- Page 1 RBG15FA / RBG18FA OWNER’S MANUAL...
- Page 2 Thank you for purchasing this Rockville Bass Gig series Folded Horn pro audio speaker. We are very proud to bring you what we consider to be the absolute best value line pro audio speakers. This project has been a culmination of years of development involving a team of dreamers, engineers, designers and marketing gurus.
-
Page 3: Specifications
• Frequency Response: (+/-3dB) 25Hz - 120Hz • Maximum SPL @ 1w / 1m: 135dB Peak / 129dB Continuous Features RBG15FA / RBG18FA • Folded horn design powered subwoofer • Power-On and Signal Input LED Indicators • Signal Input LED Indicator •... -
Page 4: Important Safety Instructions
DO NOT OPEN • To reduce risk of electric shock, never open the unit. There are no user serviceable parts, refer service to an authorized Rockville service center. • Do not expose this unit to any kind of moisture. •... - Page 5 BASS GIG What is a Folded Horn woofer you ask? Any horn shape which gradually expands from a small inlet to a large opening will act as a physical amplifier for sound applied to the smaller end. When coupled to a loudspeaker it improves its efficiency, but a full-size horn that would work at low frequencies would make for an impractically large cabinet.
- Page 6 BAS S TREBLE TREBLE MASTER MASTER POWE R LIMI T POWE R LIMI T LINE OUT BAL LINE OUT BAL Rockville RPG-15 230V 115V 230V 115V 230V 230V AC230V/1 15V 60Hz/50H z AC230V/1 15V 60Hz/50H z T3.15A 250V T3.15A 250V...
- Page 7 TREBLE TREBLE MASTER MASTER LINE IN POWE R LIMI T POWE R LIMI T LINE OUT BAL LINE OUT BAL 230V 115V 230V 115V 230V 230V Rockville RPG-15 AC230V/1 15V 60Hz/50H z AC230V/1 15V 60Hz/50H z T3.15A 250V T3.15A 250V...
- Page 8 Folded Horn w/Dual Speaker Configuration Rockville RPG-15 Signal output from mixing board to Bass Gig subwoofer Rockville RPG-15...
- Page 9 BASS GIG Balanced vs Unbalanced Lines A balanced line is a three-conductor system in which two signal wires carry an equal, but opposite voltage with respect to the ground wire. The ground wire acts only as a shield and does not carry any audio signal current. Outside interference is either shielded from the internal signal conductor, or if it gets into the cable is cancelled out by the opposite signals at the receiving end.
- Page 11 BASS GIG 1. Full range XLR / 1/4˝ combo jack input will accept line input signal from any line level device with a balanced output jack. 2. Full range parallel XLR thru / output jacks will send the signal from the full range combo inputs to another device.
-
Page 12: Troubleshooting
Trouble Shooting UNIT FAILS TO POWER UP. 1. Make sure unit is plugged in properly to wall outlet. 2. Check that power cable is plugged in tightly to unit. 3. If people or equipment tend to step and roll over or stretch your power cable it can get damaged. -
Page 13: Federal Communications Commission Compliance Information
BASS GIG FEDERAL COMMUNICATIONS COMMISSION COMPLIANCE INFORMATION Responsible party name: Rockville Address: 600 Bayview Ave. Entrance A Inwood, NY 11096 Hereby declares that the product(s) Bass Gig series pro audio folded horn speakers com- ply with FCC rules as mentioned in the following paragraph: This device complies with Part 15 of the FCC rules. - Page 14 RockvilleAudio.com © 2016 ROCKVILLE // Features and specifications are subject to change and or improvement without notice.
