RAM12BT V2/RAM15BT V2
OWNER'S MANUAL
WHO READS MANUALS?
Instead, go to vimeo.com/443443847 or scan the QR
code and watch a short video that shows you how to set
this item up and how to use it.
If you prefer written instructions, please read ahead!
With Rockville you get many options.
Missing items? If you ordered a bundle that includes more than one product and you
are missing part of your bundle, then it just means your order shipped from two different
warehouses. You will receive the remaining items very soon. If you have any concerns
or inquiries, feel free to call our customer support center at 1-646-758-0144, Monday
through Thursday, 9am to 10pm EST, and Fridays, 9am to 3pm EST.

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the RAM12BT V2 and is the answer not in the manual?

Questions and answers

Summary of Contents for Rockville RAM12BT V2

  • Page 1 If you prefer written instructions, please read ahead! With Rockville you get many options. Missing items? If you ordered a bundle that includes more than one product and you are missing part of your bundle, then it just means your order shipped from two different warehouses.
  • Page 3 Thank you for purchasing this Rockville RAM-BT v2 series pro audio speaker with blue- tooth and TWS wireless stereo linking. Please read this installation guide carefully for prop- er use of your RAM-BT v2. Should you need assistance, please call our technical help line at 1-646-758-0144, Monday through Thursday, 9am to 10pm EST, and Fridays, 9am to 3pm EST.
  • Page 4 How To Avoid Irritating Feedback The placement of your microphone is critical in avoiding feedback through your RAM BT unit. Never set up your microphone in front of the speaker. Always set up your microphone behind the speaker. When approaching the speaker to make any adjustments, we recommend approaching the speaker from the rear and not walking directly towards the front of the speaker.
  • Page 5 Setting Level Controls It is best practice to set your input level controls (gains) in this manner: 1. Unplug all inputs except for the one you wish to set the gain for. In this instance, the Line In RCA inputs. 2.
  • Page 6 5. Once the speakers are connected, go to your phone's Bluetooth interface and select "ROCKVILLE" from the list of devices. If connection is successful, you will hear the same audio from both unit's. You are now ready to enjoy true wireless stereo sound!
  • Page 7: Line Input

    APPLICATION USES Microphone Presentations Your RAM-BT v2 features ultra-low noise Mic input via an XLR port and ¼˝ TRS stereo jack. 1. Make sure the Power switch is in the OFF position. 2. Plug your microphone into the XLR/¼˝ combo jack. 3.
  • Page 8: Record Function

    RAM-BT v2 using an XLR to XLR or XLR to ¼˝ TRS cable to share the signal. We recommend you use high quality cables such as Rockville’s RCXFM20E-B XLR to XLR cable or the RCXMB20-B XLR to ¼˝ TRS cable.
  • Page 9: Bluetooth Pairing

    3. Push the Mode button on your RAM-BT v2 unit until you are in Bluetooth mode. The LCD screen will read “BLUETOOTH Disconnected” 4. Once in Bluetooth mode, the unit should show up on your device as “ROCKVILLE”. Select it from your list of available devices.
  • Page 10: Built-In Battery

    Built-in Battery This unit includes a built-in 12 volt, 9 amp battery. This convenient features allows you to use your RAM BT for up to 12 hours in any situation where outlets are not readily available. No need to concern yourself with extension cords and the such. The unit comes with battery status LED indicators to let you know the status of the battery and when to charge the battery.
  • Page 12 1. LCD display 2. USB and SD/MMC Card input 3. MP3 Player controls: • Play/Pause, Scan, TWS - Press this button once to start music playback; press again to pause. In FM radio mode press and hold for 5 seconds to automatically scan and save all available stations.
  • Page 14 1. LCD display 2. USB and SD/MMC Card input 3. MP3 Player controls: • Play/Pause, Scan, TWS - Press this button once to start music playback; press again to pause. In FM radio mode press and hold for 5 seconds to automatically scan and save all available stations.
  • Page 16: Specifications

    Internal battery will charge when unit is plugged in. • External user serviceable fusing. Specifications RAM12BT V2 • Power: 600 Watts Peak / 300 Watts Program /150 Watts RMS • 4 Ohm 1.5˝ KSV High Power Voice Coil • 25mm, 8 Ohm Titanium Diaphragm Tweeter •...
  • Page 17: Troubleshooting

    Troubleshooting PROBLEM SOLUTION 1. Make sure the unit is plugged in and the power switch is in the No power ON position. 2. Check that the power cable is plugged in tightly to the unit. 3. Check and replace the fuse if necessary. See fuse replacement diagram on page 18.
  • Page 18: Replacing The Fuse

    Replacing the Fuse...
  • Page 19 FEDERAL COMMUNICATIONS COMMISSION COMPLIANCE INFORMATION Responsible party name: Rockville Address: 600 Bayview Ave. Entrance A Inwood, NY 11096 Hereby declares that the product(s) RAM-BT V2 pro audio speakers comply with FCC rules as mentioned in the following paragraph: This device complies with Part 15 of the FCC rules. Operation is subject to the following two conditions: (1) this device may not cause harmful interference, and (2) this device must accept any interference received, including interference that may cause undesired operation.
  • Page 20 RockvilleAudio.com © 2021 ROCKVILLE // Features and specifications are subject to change and/or improvement without notice.

This manual is also suitable for:

Ram15bt v2
