9. ZONE DISPLAY 10. ZONE SELECT 11. ENTER 12. OUTPUT LEVEL 13. ESC 14. Volume MONITOR 15. BGM ALL Note: If the power supply should fail, the BGM setting will be kept 16. PAGE ALL 17. ON/OFF Switch...
10. PANNELLO POSTERIORE fig.2 1. Mains cable connector with built-in fuse Note: if connecting with a 117 V AC 50/60 Hz mains, remember to move the mains selector to the117 V AC position (fig. 2, ref. 2) 2. Mains Selector (230/117 V AC 50/60 Hz) 3.
Page 6
Moduli di Zona A. Uscita di Zona B. GAIN fig.4 C. Tone adjustments on the zone output D. PAGE E. ZONE REMOTE CONTROL Input Note: Each remote control operates within the audio zone to which it is connected, e.g. if it is connected to ZONE REMOTE CONTROL 4 it will operate only within zone 4 Piedino N°...
F. ZONE REMOTE CONTROL button NOTE: Activate ZONE REMOTE CONTROL only when a zone remote control is connected. G. Remote source input Note: This input cannot be distributed to the other zones. H. REMOTE SOURCE GAIN Note: This gain is also active on the local source, be it microphone or line, directly connected to the remote control.
Page 8
Reproduction of the “ALERT” siren Reproduction of the “EVAC” siren Reproduction of the “BASE” siren Note: Each contact acts only on its own MATRIX88. If you have an extended system consisting of several daisy-chained MATRIX88s, contacts can be independently set.
This input is particularly useful if you want to send a prerecorded evacuation or alert message from a message generator (Proel DIGI8) interfaced with the fire alarm control panel. If you have an extended system featuring several daisy-chained MATRIX88 units, parallel connect the message generator to all the EMC IN inputs, so that the same message be heard in all the zones.
Page 10
- As long as one channel is busy with one paging console, the other paging console cannot be used - If the system includes several daisy-chained MATRIX88 units, you can only connect 2 BM8X8 paging consoles to the PAGING MIC inputs on the Master unit. Those consoles will operate on the whole system.
Page 11
11. CONNECTION DIAGRAM FOR AN 8-ZONE SYSTEM fig.5...
Page 12
12. CONNECTION DIAGRAM FOR A SYSTEM OF UP TO 32 ZONES fig.6...
Page 13
Detail of four daisy-chained MATRIX88 units 13. TIPI DI CONNESSIONE...
14. TECHNICAL FEATURES MODEL MATRIX88 Line Input Sensitivity Line Input Impedance Local Input Sensitivity Local Gain MIC1 Impedance Zone Output Zone Output Level Control S/N Ratio Channel Crosstalk Distortion (T.H.D) Rs485 Communication Protocol Power supply Dimensions (W x H x D)
