Summarization of Contents
Intel CPU Cooler Installation
Install the Intel Backplate
Secure the Intel backplate (D) to the motherboard for cooler mounting.
Install Intel Standoff Screws
Attach the correct Intel standoff screws (A, B, or C) to the motherboard socket.
Install Fans and Radiator
Mount radiator and fans (L, M, N, K) to the PC case, recommending air-intake.
Install the Pump Unit
Align the pump bracket (E) and attach thumbscrews (F) to the standoffs.
AMD AM4 CPU Cooler Installation
Install AMD AM4 Mounting Bracket
Remove Intel bracket and install AMD AM4 bracket (H) onto pump.
Install Fans and Radiator
Mount radiator and fans (L, M, N, K) to the PC case, recommending air-intake.
Prepare Motherboard for Installation
Remove existing AMD AM4 mounting brackets from the motherboard.
Install AMD AM4 Standoff Screws
Attach AMD AM4 standoffs (G) to the CPU socket and secure them.
Install the Pump Unit
Align pump bracket with AMD AM4 standoffs and secure with thumbscrews.
AMD sTRX4 CPU Cooler Installation
Install AMD sTRX4 Mounting Bracket
Remove Intel bracket and install AMD sTRX4 bracket (I) onto pump.
Install AMD sTRX4 Standoff Screws
Attach AMD sTRX4 standoffs (J) to the CPU socket and secure them.
Install Fans and Radiator
Mount radiator and fans (L, M, N, K) to the PC case, recommending air-intake.
Install the Pump Unit
Align pump bracket with standoffs and secure with thumbscrews (F).
Connecting Components
Connect Fans and Pump to Commander CORE
Connect pump 24-pin, tach cable, and fan cables/RGB leads to Commander CORE.
Connect Commander CORE and LCD Module
Connect Commander CORE to motherboard USB 2.0 header and power supply.
Frequently Asked Questions (FAQ)
Fan Airflow Direction
An arrow on the fan indicates airflow direction.
Reusing Thermal Paste
Pre-applied thermal paste must be cleaned and replaced for re-installation.
Radiator Orientation
Install radiator with tubes at the bottom or inverted, ensuring highest point is above the pump.
Troubleshooting Red Lights/Malfunction
Check connections, update iCUE firmware, or contact support for issues.
