DeVillbiss Air Power Company DAPC D25690 Operator's Manual

Devillbiss air power company pressure washer operator's manual
Hide thumbs
Table of Contents

Advertisement

Quick Links

Download this manual
Pressure
Washer
Operator's Manual
Record All Information
for future reference:
Brand:
Purchase Date:
Model #:
Serial #:
Questions? 1-800-888-2468
Register your product online
www.devap.com
READ AND SAVE THESE INSTRUCTIONS
CONSUMER INFORMATION . . . . . . . . . . . .2
CARTON CONTENTS . . . . . . . . . . . . . . . . . .6
ASSEMBLY INSTRUCTIONS . . . . . . . . . . .7-8
OPERATING INSTRUCTIONS . . . . . . . . .8-12
MAINTENANCE . . . . . . . . . . . . . . . . . . .13-14
STORAGE . . . . . . . . . . . . . . . . . . . . . . . . . . .15
TROUBLE SHOOTING GUIDE . . . . . . .16-17
WARRANTY . . . . . . . . . . . . . . . . . . . . . . . . .18
QUICK FACTS . . . . . . . . . . . . . . . . . . . . . . .19
ESPAÑOL . . . . . . . . . . . . . . . . . . . . . . . .21-40
FRANÇAISE . . . . . . . . . . . . . . . . . . . . . .41-60
Part No. D25690 Rev. 1

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the DAPC D25690 and is the answer not in the manual?

Questions and answers

Related Manuals for DeVillbiss Air Power Company DAPC D25690

Summary of Contents for DeVillbiss Air Power Company DAPC D25690

  • Page 1: Table Of Contents

    Pressure Washer Operator’s Manual Record All Information for future reference: Brand: Purchase Date: Model #: Serial #: Questions? 1-800-888-2468 Register your product online www.devap.com READ AND SAVE THESE INSTRUCTIONS CONSUMER INFORMATION ... .2 CONSUMER SAFTEY INFORMATION .

  • Page 2: Consumer General And Service Information

    Please read and follow these instructions for proper use and maintenance. • Please take the time now to register your pressure washer online at www.devap.com. • All sales of pressure washers are final. Do not return this product to the retailer.

  • Page 3: Safety Guideline/Definitions

    • Never operate pressure washer in an area containing dry brush or weeds. • Always keep pressure washer a mini- mum of four feet away from surfaces (such as houses, automobiles, or live plants) that could be damaged from muffler exhaust heat •...
  • Page 4 BURN injury or death. D25690 HOW TO PREVENT IT • Operate pressure washer in a well ventilated area. Avoid enclosed areas such as garages, basements, etc. • Never operate unit in a location occupied by humans or animals.
  • Page 5 • Do not use chlorine bleach or any other corrosive compound. • Become familiar with the operation and controls of the pressure washer. • Keep operating area clear of all persons, pets, and obstacles. • Do not operate the product when fatigued or under the influence of alcohol or drugs.

  • Page 6: Carton Contents

    Operating without flow of water will result in equipment damage. Operating the pressure wash- er with water supply shutoff will void your warranty. You should never run this pressure washer for more than 2 minutes without pulling the trigger to allow cool water to enter the pump and the heated (recirculated) water to exit.

  • Page 7: Assembly Instructions

    ASSEMBLY INSTRUCTIONS Place handle assembly onto frame and connect handle to frame. Attach high pressure hose to gun. Tighten securely. Connect wand to gun. Tighten securely. Assemble grommet kit and quick-connect nozzles as described in instructions supplied. Add engine oil (supplied) to engine. Refer to engine manual supplied by engine manufacturer for correct procedure.

  • Page 8: Operating Instructions

    Save this manual for future reference. Engine BASIC ELEMENTS OF A PRESSURE WASHER High Pressure Pump: Increases the pressure of the water supply. Engine: Drives the high pressure pump. High Pressure Hose: Carries the pressurized water from the pump to the gun and wand.

  • Page 9: Basic Elements Of Engine

    Water Supply: All pressure washers must have a source of water. The minimum requirements for a water supply are 20 PSI and 5 gallons per minute. PRESSURE WASHER OPERATING FEATURES PRESSURE ADJUSTMENTS The pressure setting is preset at the factory to achieve optimum pressure and cleaning.
  • Page 10 The 0º, 15º , 25º, and 40º nozzles are high pressure nozzles. The chemical nozzle is a low pressure nozzle. The nozzles are housed in receptacles on the panel of the pressure washer handle. Colors on the panel identify nozzle location and spray pattern.
  • Page 11 HOW TO SIPHON CHEMICALS AND CLEANING SOLVENTS Siphoning chemicals or cleaning solvents is a low pressure operation. NOTE: Use only soaps and chemicals designed for pressure washer use. Do not use bleach. To siphon chemicals: Press chemical hose onto barbed fitting located near high pressure hose connection of pump as shown.

  • Page 12: Shutting Down

    STARTING Prior to starting, refer to your engine manual for proper starting procedures for your engine type. In a well ventilated outdoor area Add fresh high quality unleaded gasoline with a pump octane rating of 86 or higher. Do not overfill. Wipe up spilled fuel before starting the engine.

  • Page 13: Maintenance

    DO NOT smoke or work near open flames while performing maintenance. To ensure efficient operation and longer life of your pressure washer, a routine maintenance schedule should be prepared and followed. If the pressure washer is used in unusual conditions, such as high-temperatures or dusty conditions, more frequent maintenance checks will be required.

  • Page 14: How To Clean The Water Inlet Filter

    Reassemble the nozzle to the wand. Reconnect wand to gun and turn on water supply. Start pressure washer and place wand into high pressure setting to test. HOW TO CLEAN THE WATER INLET FILTER This screen filter should be checked periodically and cleaned if necessary.

  • Page 15: Storage

    Reconnect spark plug wire. Drain all water from high pressure hose, coil it, and store it in cradle of the pressure washer handle. 10. Drain all water from spray gun and wand by holding spray gun in a vertical position with nozzle end pointing down and squeezing trigger. Store in gun/hose holder.

  • Page 16: Trouble Shooting Guide

    TROUBLE SHOOTING GUIDE PROBLEM No fuel. Engine will not Low oil (if equipped with low oil start (see Engine shutdown). Manual for further engine Pressure builds up after two pulls troubleshooting) on the recoil starter or after initial use. Not primed or choked. Spark plug wire not attached.
  • Page 17 PROBLEM Wand not in low pressure. Will not draw chemicals Chemical filter clogged. Chemical screen not in chemical Chemical too thick. Pressure hose is too long Chemical build up in chemical injector. Worn seal or packing No or low pressure Worn or obstructed valves.

  • Page 18: Limited Warranty

    DeVilbiss Air Power Company warrants to the original purchaser who uses the product in a consumer application (personal, residential or household usage) that all products covered under this warranty are free from defects in material and workmanship for one year from the date of purchase. All products covered by this limited warranty which are used in commercial applications (i.e., income producing) are warranted to be free of defects in material and workmanship for 90 days from the date of original purchase.

  • Page 19: Quick Facts

    ENGINE Add stabilizer to fuel tank and run engine for 5 minutes before storage. Always turn on the water before starting the engine. Use only soaps and chemicals designed for pressure washer use. SOAP CHEMICALS Keep nozzle unclogged. Refer to manual for cleaning procedures.
  • Page 20 NOTES 20- ENG D25690...
