • FAX 818-500-9912 www.glenair.com...
  • Page 2 1. Use only genuine Glenair/Band-It bands. Other manufacturer’s bands may damage tool. 2. Use only .240" wide bands with 600-058 tool and .120" wide bands with 600-061 tool. 3. Calibrate Standard band tool to 150 ±5 Lbs, Micro tool to 80 ±5 Lbs.
  • Page 3 Squeeze the band insertion and release lever © 07/21 Glenair, Inc. 990-99344 CAGE Code 06324 Printed in U.S.A. GLENAIR, INC. • 1211 AIR WAY • GLENDALE, CA 91201-2497 818-247-6000 • FAX 818-500-9912 www.glenair.com...
  • Page 4 Make adjustments as necessary and finish tightening with tensioning lever (2) as described above.Instructional videos are available on the Glenair website: www.glenair.com/banding/ Tension release lever © 07/21 Glenair, Inc. 990-99344 CAGE Code 06324 Printed in U.S.A. GLENAIR, INC. • 1211 AIR WAY • GLENDALE, CA 91201-2497 818-247-6000 • FAX 818-500-9912 www.glenair.com...
  • Page 5 2. Band can be removed by lifting buckle with a screwdriver or diagonal cutters. © 07/21 Glenair, Inc. 990-99344 CAGE Code 06324 Printed in U.S.A. GLENAIR, INC. • 1211 AIR WAY • GLENDALE, CA 91201-2497 818-247-6000 • FAX 818-500-9912 www.glenair.com...
  • Page 6 Pull down at 45° angle to remove knife . Push pin out Pull knife off in a downward motion 45° © 07/21 Glenair, Inc. 990-99344 CAGE Code 06324 Printed in U.S.A. GLENAIR, INC. • 1211 AIR WAY • GLENDALE, CA 91201-2497 818-247-6000 • FAX 818-500-9912 www.glenair.com...

  • Page 7: Tool Calibration

    601-202 Standard test bands (4) fifty 601-217 Nano test bands (5) 601-205 calibration key (6) 601-218 Adjustable mounting bracket (7) Data logging software (8) 600-058 tool adapter (9) 600-067 and 601-104 tool adapter (10) 600-061, 600-068 and 601-105 (11) 601-109, 601-110, 601-100, 601- 106 tool adapter (12) 601-101, 601-107, 601-122, and 601-123 (13) 601-108 and 601-118.
  • Page 8 (included with pneumatic banding tool kits). Tool Repair and Refurbishment Glenair provides repair and refurbishment services for Band-Master® ATS tools. Typical services include calibration along with replacements of cutter knife and cut-off blade. Simply send the tool to Glenair: ATTN: Customer Service Glenair, Inc.
  • Page 9 Extended Length Band, Supplied Flat 600-083 Extended Length Band, Supplied Pre-Coiled 600-083-1 Cut-Off Blade and Knife Kit 601-329 © 07/21 Glenair, Inc. 990-99344 CAGE Code 06324 Printed in U.S.A. GLENAIR, INC. • 1211 AIR WAY • GLENDALE, CA 91201-2497 818-247-6000 • FAX 818-500-9912 www.glenair.com...
  • Page 10 _____________________________________________________________ _____________________________________________________________ _____________________________________________________________ _____________________________________________________________ _____________________________________________________________ _____________________________________________________________ _____________________________________________________________ _____________________________________________________________ _____________________________________________________________ _____________________________________________________________ _____________________________________________________________ _____________________________________________________________ _____________________________________________________________ _____________________________________________________________ © 07/21 Glenair, Inc. 990-99344 CAGE Code 06324 Printed in U.S.A. GLENAIR, INC. • 1211 AIR WAY • GLENDALE, CA 91201-2497 818-247-6000 • FAX 818-500-9912 www.glenair.com...
  • Page 11 _____________________________________________________________ _____________________________________________________________ _____________________________________________________________ _____________________________________________________________ _____________________________________________________________ _____________________________________________________________ _____________________________________________________________ _____________________________________________________________ _____________________________________________________________ _____________________________________________________________ _____________________________________________________________ _____________________________________________________________ _____________________________________________________________ _____________________________________________________________ © 07/21 Glenair, Inc. 990-99344 CAGE Code 06324 Printed in U.S.A. GLENAIR, INC. • 1211 AIR WAY • GLENDALE, CA 91201-2497 818-247-6000 • FAX 818-500-9912 www.glenair.com...
  • Page 12 Consult factory for additional recommendations for technical information on overall shields with distributed individual shields on common terminations. © 07/21 Glenair, Inc. 990-99344 CAGE Code 06324 Printed in U.S.A. GLENAIR, INC. • 1211 AIR WAY • GLENDALE, CA 91201-2497 818-247-6000 • FAX 818-500-9912 www.glenair.com...
