Thunder h2000M
S3992
Version 1.0
Copyright
Copyright © TYAN Computer Corporation, 2006. All rights reserved. No part of
this manual may be reproduced or translated without prior written consent from
TYAN Computer Corp.
Trademark
All registered and unregistered trademarks and company names contained in
this manual are property of their respective owners including, but not limited to
the following.
TYAN, Taro and Thunder h2000M are trademarks of TYAN Computer
Corporation.
AMD, Opteron, and combinations thereof are trademarks of AMD Corporation.
Nvidia and nForce are trademarks of Nvidia Corporation
Microsoft, Windows are trademarks of Microsoft Corporation.
SuSE,is a trademark of Novell.
Linux is a trademark of Linus Torvalds
IBM, PC, AT, and PS/2 are trademarks of IBM Corporation.
Winbond is a trademark of Winbond Electronics Corporation.
Notice
Information contained in this document is furnished by TYAN Computer
Corporation and has been reviewed for accuracy and reliability prior to printing.
TYAN assumes no liability whatsoever, and disclaims any express or implied
warranty, relating to sale and/or use of TYAN products including liability or
warranties relating to fitness for a particular purpose or merchantability. TYAN
retains the right to make changes to product descriptions and/or specifications
at any time, without notice. In no event will TYAN be held liable for any direct or
indirect, incidental or consequential damage, loss of use, loss of data or other
malady resulting from errors or inaccuracies of information contained in this
document.
1
http://www.tyan.com

Advertisement

Table of Contents
loading

Related Manuals for TYAN THUNDER H2000M

Summary of Contents for TYAN THUNDER H2000M

  • Page 1 In no event will TYAN be held liable for any direct or indirect, incidental or consequential damage, loss of use, loss of data or other malady resulting from errors or inaccuracies of information contained in this document.

  • Page 2: Table Of Contents

    Chapter 4: Diagnostics Beep Codes Page 81 Flash Utility Page 81 AMIBIOS Post Code Page 82 Appendix I: SMDC Information Page 85 Appendix II: How to Make a Driver Diskette Page 87 Glossary Page 89 Technical Support Page 95 http://www.tyan.com...
  • Page 3 1 x Ultra-DMA-100/66 IDE cable 1 x USB2.0 cable 1 x COM Port cable 1 x Thunder h2000M User’s Manual 1 x Thunder h2000M Quick Reference Guide 1 x TYAN driver CD 1 x I/O shield 2 x CPU Retention Frame and Back Plate If any of these items are missing, please contact your vendor/dealer for replacement before continuing with the installation process.
  • Page 4 NOTE http://www.tyan.com...

  • Page 5: Chapter 1: Introduction Congratulations

    1.1 - Congratulations You have purchased one of the most powerful server solutions available. The Thunder h2000M (S3992) is a high-end server motherboard, based on the ServerWorks BCM5780 & BCM5785 chipsets. It also includes the NS PC87417 Super I/O and SMSC EMC6D103 Hardware Monitoring chipsets.
  • Page 6 - Adaptec AIC-7901/7902 single/dual- Tyan 2 x 9 front panel pin header channel Ultra320 SCSI controller Tyan 2 x 6 front panel pin header for - Adaptec Host RAID 0, 1, 10 supported LAN/ID LED Tyan 2 x 7 pin header (2.0mm) for...

  • Page 7: Chapter 2: Board Installation

    Chapter 2: Board Installation Precautions: The Thunder h2000M supports SSI, EPS12V type power supplies (24pin + 8pin) and will not operate with any other types. For proper power supply installation procedures see page 36. DO NOT USE ATX 2.x or ATXGES power supplies as they will damage the board and void your warranty.

  • Page 8: Board Image

    This picture is representative of the latest board revision available at the time of publishing. The board you receive may or may not look exactly like the above picture. The following page includes details on the vital components of this motherboard. http://www.tyan.com...

  • Page 9: Block Diagram

    2.2 - Block Diagram Thunder h2000M (S3992) Block Diagram http://www.tyan.com...

  • Page 10: Jumper Legend

    This diagram is representative of the latest board revision available at the time of publishing. The board you receive may not look exactly like the above diagram. Jumper Legend ©© OPEN - Jumper OFF, without jumper cover ©© CLOSED – Jumper ON, with jumper cover http://www.tyan.com...
  • Page 11 PCI-X Frequency Select Jumper JP7/JP9 (Close 1-2) Default, based on Card (Close 2-3) 100MHz or less Clear CMOS Jumper JP10 (Close 1-2) Default (Close 2-3) Clear CMOS LED1 Standby Power LED LED2 Power On LED J43/J46/J60 Reserved for OEM only http://www.tyan.com...
  • Page 12 CPUFAN2 FAN6 FAN1 CPUFAN1 FAN5 FAN2 FAN4 FAN3 http://www.tyan.com...
  • Page 13 FAN6 Pin 1 Pin 2 Pin 3 Pin 4 +12V Tachometer +12V J7: FAN5 J8: FAN6 Tachometer J9: COM2 Header Use these pin definitions to connect a port to COM2. Signal Signal http://www.tyan.com...
  • Page 14 http://www.tyan.com...
  • Page 15 GND1 LFRAME# GND2 PCI_CLK GND3 PCIRST# GND4 I2C1CLK I2C1DA GND5 I2C4CLK I2C4DA GND6 I2C3CLK For connection with Tyan Server I2C3DA 5VSB1 I2C2CLK I2C2DA Management Daughter Card (SMDC). 5VSB2 GND7 PWRBTN# PCIPME# The SMDC connector is only compatible RSTBTN# COM_TXD OEMBTN# COM_RXD with Tyan M3291 (SMDC).
  • Page 16 http://www.tyan.com...
  • Page 17 J42: SO-DIMM Socket Connect SAS/SATA II Daughter Card (compatible with Tyan M9000-10, M7901/7902 Ultra 320 SCSI “TARO” card). J47: LAN & ID LED and ID Switch Connector Use these pin definitions to connect a port to LAN & ID LED and ID Switch.
  • Page 18 http://www.tyan.com...
  • Page 19 (Default) - Enable VGA Disable VGA JP4: LAN3 Enable/Disable Jumper (Default) - Enable LAN3 (Intel 82551) Disable LAN3 JP5/JP8: PCI-X Mode Select Jumper (Default) - Based on card Force to run at PCI mode (only 66 or 33 MHz) http://www.tyan.com...
  • Page 20 JP10 http://www.tyan.com...
  • Page 21 The CMOS will be cleared when the screen is on. Finally shut down the power, replace JP10 to the default setting (1- 2), power on the system again after done. (Default) http://www.tyan.com...

  • Page 22: Tips On Installing Motherboard In Chassis

    Some chassis’ include plastic studs instead of metal. Although the plastic studs are usable, TYAN recommends using metal studs with screws that will fasten the motherboard more securely in place. Below is a chart detailing what the most common motherboard studs look like and how they should be installed.

  • Page 23: Installing The Processor(S)

    2.5 - Installing the Processor(s) Your S3992 supports the latest processor technologies from AMD. Check the TYAN website for latest processor support: http://www.tyan.com Figure 1. Exploded View of Thermal Solution AMD PIB Platforms based on AMD Socket F Processor http://www.tyan.com...
  • Page 24 PCB. The remaining four shorter PEM nuts should automatically fit the 4 holes on the PCB as shown in the following pictures . 4 PEM nuts Let 2 upper & should fit 4 lower-middle PEM nuts pass holes. through the holes. http://www.tyan.com...
  • Page 25 Locate four screw holes on socket and screw the socket to the PCB board. NOTE: Do not assemble CPU before securing socket with screws. Inspect Socket F assembly to PCB. The Socket F must be tightly attached onto the PCB. There must NOT be any gap between stand off the PCB. http://www.tyan.com...
  • Page 26 Vertically check if the CPU is seated well in the socket housing. If not, take out the CPU, with vertical motion only, and repeat the above steps. NOTE: The alignment keys must be located in the notches of the package. http://www.tyan.com...
  • Page 27 Close the socket. Rotate the load plate onto the package lid. Engage the load lever while pressing down lightly onto the load plate. Secure the lever near the hook end under the retention tab. Repeat this procedure for the second processor if necessary. http://www.tyan.com...

  • Page 28: Installing The Memory

    Before installing memory, ensure that the memory you have is compatible with the motherboard and processor. Only DDR2- 667/533/400 DIMM modules are required. Check the TYAN Web site at: www.tyan.com for details of the type of memory recommended for your motherboard.
  • Page 29 Align the memory module with the socket. The memory module is keyed to fit only one way in the socket. Key slot Seat the module firmly into the socket by gently pressing down until it sits flush with the socket. The locking levers pop up into place. http://www.tyan.com...
  • Page 30 Key points to note before installing memory into Thunder h2000M: For optimal dual-channel DDR operation, always install memory in pairs beginning with CPU1_DIMMA3 and CPU1_DIMMB3. Memory modules of the same type and density are required for dual-channel DDR operation. Mismatched memory may cause system instability.

  • Page 31: Attaching Drive Cables

    Attaching Serial ATA Cables The Thunder h2000M is also equipped with 4 Serial ATA (SATA) channels. Connections for these drives are also very simple. There is no need to set Master/Slave jumpers on SATA drives.
  • Page 32 Attach first floppy drive (drive A:) to the end of the cable with the twist in it. Drive B: is usually connected to the next possible connector on the cable (the second or third connector after you install Drive A:). http://www.tyan.com...

  • Page 33: Installing Add-In Cards

    Do not force any add-in cards into any slots if they do not seat in place. It is better to try another slot or return the faulty card rather than damaging both the motherboard and the add-in card. http://www.tyan.com...

  • Page 34: Installing Optional So-Dimm Modules

    2.9 - Installing Optional SO-DIMM Modules Your Thunder h2000M S3992 motherboard is equipped with an optional proprietary SO- DIMM connector. The SO-DIMM connector can be us ed for expansion cards to provide such features as, additional SAS/SATA II or SCSI support. For details of available expansions cards, visit the TYAN website at http://www.tyan.com.

  • Page 35: Connecting External Devices

    LAN1 and LAN2 LED Color Definition The two onboard LAN ports have green LEDs to indicate the LAN status. The chart below illustrates the different LED states. LAN1 and LAN2 Link/Activiey LED Scheme Left LED Right LED Left Right Activity Link Green (Blink) Green http://www.tyan.com...

  • Page 36: Installing The Power Supply

    2.11- Installing the Power Supply There are two power connectors on your Thunder h2000M. The Thunder h2000M requires an EPS12V (24 pin + 8 pin) power supply to boot. Please be aware that ATX 2.x and ATXGES power supplies are compatible with the board and can damage the motherboard and/or CPU(s).

  • Page 37: Finishing Up

    In the rare circumstance that you have experienced difficulty, you can find help by asking your vendor for assistance. If they are not available for assistance, please find setup information and documentation online at our website or by calling your vendor’s support line. http://www.tyan.com...
  • Page 38 NOTE http://www.tyan.com...

  • Page 39: Chapter 3: Bios

    Use the left/right (ß à) arrow keys to make a selection. To display a sub-menu (A pointer “4” marks all sub menus) Use the arrow keys to move the cursor to the sub menu you want. Then press <Enter>. http://www.tyan.com...

  • Page 40: Bios Menu Bar

    Execute command or select submenu Getting Help Pressing [F1] will display a small help window that describes the appropriate keys to use and the possible selections for the highlighted item. To exit the Help Window, press [ESC] or the [F1 ] key again. http://www.tyan.com...
  • Page 41 Chipset section unless you are absolutely sure of the outcome. The Chipset defaults were carefully chosen by TYAN or your system manufacturer for the best performance and reliability. Even a seemingly small change to the Chipset setup options may cause the system to become unstable or unusable.

  • Page 42: Bios Main Menu

    F10 Save and Exit System Time [22:21:21] ESC Exit System Date [Tue 01/01/2002] Feature Option Description Main Set the system time System Time HH : MM : SS System Date MM : DD : YYYY Set the system date http://www.tyan.com...

  • Page 43: Bios Advanced Menu

    Configure ServerWorks S-ATA Configuration Menu Item HT1000 S-ATA Section for Advanced ACPI ACPI Configuration Menu Item Configuration Mark as read, Clear or View Event Log Configuration Menu Item Event Log statistics Hardware Health Configure/monitor the Menu Item Configuration Hardware Health http://www.tyan.com...
  • Page 44 PCI Express Configuration Menu Item L1 link power states. Remote Access Configuration Menu Item Configure Remote Access USB Configuration Menu Item Configure the USB support Device & PCI Slots Onboard Devices and PCI Add- Menu Item Configuration On Cards Enabled/Disabled http://www.tyan.com...
  • Page 45 CPU Configuration Module Version Physical Count Read only Displays information about CPU Logical Count Revision Cache L1 Cache L2 Speed Read only Displays information about CPU Current FSB Multiplier Maximum FSB Multiplier Able to change Freq. uCode Patch Level http://www.tyan.com...
  • Page 46 Continuous explicitly describes the PCI hole as non-cacheable. Enable/disable the generation of Disabled Power State Block for use of Runtime Legacy PSB PowerNow(tm) driver in a single core system. Enabled Enable/disable the generation of Disabled ACPI_PPC, _PSS, _PCT AMD PowerNow objects. Enabled http://www.tyan.com...
  • Page 47 IDE devices. This XXXX displays the status of auto detection of Primary IDE Master/Slave Not Detected IDE devices. Enabled 0~35 Selects the time out value for detecting IDE Detect Time Out (Sec) (at 5 interval) ATA/ATAPI device(s). http://www.tyan.com...
  • Page 48 S.M.A.R.T (Self-Monitoring Analysis Auto and Reporting Technology) is a S.M.A.R.T. Disabled utility that monitors your disk status Enabled to predict hard disk failure. Enabled Enables 32-bit to maximize the IDE 32Bit Data Transfer hard disk data transfer rate. Disabled http://www.tyan.com...
  • Page 49 F10 Save and Exit ESC Exit Feature Option Description Floppy Configuration Disabled 360 KB 51/4” Selects the type of floppy drive connected to the system. Floppy A 1.2 MB 51/4” Floppy B 720 KB 31/2” 1.44 MB 31/2” 2.88 MB 31/2” http://www.tyan.com...
  • Page 50 Allows BIOS to enable or disable the Onboard Floppy Controller Disabled floppy controller. 3F8/IRQ4 3E8/IRQ4 Allows BIOS to select Serial Port1 Serial Port1 Address 2E8/IRQ3 Base Addresses. Disabled 2F8/IRQ3 3E8/IRQ4 Allows BIOS to select Serial Part2 Serial Port2 Address Base Addresses. 2E8/IRQ3 Disabled http://www.tyan.com...
  • Page 51 Allow s user to enable or disable HT1000 S-ATA HT1000 S-ATA controller. Disabled P-ATA Sets S-ATA mode as P-ATA S-ATA Mode S-ATA emulation native S-ATA, or S-ATA RAID. S-ATA RAID Enabled INT13 Support Enables or disables INT13 support. Disabled http://www.tyan.com...
  • Page 52 OEMB table in the Root System AMI OEMB table Description Table (RSDT) table. Note: OEMB table is used to pass Disabled POST data to the AMI code during ACPI O/S operations. Enabled Enable or disable Headless Headless mode operation mode through ACPI. Disabled http://www.tyan.com...
  • Page 53 Mark All Events as Read read. Cancel Erases all of events. Clear Event Log Cancel View details on the count of total unread events. Other Event Log Statistics stats include size occupied and size free. (in terms of event units) http://www.tyan.com...
  • Page 54 :xxxx RPM FAN5 Speed :xx C/ xxx F FAN6 Speed :xx C/ xxx F Feature Option Description Hardware Health Configuration Enables Hardware Health Monitoring Device. Enabled H/W Health Function Disabled Selects the FAN type. 4Pin FAN FAN Select 3Pin FAN http://www.tyan.com...
  • Page 55 Hardware Health Event Monitoring Displays V oltage for CPU, Mainboard Voltages Report Read only memory, & other devices . Read only Displays Temperature CPU1 Temperature and FAN Speed. CPU2 Temperature AMB1 Temperature AMB2 Temperature CPU FAN1 Speed CPU FAN2 Speed FAN1/2/3/4/5/6 Speed http://www.tyan.com...
  • Page 56 : x.xxx V F10 Save and Exit +V3.3 (SB) : x.xxx V ESC Exit +3VDU : x.xxx V +V5 (SB) : x.xxx V : x.xxx V +12V (for cpu1 vcore) : x.xxx V +12V (for cpu2 vcore) : x.xxx V http://www.tyan.com...
  • Page 57 MPS Configuration Select MPS Revision. ? ? Select Screen MPS Revision [1.4] ? ? Select Item Change Option General Help F10 Save and Exit ESC Exit Feature Option Description MPS Configuration MPS Revision Allows user to select MPS revision. http://www.tyan.com...
  • Page 58 ? ? Select Screen ? ? Select Item Change Option General Help F10 Save and Exit ESC Exit Feature Option Description PCI Express Configuration Enabled Active State Power- Enabled/Disabled PCI Express L0s Management and L1 link power states. Disabled http://www.tyan.com...
  • Page 59 Make sure the COM2 selected port is enabled. Base Address, IRQ Read only Select Serial Port settings. 115200 8,n,1 57600 8,n,1 Serial Port Mode 19200 8,n,1 9600 8,n,1 Select Flow Control for console None redirection. Flow Control Hardware Software http://www.tyan.com...
  • Page 60 VT-UTF8 Enable VT-UTF8 Combination key Enabled VT-UTF8 Combo Key Support for ANSI/VT100 terminals. Support Disabled Gives the delay in seconds to No Delay display memory information Delay 1 Sec Sredir Memory Display Delay Delay 2 Sec Delay 4 Sec http://www.tyan.com...
  • Page 61 Option Description USB Configuration Enables support for legacy Disabled USB. Legacy USB Support Enabled This is a work around for OSes Enabled without EHCI hand-off support. BIOS EHCI Hand-Off The EHCI ownership change Disabled should claim by EHCI driver. http://www.tyan.com...
  • Page 62 Option Description MPS Configuration Disabled Onboard VGA Enabled/Disabled VGA controller Enabled Onboard LAN1, LAN2 Disabled Devices Enabled/Disabled LAN controller Onboard LAN3 Device Enabled Onboard LAN1 OP-ROM Disabled Onboard LAN2 OP-ROM Executed LAN OPROM or not Onboard LAN3 OP-ROM Enabled http://www.tyan.com...

  • Page 63: Bios Pnp/Pci Menu

    Clear NVRAM [No] Change Option Plug & Play O/S [Yes] General Help PCI Latency Timer [64] F10 Save and Exit ESC Exit PCI Bus Scan Order [Descent] Allocate IRQ to PCI VGA [Yes] Palette Snooping [Disabled] PCI IDE BusMaster [Disabled] http://www.tyan.com...
  • Page 64 Enabled: informs the PCI devices that an ISA graphics device is Enabled installed in the system so the card will function correctly. Disabled Enabled: BIOS uses PCI bus mastering for reading / writing to PCI IDE BusMaster Enabled IDE drives. Reserved http://www.tyan.com...

  • Page 65: Bios Boot Menu

    [On] PS/2 Mouse Support [Auto] ? ? Select Screen Wait for ‘F1’ if Error [Enabled] ? ? Select Item Hit ‘DEL ’ Message Display [Enabled] Interrupt 19 Capture [Enabled] Change Option General Help F10 Save and Exit ESC Exit http://www.tyan.com...
  • Page 66 Waits for F1 key to be present if error Wait for ‘F1’ If Error occurs. Disabled Enabled Displays “Press DEL to run Setup” in Hit ‘DEL’ Message Display POST. Disabled Disabled Enabled: allows option ROMs to trap Interrupt 19 Capture interrupt 19. Enabled http://www.tyan.com...
  • Page 67 ? ? Select Item Change Option General Help F10 Save and Exit ESC Exit Feature Option Description Boot Device Priority 1st Boot Device xx,xxx-xxxxx:xxx Settings for boot priority. 2nd Boot Device These can be customized xx,xxx-xxxxx:xxx depending on your Disabled preference. http://www.tyan.com...
  • Page 68 ? ? Select Screen ? ? Select Item Change Option General Help F10 Save and Exit ESC Exit Feature Option Description Removable Drives Specifies the boot sequence xx,xxx-xxxxx:xxx for removable drive booting. 1st Drive This option will show all removable devices. Disabled http://www.tyan.com...

  • Page 69: Bios Security Menu

    User Password. When it is set to [Enabled], BIOS Disabled will issue a virus warning Boot Sector Virus Protection message and beep if a write to the boot sector or the partition Enabled table of the HDD is attempted. http://www.tyan.com...

  • Page 70: Bios Chipset Menu

    4 NorthBridge Configuration Options for NB. 4 HT2000 System I/O Configuration 4 HT1000 South Bridge Configuration ? ? Select Screen ? ? Select Item Change Option Enter Go to Sub Screen General Help F10 Save and Exit ESC Exit http://www.tyan.com...
  • Page 71 CPU Node 1 It shows the clock frequency of the Memory CLK Read only installed SDRAM. This controls the timing delay (in clock cycles) before SDRAM starts a read CAS Latency (Tcl) Read only command after receiving it. http://www.tyan.com...
  • Page 72 Bits 7-4. RAS#-active to RAS#-active Read only or auto refresh of the same bank. Asynchronous Latency Bits 3-0. This filed should be loaded with a 4-bit value equal to the Read only maximum asynchronous latency in the DRAM read round-trip loop. http://www.tyan.com...
  • Page 73 MCT Timing Mode Timing Mode manually. Auto Disabled Enable Bank Memory Interleaving Bank Interleaving Auto Enable/Disable MemClk Tri-Stating Disabled MemClk Tristate during C3 and Alt VID C3/ATLVID Enabled Memory Hole Remapping Enable Memory Remapping around Enabled Memory Hole Disabled http://www.tyan.com...
  • Page 74 40ns Doing this while memory is not being 80ns used improves performance. 160ns Note: When AMD’s node interleave 320ns feature is enabled, BIOS will force 640ns DRAM scrub off. 1.28us 2.56us 5.12us 10.2us 20.5us 41.0us http://www.tyan.com...
  • Page 75 10.2us 20.5us 41.0us 81.9us 163.8us 327.7us 655.4us Disabled Allow s the L1 Data Cache RAM to 40ns be corrected while idle. 80ns 160ns 320ns 640ns 1.28us 2.56us Data Cache BG Scrub 5.12us 10.2us 20.5us 41.0us 81.9us 163.8us 327.7us 655.4us http://www.tyan.com...
  • Page 76 Disabled AGP, or disable altogether. Some 32 MB OSes require valid GART for proper 64 MB IOMMU Mode operation, If AGP is present, select 128 MB appropriate option to ensure proper 256 MB AGP operation. 512 MB 1 GB http://www.tyan.com...
  • Page 77 Change Option General Help F10 Save and Exit ESC Exit Feature Option Description Chipset Configuration Split PCI-E Master 1 to 2 Enabled (x4) Enabled/Disable EXB1 Split Disabled Split PCI-E Master 3 to 2 Enabled (x4) Enabled/Disable EXB3 Split Disabled http://www.tyan.com...
  • Page 78 Start at PowerON. POST Stop at OS boot. Watchdog Mode OS: OS boot Watchdog. Start at OS boot. PowerON PowerON: Start at PowerON. Watchdog timer sets 2/4/6/8/10/12 minutes. When WD time-out Watchdog Timer occurs, system will auto reboot. http://www.tyan.com...
  • Page 79 Feature Option Description South ridge Chipset Configuration Hide XIOAPIC PCI Enabled Hide XIOAPIC PCI functions. Functions Disabled Enabled Disable or enable power button Power Button Install Off instant off. Disabled http://www.tyan.com...

  • Page 80: Bios Exit Menu

    Use this option to load default performance setup values. Use this option when system CMOS values have been corrupted or modified incorrectly. Load Failsafe Defaults Use this option to load all default failsafe setup values. Use this option when troubleshooting. http://www.tyan.com...

  • Page 81: Chapter 4: Diagnostics

    BIOS flash failure, you must contact your dealer for a replacement BIOS. There are no exceptions. TYAN does not have a policy for replacing BIOS chips directly with end users. In no event will TYAN be held responsible for damages done by the end user.

  • Page 82: Amibios Post Code

    Initializes all the output devices. Allocate memory for ADM module and uncompress it. Give control to ADM module for initialization. Initialize language and font modules for ADM. Activate ADM module. Initializes the silent boot module. Set the window for displaying text information. http://www.tyan.com...
  • Page 83 Wait for user input at config display if needed. Uninstall POST INT1Ch vector and INT09h vector. Deinitializes the ADM module. Prepare BBS for Int 19 boot. End of POST initialization of chipset registers. Save system context for ACPI. Passes control to OS Loader (typically INT19h). http://www.tyan.com...
  • Page 84 NOTE http://www.tyan.com...

  • Page 85: Appendix I: Smdc Information

    Tyan SMDC is not a peripheral card. Unlike regular peripheral card such as AGP card, Network card or SCSI card, SMDC does not require any hardware specific driver. As long as a standby power comes into the system, SMDC will begin looking after the system.
  • Page 86 Features of Tyan Server Management Monitor various system components remotely - such as fans, processor temperature, and more Remote power on and power off Console redirect -the ability to view system remotely Alert and error actions -such as audible beep, e-mail, power down and reboot...

  • Page 87: Appendix Ii: How To Make A Driver Diskette

    Appendix II: How to Make a Driver Diskette Follow the steps below to make a driver diskette from the TYAN driver CD provided. Start the system and insert the TYAN CD into the CD-ROM drive to boot from CD. You will see the following menu. Then press [1] and [Enter] to boot the system to TYAN diskette maker.
  • Page 88 Follow the instruction on menu to insert a diskette and press [ENTER]. Please insert a formatted diskette into A:/ and press [ENTER] Writing image to drive A: Track: 36 Hoad: 8 Sector: 1 Using "ESC" key to quit the TYAN diskette maker. The system will autom atically restart. http://www.tyan.com...

  • Page 89: Glossary

    The CPU can manipulate data in a buffer before copying it to a disk drive. While this improves system performance (reading to or writing from a disk drive a single time is much faster than doing so repeatedly) there is the possibility of http://www.tyan.com...
  • Page 90 CPU. This frees up CPU resources for other tasks. As with IRQs, it is vital that you do not double up devices on a single line. Plug-n-Play devices will take care of this for you. http://www.tyan.com...
  • Page 91 BIOS, it is a ROM chip which can, unlike normal ROM, be updated. This allows you to keep up with changes in the BIOS programs without having to buy a new chip. TYAN’s BIOS updates can be found at http://www.tyan.com ESCD (Extended System Configuration Data): a format for storing information about Plug-n-Play devices in the system BIOS.
  • Page 92 PnP (Plug-n-Play): a design standard that has become ascendant in the industry. Plug-n-Play devices require little set-up to use. Devices and operating systems that are not Plug-n-Play require you to reconfigure your system each time you add or change any part of your hardware. http://www.tyan.com...
  • Page 93 AcceleRAID 150, 200 or 250, to implement RAID on a system board-embedded SCSI bus or a set of SCSI busses. SISL: SCSI Interrupt Steering Logic ( LSI ) (only on LSI SCSI boards) Sleep/Suspend mode: in this mode, all devices except the CPU shut down. http://www.tyan.com...
  • Page 94 CPUs without damaging the sensitive CPU pins. The CPU is lightly placed in an open ZIF socket, and a lever is pulled down. This shifts the processor over and down, guiding it into the board and locking it into place. http://www.tyan.com...

  • Page 95: Technical Support

    (which can have expensive consequences). If these options are not available for you then Tyan Computer Corporation can help. Besides designing innovative and quality products for over a decade, Tyan has continuously offered customers service beyond their expectations.
  • Page 96 Authorization (RMA) number. The RMA number should be prominently displayed on the outside of the shipping carton and the package should be mailed prepaid. TYAN will pay to have the board shipped back to you. Notice for the USA Compliance Information Statement (Declaration of...

This manual is also suitable for:

Thunder h2000m s3992

Table of Contents
