USER'S MANUAL
AUDIO DISTRIBUTOR
ADIS5

Advertisement

loading
Need help?

Need help?

Do you have a question about the ADIS5 and is the answer not in the manual?

Questions and answers

Related Manuals for PROEL ADIS5

Summary of Contents for PROEL ADIS5

  • Page 1 USER’S MANUAL AUDIO DISTRIBUTOR ADIS5...

  • Page 2: Important Safety Instructions

    IMPORTANT SAFETY INSTRUCTIONS To reduce the risk of electric shock do not remove cover (or back panel). No CAUTION: user serviceable parts inside. Refer servicing to qualified personnel only. To reduce the risk of fire or electric shock, do not expose this apparatus to WARNING: rain or moisture.

  • Page 3: Detailed Safety Instructions

    Sentences preceded by symbol contain important safety instruction. Please read it carefully. DETAILED SAFETY INSTRUCTIONS. Water and moisture: This apparatus should not be used near water (i.e. bathtub, kitchen sink, swimming pools, etc.) Ventilation: This apparatus should be placed in a position that doesn’t interfere with correct ventilation. This unit, for example, should not be placed on a bed, sofa cover o similar surfaces that could cover ventilation openings, or placed in a built-in installation, such a bookcase or a cabinet that could block air flow trough ventilation openings.
  • Page 4 Objects or liquid entry inside the unit: Be careful that no objects fall or liquid is spilled inside the unit through ventilation openings. Safe power line use: • Keep firmly the plug and the wall outlet while disconnecting the unit from AC power. •...
  • Page 5 Don’t place this unit in a bookshelf o in other places with small room. • PROEL S.P.A. is not responsible for any damage that occurs due to a wrong unit installation. Thank you for choosing one of Proel products, and for your confidence towards our brand, synonymous of professionalism, accuracy, high quality and reliability.

  • Page 6: Fuse Holder

    Front panel description 1. Power switch and LED 2. Input peak level LED indicators 3. Mono/stereo switch 4. Independent output level controls for CH1 and CH2 sections Rear panel description 1. IEC standard AC power supply socket 2. Fuse-holder 3. AC power selector 4.
  • Page 7 1. Input connections Input connectors are two independent balanced XLR (CH1, CH2). These connectors may be used for line level signals of different sound sources (CD player, tuner, tape, etc. Each source can be independently routed to each output (OUTPUT1, 2, 3, 4, 5). 2.
  • Page 8 Warning: before connecting and/or disconnecting any sound source to this unit, in order to avoid forthcoming units damages please make sure that the output knobs are set totally counter-clockwise. Technical Specifications Model ADIS5 Input connectors 2 balanced line level female XLR Input sensitivity/impedance 0,775V/15KΩ...
  • Page 9 Directive 73/23/EEC (Low Voltage) and following modifications 93/68/EEC, as the following standard: EN 60065:1998 Proel SpA pursue a policy of continuous research and development. Proel SpA reserve the right to modify product circuitry and appearance at any moment, without prior notice.
  • Page 10 PROEL S.p.A. (World Headquarters - Factory) Via alla Ruenia 37/43 64027 Sant’Omero (Te) – Italy Tel: +39 0861 811241 Fax: +39 0861 887862 E-mail: info@proelgroup.com installation.proelgroup.com...
